Hardware Installation and Reference Guide
Mark
4
5
1.4

Technical Specifications

Table 1-4 Specification
Radio
Specifications
Protocol and
Standard
Operating
Frequency Bands
Antenna Type
Spatial Streams
Item
connector
Reset button
Mesh button
2.4 GHz and 5 GHz 4 dual-radio
Wi-Fi 6 (802.11ax)
802.11b/g/n/ac: 2.400 GHz to 2.483 GHz
802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725
GHz, 5.725 GHz to 5.850 GHz
(country-specific restrictions apply)
External flat omni-directional antenna
2.4 GHz: 5.2 dBi
5 GHz: 4.8 dBi
2.4 GHz, 4×4, MU-MIMO
5 GHz, 4×4, MU-MIMO
Description
supply power to the router.
Press and hold for less than 1 second: No
action is triggered.
Press and hold for more than 10 seconds:
The router is restored to factory defaults.
Press and hold for less than 2 seconds: The
router establishes a mesh network with
nearby unconfigured Reyee routers or range
extenders.
4
Product Introduction
