Sharp AQUOS 4T-C60CH1X Operation Manual

4T-C60CH1X
LED BACKLIGHT TV
OPERATION MANUAL
Dear SHARP customer
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many
years of trouble-free operation of your product, please read the Important Safety Precautions
carefully before using this product.
Supplied accessories
1. Remote control unit 3. Operation manual
2. "AAA" size battery (g 2) 4. Stand base
Important Safety Precautions
• Stand base must be attached to prevent the TV set from falling down and cause injuries.
• Cleaning — Unplug the AC cord from the AC outlet before cleaning the product. Use a soft damp cloth to clean the product. Do not use
liquid cleaners, aerosol cleaners or chemical cloth to clean it, as such materials may damage the product.
• Water and moisture — Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub, swimming pool and in
a wet basement.
• Do not place vases or any other water-fi lled containers on this product.
The water may spill onto the product causing fi re or electric shock.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the product to fall, resulting in serious
personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer
or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer's instructions. Use only the mounting
hardware recommended by the manufacturer.
• When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops, excessive force and uneven fl oor
surface can cause the product to fall from the cart.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings
since insuffi cient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or
other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product
in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer's instructions are followed.
• The LCD panel used in this product is made of glass. Therefore, it can break when the product is struck forcefully or with a sharp object.
If the LCD panel is broken, be careful not to be injured by broken glass.
• Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating products
(including amplifi ers).
• To prevent fi re, never place any type of candle or naked fl ames on the top or near the TV set.
• To prevent fi re or shock hazard, do not place the AC power cord under the TV set or other heavy items.
• Do not place heavy objects on this product or stand on it. Doing so could cause injury if the product overturns. Take special care near
children and pets.
• The LCD panel is a very high technology product with 8,294,400 pixels, giving you fi ne picture details.
Due to the very large number of pixels, occasionally a few non-active pixels may appear on the screen as a fi xed point of blue, green or red.
This is within product specifi cations and does not constitute a fault.
• Precautions when transporting the TV
When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always carry the TV by two
people holding it with two hands — one hand on each side of the TV.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• Install the product on the place where the AC cord can be unplugged easily from the AC outlet or from the AC INPUT terminal on the
rear of the product.
• If a television is not positioned in a suffi ciently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to
children, can be avoided by taking simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the television.
• Only using furniture that can safely support the television.
• Ensuring the television is not overhanging the edge of the supporting furniture.
• Not placing the television on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the
television to a suitable support.
• Not standing the televisions on cloth or other materials placed between the television and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television or its controls.
• Do not install the TV in a location in which it will be subject to water drops such as underneath an air conditioning unit or in the vicinity of
a humidifi er.
• Water drops falling onto the TV and water entering inside it may result in fi re, electric shock, or malfunctions.
• We recommend that you install the TV at least 1m away from the outlet of an air conditioner.
TINS-H375WJZZ
5. Screws (g 4)
Printed in Malaysia
TINS-H375WJZZ
20P04-MA-NF
1
Attaching the stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC outlet.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from
being damaged.
1
Confi rm the screws supplied with the TV.
Screws (4)
2
Insert the stand assembly into the openings on
the bottom of the TV. (1)
3
Insert and tighten the screws into the holes on
the rear of the TV. (2)
Connecting external devices
You can connect many types of external equipment to your TV, like a VCR, game console, camcorder, DVD
player, Digital TV STB (Set Top Box) and PC. To view external source images, select the input source from
INPUT on the remote control unit or INPUT on the TV.
CAUTION
• To protect all equipment, always turn off the TV before connecting to a VCR, game console, camcorder, DVD player, Digital
TV STB (Set Top Box), PC or other external equipment.
• Refer to the relevant operation manual (VCR, DVD player, etc.) carefully before making connections.
Using composite cable
SUPPLY POWER
TOTAL 2A DC5V
USB
/ AUDIO OUT(L/R)
VCR/Game
console/
Camcorder
Connecting a PC
HDMI 1
1
HDMI
HDMI 2
2
SUPPLY POWER
TOTAL 2A DC5V
USB
HDMI 3
/ AUDIO PC
OUT(L/R) 3
CAUTION
• Do not disconnect a USB device from the TV while transferring fi les, when a screen is in "USB" mode.
Symbols placed on equipment
• This mark indicates the product operates on AC Voltage.
• This mark indicates a class II or double insulated electrical appliance wherein the product does not require a safety
connection to electrical earth (ground).
2
Soft cushion
Stand base
Stand base
with letter "L"
with letter "R"
Using HDMI-certifi ed cable
HDMI
HDMI 1
1
SUPPLY POWER
DC5V TOTAL 2A
USB
OUT(L/R) / AUDIO
DVD player/Digital TV STB
(Set Top Box)
Connecting a USB device
USB
SUPPLY POWER
TOTAL 2A DC5V
USB
/ AUDIO
OUT(L/R)
