Toshiba Qosmio G55-Q802 Specifications

Qosmio G55 Detailed Product Specification
Model Name G55-Q804
:
C1 2

Operating System

• Genuine Windows Vista ®
Home Premium (SP1, 64-bit version)
• Genuine Windows Vista
®
Home Premium (SP1, 32-bit version)

Processor and Chipset

® ®
Intel Centrino 2 Processor Technology featuring:
• Intel
®
Core™ 2 Duo Processor P7350
o 2.0GHz, 3MB L2 Cache, 1066MHz FSB
• Mobile Intel
®
PM45 Express Chipset
• Intel
®
WiFi Link 5100AGN (802.11 a/g/n)
5
Memory
• Configured with 4096MB PC6400 DDR2 800MHz SDRAM (both
memory slots may be occupied). Maximum capacity 4096MB
6
Storage Drive
• 320GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive
• DVD SuperMulti (+/- double layer) drive with Labelflash™ supporting 11
formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
o Supports Labelflash™ media to burn high quality labels directly
8
Display
• 18.4" diagonal widescreen TruBrite
1680x945 native resolution (HD+)
9
Graphics
• PCI-Express™ x16 graphics subsystem, featuring:
® ®
o NVIDIA GeForce 9200M GS, 256MB GDDR2 discrete graphics
memory, plus up to 1791MB dynamically allocated shared
graphics memory using NVIDIA
o Total Available Graphics memory 2047MB (64-bit version)
Sound
• 2 built-in harman/kardon
®
speakers plus1 sub-woofer
• Sound volume control dial
• Built-in microphone
Input Devices
• 104 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Mute button
o Media button
o CD/DVD control buttons (Play/Pause, Stop, Previous Track, Next
Track)
o Panel lights
o Camera
o Dolby settings
Communications
• Webcam and microphone built into LCD bezel
• FM Tuner with antenna
• 10/100/1000 Ethernet
• Integrated Wi-Fi
®
compliant wireless:
®
Intel WiFi Link 5100AGN (802.11 a/g/n)
o
• Consumer infrared for remote control
• Wireless USB
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
1
Part Number: PQG55U-03103D
3
4
7
®
TFT active-matrix LCD display at
®
TurboCache™ technology.
10
11
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
MultiMedia Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o REGZA LINK™ (HDMI-CEC)
o 1080p support
• Audio
o S/P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports with USB Sleep and Charge
o 3 x USB v2.0
o 1 x eSATA/USB combo port
o RJ-45 LAN port
Physical Description
• Fusion™ Finish with Vibe pattern
• Dimensions (WxDxH Front/H Rear): 17.8" x 12.2" x 1.5" /1.9" with feet
• Weight: Starting at 10.8 lbs, depending upon configuration
Power
• 120W (19V x 6.3A) Auto sensing ,100-240V/50-60Hz AC Adapter
o Dimensions (WxDxH): 6.10" x 2.63" x 1.43
o Weight: starting at 1.25 lbs
14
Battery
• 7050mAh Lithium Ion battery pack
C1
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree
o TOSHIBA Disc Creator
o TOSHIBA DVD Player
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Speech System
o TOSHIBA Face Recognition
o TOSHIBA Resources
o Hard disc (HDD) recovery
• Third-party Software
o WildTangent
o Google™ Toolbar
o Google™ Desktop(only on 32 bit Home Premium)
o Google™ Picasa™ (only on 32 bit Home Premium)
®
o Sun Java™ 2 Runtime Environment
®
o Adobe
®
o Ulead DVD MovieFactory
o Computrace
o PowerCinema for TOSHIBA
• Trial Software
o Microsoft
60-day trial edition Norton 360™ All-In-One Security
• Special Offers
o Amazon.com-Online Shopping
®
o Intuit Quickbooks
o Skype™
o eMusic
Environmental Specifications
Qosmio G55-Q804 1.0
UPC: 883974150533
15
®
®
Orb™ Games Console
®
Acrobat Reader
®
5 for TOSHIBA
® ®
LoJack for Laptops
®
Office Ready with Microsoft Office Professional 2007
®
Financial Center
Operating
12
13
Non-operating
Page 1 of 4
