Summary of Contents for Toshiba Qosmio G30

  • Page 1 User’s Manual Qosmio G30...
  • Page 2 This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the TOSHIBA Qosmio G30 Portable Personal Computer at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice.
  • Page 3 Photo CD is a trademark of Eastman Kodak. Sonic RecordNow! and Sonic PrimeTime are registered trademarks of Sonic Solutions. Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license. Memory Stick is a registered trademark and i.LINK is a trademark of Sony Corporation.
  • Page 4 Modem warning notice Conformity Statement The equipment has been approved to [Commission Decision “CTR21”] for pan-European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
  • Page 5: Optical Disc Drive Safety Instructions

    Optical disc drive safety instructions Be sure to check the international precautions at the end of this section. Panasonic Shikoku DVD Super Multi with Double Layer Recording UJ-846 ■ The DVD Super Multi drive with Double Layer Recording model employs a laser system. To ensure proper use of this product, please read this instruction manual carefully and retain for future reference.
  • Page 6 International precautions CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest “AUTHORIZED service station.”...
  • Page 7 OBS! Apparaten innehåller laserkomponent som avger laserstråining överstigande gränsen för laserklass 1. VAROITUS. Suojakoteloa si saa avata. Laite sisältää laserdiodin, joka lähetää näkymätöntä silmilie vaarallista lasersäteilyä. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER’S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
  • Page 8 viii User’s Manual...
  • Page 9: Table Of Contents

    Table of Contents Preface General Precautions Introduction Chapter 1 Equipment checklist........1-1 Features.
  • Page 10 Replacing the battery pack ....... . .6-12 TOSHIBA Password Utility ....... . .6-14 Starting the computer by password .
  • Page 11 TOSHIBA support ........
  • Page 12 Regulatory statements........E-3 Using Bluetooth™ Card from TOSHIBA equipment in Japan ..E-6...
  • Page 13: Preface

    When Windows is running, you can display or record a TV program using the My TV feature of Media Center. This manual tells how to set up and begin using your Qosmio G30 computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.
  • Page 14 Preface Chapter 4, Operating Basics, This chapter describes the basic operations of your computer and precautions when using it, as well as the handling of CDs/DVDs. Chapter 5, Keyboard, describes special keyboard functions including the keypad overlay and hot keys. Chapter 6, Power, gives details on the computer’s power resources and battery save modes.
  • Page 15 Preface Key operation Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, Ctrl + C means you must hold down Ctrl and at the same time press C.
  • Page 16 Preface User’s Manual...
  • Page 17: General Precautions

    General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the general precautions below and to note the cautions included in the text of the manual.
  • Page 18 General Precautions PC card overheating Some PC cards can become hot with prolonged use. Overheating of a PC card can result in errors or instability in the PC card operation. Also be careful when you remove a PC card that has been used for a long time. Mobile phone Use of mobile phones can interfere with the audio system.
  • Page 19 General Precautions Cooling vents Cooling vents To prevent possible overheating of the CPU, make sure the cooling fan’s air intake is not blocked. The fan draws in air by creating a vacuum. If the fan is blocked, it could cause the CPU to run at a lower performance level or cause the computer to shut down.
  • Page 20 General Precautions User’s Manual...
  • Page 21: Equipment Checklist

    Some of the features described in this manual may not function properly if you use an operating system that was not preinstalled by TOSHIBA. Equipment checklist Carefully unpack your computer. Save the box and packing materials for future use.
  • Page 22 TOSHIBA Hotkey Utility for Display Devices ■ TOSHIBA Display Device Change Utility ■ TOSHIBA Password Utility ■ TOSHIBA RAID Utility ■ Bluetooth Stack for Windows by Toshiba (depending on the model purchased) ■ DVD-RAM Driver ■ Wireless Hotkey utility ■ Display Driver ■...
  • Page 23: Features

    If any of the items are missing or damaged, contact your dealer immediately. Features The computer uses TOSHIBA’s advanced Large Scale Integration (LSI), Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to provide compact size, minimum weight, low power usage, and high reliability. This computer incorporates the following features and...
  • Page 24 Introduction Video RAM There are two different types of graphics controllers. The Video RAM specifications will differ depending on the type of graphics controller used in the computer. ■ nVIDIA GeForce Go 7300 model: 256MB of RAM is provided for video display. Part of system memory is used for Video RAM.
  • Page 25: Optical Media Drive

    Introduction Legal Footnote (HDD Drive Capacity) For more information on the Legal Footnote regarding HDD Drive Capacity, please refer to the Legal Footnotes section in Chapter 11. USB floppy disk Accommodates either 3 1/2" 1.44-megabyte or drive (optional) 720-kilobyte floppy disks. It connects to a USB port.
  • Page 26: Pointing Device

    Introduction Display The computer’s LCD panel supports high-resolution video graphics. The screen can be set at a wide range of viewing angles for maximum comfort and readability. Built-in 17" TFT LCD screen, 32 M colors, with one of the following resolutions: ■...
  • Page 27 Introduction Universal Serial Bus The computer has Universal Serial Bus ports that (USB 2.0) comply with the USB 2.0 standard, which enables data transfer speeds 40 times faster than the USB 1.1 standard (The ports also support USB 1.1). i.LINK™ (IEEE1394) This port enables high-speed data transfer directly from external devices such as digital video cameras.
  • Page 28 Introduction The computer is equipped with either an HDMI or D-Video out port. Headphone (S/PDIF) This jack lets you connect digital speakers or stereo headphones (16 ohm minimum). When jack you connect a digital speaker or headphones, the internal speakers are automatically disabled. This jack can be used also as S/PDIF jack and enables connection of optical digital correspondence apparatus.
  • Page 29 Introduction Bluetooth Some computers in this series are equipped with Bluetooth functions. Bluetooth wireless technology eliminates the need for cables between electronic devices such as computers and printers. Bluetooth provides fast, reliable, and secure wireless communication in a small space. Wireless LAN Some computers in this series are equipped with a Wireless LAN mini-PCI card that is compatible...
  • Page 30: Special Features

    Connects a security lock to anchor the computer to a desk or other large object. Special features The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use. Hot keys...
  • Page 31 You can specify the setting in the When I close the lid item of the Setup Action tab in TOSHIBA Power Saver. Low battery When battery power is exhausted to the point that...
  • Page 32: Utilities

    To access this power savings management Saver program, click start, click the Control Panel, click Performance and Maintenance and click the TOSHIBA Power Saver icon. HW Setup This program lets you customize your hardware settings according to the way you work with your computer and the peripherals you use.
  • Page 33 Enhancement Utility according to your viewing environment lets you select external input settings for Video. TOSHIBA ConfigFree TOSHIBA ConfigFree is a suite of utilities to allow easy control of communication devices and network connections. TOSHIBA ConfigFree also allows you to find communication problems and create profiles for easy switching between locations and communication networks.
  • Page 34 Bluetooth cannot be used in models that do not have a Bluetooth module installed. TOSHIBA Touch and TOSHIBA Touch and Launch is a tool that allows Launch you to perform various tasks easily using the Touch Pad. TOSHIBA Touch and Launch is useful in the following conditions.
  • Page 35: Options

    (DDR2 533/667 MHz) can easily be installed in the computer. Battery Pack An additional battery pack can be purchased from your TOSHIBA dealer. Use it as a spare or replacement. High Capacity An additional high capacity battery pack can be purchased from your TOSHIBA dealer.
  • Page 36 Introduction 1-16 User’s Manual...
  • Page 37: Chapter 2 The Grand Tour

    Chapter 2 The Grand Tour This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer. Legal Footnote (Non-applicable Icons) For more information on the Legal Footnote regarding Non-applicable Icons, please refer to the Legal Footnotes section in Chapter 11.
  • Page 38: Left Side

    The Grand Tour ■ Turn WiFi and Bluetooth functionalities off when near a person who may have a cardiac pacemaker implant or other medical electric device. Radio waves may affect pacemaker or medical device operation, possibly resulting in serious injury. Follow the instruction of your medical device when using any WiFi or Bluetooth functionality.
  • Page 39 The Grand Tour Keep foreign objects out of the USB connectors. Never allow metal objects, such as screws, staples and paper clips, to enter the PC or keyboard. Foreign metal objects can create a short circuit, which can cause PC damage and fire, possibly resulting in serious injury. Operation of all functions of all USB devices has not been confirmed.
  • Page 40: Right Side

    The Grand Tour Headphone (S/PDIF) This jack lets you connect digital speakers or a jack stereo headphone (16 ohm minimum). When you connect a digital speaker or headphones, the internal speaker is automatically disabled. This jack can be used also as S/PDIF jack and enables connection of optical digital correspondence apparatus.
  • Page 41: Back Side

    The Grand Tour ■ Connection to any communication line other than an analog phone line could cause a PC system failure. ■ Connect the built-in modem only to ordinary analog phone lines. ■ Never connect the built-in modem to a digital line (ISDN). ■...
  • Page 42 The Grand Tour Do not block the cooling vents. Never allow metal objects, such as screws, staples and paper clips, to enter the PC or keyboard. Foreign metal objects can create a short circuit, which can cause PC damage and fire, possibly resulting in serious injury.
  • Page 43: Underside

    The Grand Tour Underside The following figure shows the underside of the computer. Make sure the display is closed before turning over your computer. Memory module cover HDD2 Battery pack Battery safety lock Battery release latch HDD1 The underside of the computer Memory module This cover protects memory module sockets.
  • Page 44: Front With The Display Open

    The Grand Tour Battery release Slide and hold this latch to release the battery latch pack for removal. For detailed information on removing the battery packs, refer to Chapter 6, Power. Battery pack The battery pack powers the computer when the AC adaptor is not connected.
  • Page 45 The Grand Tour Display screen The LCD screen displays high-contrast text and graphics. The available resolution depends on the model. With WXGA+, you can change the resolution between 800 × 600 and 1440× 900 pixels. With WUXGA, between 800 × 600 and 1920 × 1200 pixels. Refer to Display Controller and Modes in Appendix B.
  • Page 46: System Indicators

    Hibernation mode. Use the TOSHIBA Power Saver Utility to enable or disable this feature. The default is “enabled”. Refer to the TOSHIBA Power Saver Utility and Panel Power Off/On items in Chapter 1, Introduction, for details on settings.
  • Page 47: Keyboard Indicators

    The Grand Tour Power The Power indicator glows blue when the computer is on. If you select Standby from Shut Down Windows, this indicator flashes orange (one second on, two seconds off) while the computer shuts down. Battery The Battery indicator shows the condition of the battery’s charge: blue indicates full charge, orange indicates battery charging and flashing orange indicates a low battery charge.
  • Page 48: Optical Media Drives

    The Grand Tour The following indicators show the status of the display overlay. Numeric Mode indicator Arrow Mode indicator Keypad overlay indicators Arrow mode When the Arrow mode indicator lights green, you can use the keypad overlay (gray labeled keys) as cursor keys. Refer to the Keypad overlay section in Chapter 5,...
  • Page 49: Region Codes For Dvd Drives And Media

    The Grand Tour Region codes for DVD drives and media DVD Super Multi drives and media are manufactured according to the specifications of six marketing regions. When you purchase DVD-Video media, make sure it matches your drive, otherwise it will not play properly. Code Region Canada, United States...
  • Page 50: Dvd Super Multi Drive Double Layer

    The Grand Tour Formats The drive supports the following formats: ■ ■ CD-ROM DVD -Video ■ ■ DVD-ROM CD-Text ■ ■ HD DVD CD-ROM Mode 1, Mode 2 ■ ■ CD-DA Enhanced CD (CD-EXTRA) ■ ■ Photo CD™ Addressing Method 2 (single/multi-session) ■...
  • Page 51: Ac Adaptor

    For use in other regions, please buy power cords that conform to safety rules and regulations in the particular region. Always use the Toshiba AC adaptor that was provided with your PC and the Toshiba Battery Charger (that may have been provided with your PC), or use Toshiba recommended alternate models to avoid any risk of fire or other damage to the PC.
  • Page 52 The Grand Tour 2-16 User’s Manual...
  • Page 53: Chapter 3 Getting Started

    Chapter 3 Getting Started This chapter provides basic information to get you started using your computer. It covers the following topics: ■ Setting up your work space - for your health and safety Be sure also to read Instruction Manual for Safety & Comfort. This guide, which is included with the computer, explains product liability.
  • Page 54: General Conditions

    PC, it could cause a system failure, malfunction or loss of data. If dust contaminates the PC, do not turn on the power. Take it to an authorized Toshiba service provider before you use it. ■ Never place your PC near an object that generates a magnetic field, such as a speaker or TV.
  • Page 55: Placement Of The Computer

    Getting Started ■ Leave ample ventilation room for the fan. Do not block the vents. ■ If the PC interferes with radio equipment, turn the PC power off immediately. Such interference could cause equipment malfunction. ■ Never place your PC on a shaky table, uneven, tilted surface or other unstable location.
  • Page 56: Seating And Posture

    Getting Started Seating and posture Maintain a comfortable working posture when using your PC where your body joints are naturally aligned to reduce stress on different parts of your body. Consider the following: Below eye level 90°angles Foot rest Posture and positioning of the computer ■...
  • Page 57: Work Habits

    Getting Started Lighting Select the right level of illumination and place your PC appropriately to minimize glare from overhead lights, desk lamps and windows. Glare on the LCD or monitor may cause eye strain, eye fatigue or headaches. Consider the following suggestions regarding lighting your work environment: ■...
  • Page 58: Connecting The Ac Adaptor

    Getting Started Strategic Rest Breaks Take short, strategically spaced rest breaks to avoid eye strain and body discomforts. For more specific recommendations on the safety and comfort of your computer environment, customers in the United States may visit the United States Department of Labor, Occupational Safety &...
  • Page 59 Getting Started ■ Always use the Toshiba AC adaptor that was provided with your PC and the Toshiba Battery Charger (that may have been provided with your PC), or use Toshiba recommended alternate models to avoid any risk of fire or other damage to the PC. Use of an incompatible AC adaptor or Battery Charger could cause fire or damage to the PC possibly resulting in serious injury.
  • Page 60 Getting Started 1. Connect the power cord to the AC adaptor. Connecting the power cord to the AC adaptor (2-pin plug) Connecting the power cord to the AC adaptor (3-pin plug) Depending on the model, a 2-pin plug or 3-pin plug set of the above may be bundled.
  • Page 61: Opening The Display

    Getting Started Opening the display The display panel can be rotated in a wide range of angles for optimal viewing. 1. Push the display latch on the front of the computer to unlatch the display panel. 2. While holding down the palm rest with one hand so that the main body is not raised, lift the panel slowly.
  • Page 62: Starting Up For The First Time

    Getting Started 2. Press and hold the computer’s power button for two or three seconds. Power button Turning on the power Starting up for the first time When you first turn on the power, the computer’s initial screen is the Microsoft Windows XP Startup Screen Logo.
  • Page 63: Standby Mode

    ■ When the AC adaptor is connected, the computer will go into Standby mode according to the settings in the TOSHIBA Power Saver utility. ■ To restore operation from Standby Mode, press the power button or press any key. The latter action only works on the internal keyboard if the Wake-up on Keyboard option is enabled in HW Setup.
  • Page 64: Hibernation Mode

    1. Click start, click Turn Off Computer and click Standby. 2. Close the display panel. This feature must be enabled. Refer to the Setup Action tab in TOSHIBA Power Saver Utility described in the Control Panel. Open Performance and Maintenance and open TOSHIBA Power Saver.
  • Page 65: Starting Hibernation Mode

    For the computer to shut down in Hibernation Mode, this feature must be enabled in two places: the Hibernate tab in Power Options and Setup Action tab in TOSHIBA Power Saver. If you do not configure this feature, the computer will shut down in Standby Mode - if battery power becomes depleted, data saved in Standby Mode will be lost.
  • Page 66: Restarting The Computer

    Getting Started Data save in Hibernation Mode When you turn off the power in Hibernation Mode, the computer takes a moment to save current memory data to the hard disk. During this time, the HDD indicator will light. After you turn off the computer and memory is saved to the hard disk, turn off the power to any peripheral devices.
  • Page 67: Restoring Toshiba Utilities And Drivers

    Restoring TOSHIBA utilities and drivers If Windows is working properly, individual drivers or applications can be separately restored. The TOSHIBA Tools & Utilities folder (C:\TOOLSCD) contains drivers and applications, which are included with your computer system. If your system drivers or applications have become damaged in some way, you can reinstall most of the components from this folder.
  • Page 68 Getting Started 3-16 User’s Manual...
  • Page 69: Chapter 4 Operating Basics

    Chapter 4 Operating Basics This chapter describes the basic operations of your computer and precautions when using it, as well as the handling of CD/DVD. Using the Touch Pad Touch Pad Touch Pad control buttons Touch Pad and Touch Pad control buttons To use the Touch Pad, simply touch it with a fingertip and move the finger along the pad in the direction you want the on-screen pointer to move.
  • Page 70: Using Optical Media Drives

    Operating Basics You can also tap the Touch Pad to perform functions similar to those of the left button. Click: Tap once Double-click: Tap twice Drag and drop: Tap to select the object you want to move. Leave your finger on the Touch Pad after the second tap and move your finger along the pad to move the object.
  • Page 71: Removing Discs

    Operating Basics Removing discs To remove the CD/DVD, follow the steps below. 1. Check that your computer is on. If not, turn your computer on. 2. Press the Eject button. The CD/DVD will be ejected about halfway. Do not place your hand or another object near the optical media drive slot.
  • Page 72: Writing Cd/Dvds On Dvd Super Multi Drive

    DVD Super Multi drive may not function properly, and you may fail to write or rewrite, lose data or incur other damage. Legal Footnotes TOSHIBA does not bear responsibility for the following: ■ Damage to any CD-R/RW or DVD-R/-RW/+R/+RW/-RAM disc that may be caused by writing or rewriting with this product.
  • Page 73: Before Writing Or Rewriting

    Based on TOSHIBA’s limited compatibility testing, we suggest the following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM disc. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates.
  • Page 74 Operating Basics DVD-RAM: (DVD Super Multi drive only) DVD Specifications for DVD-RAM Disc for Version 2.0, Version 2.1 or Version 2.2 Matsushita Electric Industrial Co., Ltd. Hitachi Maxell Ltd. ■ This drive cannot use discs that allow writing faster than 8 speed (DVD-R, DVD+R), 4 speed (DVD-RW, DVD+RW), 5 speed (DVD-RAM), 2.4 speed (DVD+R DL), 2 speed (DVD-R DL).
  • Page 75: When Writing Or Rewriting

    Operating Basics ■ Do not run software such as a screen saver, which can put a heavy load on the CPU. ■ Operate the computer in the full-power mode. Do not use power-saving features. ■ Do not write while virus check software is running. Wait for it to finish and then disable virus detection programs including any software that checks files automatically in the background.
  • Page 76 Operating Basics RecordNow! Basic for TOSHIBA Note the following limitations when you use RecordNow!: ■ DVD-Video cannot be created using RecordNow!. ■ DVD-Audio cannot be created using RecordNow!. ■ You cannot use RecordNow!’s “Audio CD for Car or Home CD Player”...
  • Page 77: Data Verification

    3. Mark the Verify data written to the disc after burning check box in the Data Options. 4. Click the OK button. DLA for TOSHIBA Note the following limitations when you use DLA: ■ This software supports only rewritable discs (DVD+RW, DVD-RW, and CD-RW).
  • Page 78: When Using Windvd Creator Platinum

    Operating Basics When using WinDVD Creator Platinum You can record video back to your digital camcorder via i.LINK (IEEE1394) using WinDVD Creator Platinum. However, there is a case where you may find that playback sound is choppy -if this is the case follow the below instructions: 1.
  • Page 79: Important Information For Use

    2. Before recording the video to DVD ■ When you record to DVD discs, please use only media recommended by TOSHIBA. ■ Do not set the working drive to a slow device like a USB 1.1 hard disk drive or it will fail to write DVD.
  • Page 80: Media Care

    Operating Basics ■ Please verify your disc after recording important data. ■ DVD-R/+R/-RW disc cannot be written in VR format. ■ WinDVD Creator cannot export to DVD-Audio, VideoCD, miniDVD format. ■ WinDVD Creator can write DVD-RAM/+RW in VR format, but the disc may only play on your computer.
  • Page 81: Floppy Disks

    Operating Basics 6. If your CD/DVDs become dusty or dirty, wipe them with a clean dry cloth. Wipe from the center out, do not wipe in a circular direction around the CD/DVD. If necessary, use a cloth dampened in water or a neutral cleaner.
  • Page 82: Tv Tuner

    Operating Basics TV Tuner Use the My TV feature of Media Center in Windows mode to watch TV programs or record them. According to the government regulations, it is not permitted to bring PAL/SECAM TV tuners into Korea. Using the TV Tuner Antenna ■...
  • Page 83 Operating Basics 2. Connect the antenna adaptor to the TV antenna port of your computer. TV antenna port Antenna adaptor Connecting the antenna adaptor 3. Connect the antenna cable to the other end of the antenna adaptor. Antenna adaptor Antenna cable Connecting the antenna cable When you have been using a descrambler to receive the programs on cable TV or satellite broadcasting, connect the descrambler to the antenna...
  • Page 84: Sound System

    Operating Basics Sound System This section describes audio controls including sound levels and power management. Volume Control The Volume Control utility lets you control the audio volume in Windows for both playback and recording. ■ To launch Volume Control for playback, click start, point to All Programs, point to Accessories, point to Entertainment and click Volume Control.
  • Page 85: Audio Power Management

    Operating Basics Audio power management The audio controller can be powered down when the audio function is not used. To enable audio power management, follow the steps below. 1. Click the Advanced tab. 2. Check the Enable Power Management check box. 3.
  • Page 86: Modem

    Check the specified areas carefully before using it. To select a region, follow the steps below. 1. Click start, point to All Programs, point to TOSHIBA, point to Networking and click Modem Region Select. Do not use the Country/Region Select function in the Modem setup utility in the Control Panel if the function is available.
  • Page 87: Properties Menu

    Operating Basics Properties menu Click the icon with the secondary mouse button to display properties menu on the screen. Setting You can enable or disable the following settings: AutoRun Mode The Region Select utility starts automatically when you start up the operating system.
  • Page 88 Operating Basics Connecting To connect the modular cable, follow the steps below. The modular cable that comes with the computer must be used to connect a modem. Connect the end of the modular cable with the core to the computer. ■...
  • Page 89: Wireless Communications

    Operating Basics Disconnecting To disconnect the modular cable, follow the steps below. 1. Pinch the lever on the connector in the telephone jack and pull out the connector. 2. Disconnect the modular cable from the computer’s modem jack in the same manner.
  • Page 90: Worldwide Operation

    ■ TOSHIBA is not liable for the loss of data due to eavesdropping or illegal access through the wireless LAN and the damage thereof. Bluetooth wireless technology Bluetooth™...
  • Page 91: Product Support

    Please refer also to the electronic information which is included with each software. This Bluetooth™ Stack is based on Bluetooth™ Version 1.1/1.2/2.0+EDR specification. TOSHIBA cannot confirm compatibility between any PC products and/or other electronic devices that use Bluetooth™ other than TOSHIBA mobile PCs.
  • Page 92: Wireless Communication Switch

    Operating Basics Wireless communication switch You can enable or disable wireless communication functions with the on/off switch. No transmissions are sent or received when the switch is off. Slide the switch to the right to turn it on and to the left to turn it off. ■...
  • Page 93: Lan

    Operating Basics The computer has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX) and Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T). Some models are equipped with a Gigabit Ethernet LAN. This section describes how to connect/disconnect to a LAN.
  • Page 94: Cleaning The Computer

    Operating Basics 2. Plug one end of the cable into the LAN jack. Press gently until you hear the latch click into place. LAN jack Connecting the LAN cable 3. Plug the other end of the cable into a LAN hub connector. Check with your LAN administrator before connecting to a hub.
  • Page 95: Moving The Computer

    Operating Basics Moving the computer The computer is designed for rugged durability. However, a few simple precautions taken when moving the computer will help ensure trouble-free operation. ■ Make sure all disk activity has ended before moving the computer. Check the HDD indicator on the computer. ■...
  • Page 96 Operating Basics 4-28 User’s Manual...
  • Page 97: Chapter 5 The Keyboard

    Chapter 5 The Keyboard The computer’s keyboard layouts are compatible with a 101/102-key enhanced keyboard. By pressing some keys in combination, all the 101/102-key keyboard functions can be executed on the computer. The number of keys on your keyboard depends on which country/region’s keyboard layout your computer is configured with.
  • Page 98: Function Keys: F1

    Soft keys: Fn key combinations The Fn (function) is unique to TOSHIBA computers and is used in combination with other keys to form soft keys. Soft keys are key combinations that enable, disable or configure specific features.
  • Page 99: Hot Keys

    The Keyboard Press Fn + F10 or Fn + F11 to access the integrated keypad. When activated, the keys with gray markings on the bottom edge become numeric keypad keys (Fn + F11) or cursor control keys (Fn + F10). Refer to Keypad overlay section in this chapter for more information on how to operate these keys.
  • Page 100 Continue holding down Fn and press F2 again to change the setting. You can also change this setting through the profile item in TOSHIBA Power Saver. Standby: When you press Fn + F3, the computer enters Standby. To avoid entering Standby unexpectedly, a dialog box appears for verification.
  • Page 101 The brightness level is always set at the maximum value for about 18 seconds, when the LCD turns on. After 18 seconds, the brightness level will return to the level set within the TOSHIBA Power Saver utility or you can change it manually.
  • Page 102: Windows Special Keys

    Fn key. Fn Sticky key You can use the TOSHIBA Accessibility Utility to make the Fn key sticky, that is, you can press it once, release it, and then press an “F number” key. To start the TOSHIBA Accessibility Utility, click start, point to All Programs, point to TOSHIBA, point to Utilities and click Accessibility.
  • Page 103: Keypad Overlay

    The Keyboard Keypad overlay Your computer’s keyboard does not have an independent numeric keypad, but its numeric keypad overlay functions like one. The keys in the center of the keyboard with gray letters make up the numeric keypad overlay. The overlay provides the same functions as the numeric keypad on the 101/102-key enhanced keyboard in figure 5-2.
  • Page 104: Generating Ascii Characters

    The Keyboard Temporarily using normal keyboard (overlay on) While using the overlay, you can temporarily access the normal keyboard without turning off the overlay: 1. Hold Fn and press any other key. All keys will operate as if the overlay were off.
  • Page 105: Power

    Chapter 6 Power The computer’s power resources include the AC adaptor and internal batteries. This chapter gives details on making the most effective use of these resources including charging and changing batteries, tips for saving battery power, and power up modes. Power conditions The computer’s operating capability and battery charge status are affected by the power conditions: whether an AC adaptor is connected, whether a...
  • Page 106: Power Indicators

    Power Power conditions (continued) Power on Power off (no operation) Battery charge • Operates adaptor is above low • LED: Battery off battery trigger DC IN off connected point Battery charge • Operates is below low • LED: Battery battery trigger flashes orange point DC IN off...
  • Page 107: Battery Types

    Power DC IN indicator Check the DC IN indicator to determine the power status with the AC adaptor connected: Indicates the AC adaptor is connected and Blue supplying proper power to the computer. Indicates a problem with the power supply. Plug Flashing orange the AC adaptor into another outlet.
  • Page 108: Battery Pack

    The battery pack is a lithium ion battery, which can explode if not properly replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Always use the battery pack supplied as an accessory or an equivalent battery pack specified in the User’s Manual.
  • Page 109: Real Time Clock Battery

    The computer’s RTC battery is a Ni-MH battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations.
  • Page 110: Care And Use Of The Battery Pack

    Power Care and use of the battery pack The battery pack is a vital component of portable computing. Taking proper care of it will help ensure longer operating time on battery power as well as a longer life for your battery pack. Follow the instructions in this section carefully to ensure safe operation and maximum performance.
  • Page 111 Do not turn on the PC’s power again until an authorized Toshiba service provider has checked it for safety. Continued use could cause a fire or rupture possibly resulting in serious injury or PC failure including but not limited to the loss of data.
  • Page 112 Power Caution 1. Use only battery packs recommended by TOSHIBA as replacements. 2. When installing a battery pack or before moving the PC, always make sure the battery pack is inserted correctly and securely. If the battery falls out, while you are carrying the PC, you could be injured or the battery pack could be damaged.
  • Page 113: Charging The Batteries

    The Battery indicator glows orange when the battery is being charged. Use only the computer connected to an AC power source or the optional TOSHIBA Battery charger to charge the battery pack. Never attempt to charge the battery pack with any other charger.
  • Page 114: Battery Charging Notice

    Therefore, an often used, older battery will not operate for as long as a new battery even when both are fully charged. In this case, TOSHIBA Power Saver will indicate a 100% charge for both the old and new battery, but the displayed estimated time remaining will be shorter for the older battery.
  • Page 115: Maximizing Battery Operating Time

    ■ How you configure the computer (for example, whether you enable battery-power saving options). The computer provides a battery save mode, which can be set in TOSHIBA Power Saver, to conserve battery power. This mode has the following options: ■...
  • Page 116: Replacing The Battery Pack

    Power Extending battery life To maximize the life of your battery pack: ■ At least once a month, disconnect the computer from a power source and operate it on battery power until the battery pack fully discharges. Before doing so, follow the steps below. 1.
  • Page 117 Power ■ Do not remove the battery pack while the computer is in Standby mode. Data is stored in RAM, so if the computer loses power it will be lost. ■ In Hibernation mode, data will be lost if you remove the battery or disconnect the AC adaptor before the save is completed.
  • Page 118: Toshiba Password Utility

    Windows password. User password To start the utility, point to or click the following items: start -> All Programs -> TOSHIBA -> Utilities -> Password Utility ■ Set (button) Click this button to register a password of up to 50 characters. After a password is set, you will be prompted to enter it when you start the computer.
  • Page 119: Starting The Computer By Password

    To set a supervisor password, follow the steps below. 1. Click start. 2. Click Run. 3. Enter the following: C:\Program Files\Toshiba\Windows Utilities\SVPWTool\TOSPU.EXE If you set a supervisor password, some functions might be restricted when a user logs on with the user password.
  • Page 120: Power-Up Modes

    Started. Windows utilities You can configure various settings associated with both Standby Mode and Hibernation Mode within TOSHIBA Power Saver. Hot keys You can use hot keys Fn + F3 to enter Standby mode and Fn + F4 to enter Hibernation.
  • Page 121: Chapter 7 Hw Setup

    Chapter 7 HW Setup This chapter explains how to use TOSHIBA HW Setup program to configure your computer, and other setting. Accessing HW Setup To run HW Setup, click start, click Control Panel, click Printers and Other Hardware and select TOSHIBA HW Setup.
  • Page 122: Power On Display

    HW Setup Display This tab lets you customize your computer’s display settings for either the internal LCD screen or for an external monitor. Power On Display Lets you select the display to be used when the computer is booted - this setting is only available with standard VGA modes and cannot be configured through the Windows Desktop properties.
  • Page 123: Boot Priority

    HW Setup Boot Priority Boot Priority Options This option sets the priority for booting the computer. Select from the following settings: “HDD” here refers to the Built-in HDD that is defined in the HDD Priority Option so that it should be recognized first. HDD −>...
  • Page 124 HW Setup To change the boot drive, follow the steps below. 1. Hold down F12 and boot the computer. 2. The following menu will be displayed with the following icons: Built-in HDD1, Built-in HDD2, CD-ROM, floppy disk drive, Network (LAN) boot. A bar will appear only under the selected device.
  • Page 125 HW Setup ■ If a boot command is not found on the first detected HDD, the system will not boot from the other HDD. It will search the next device in the boot priority for a boot command. ■ Although, generally, most models have two hard disks installed, some models have only one hard disk.
  • Page 126: Device Config

    HW Setup Wake-up on LAN This feature lets the computer’s power be turned on when it receives a wake-up signal from the LAN. Enables Wake-up on LAN. Enabled Disables Wake-up on LAN (Default). Disabled Do not install or remove an optional memory module while Wake-up on LAN is enabled.
  • Page 127: Other Settings

    ■ In most cases, changes to the system's configuration should be made within Windows by using applications such as TOSHIBA HW Setup, TOSHIBA Password Utility, TOSHIBA Power Saver, Windows Device Manager and so forth. If you make changes to the configuration through the BIOS setup program, please be aware that the configuration set through the Windows applications will take priority.
  • Page 128: Starting The Bios Setup Program

    If “Password =” is displayed, enter either the Supervisor Password, if one is set, or the user password and press the Enter key. Please refer to Chapter 6, the TOSHIBA Password Utility, for details about the user password. The “Check system. Then press [F1] key.” message is displayed.
  • Page 129 Capability so that it is not available for use. (Default). System configuration changes, other than changes to this setting, should be made within Windows by using applications such as TOSHIBA HW Setup, TOSHIBA Password Utility, TOSHIBA Power Saver, Windows Device Manager and so forth.
  • Page 130: Virtualization Technology

    HW Setup Virtualization Technology Virtualization Technology sets enable or disable of the Intel Virtualization Technology installed in the CPU. The configuration for the Virtualization Technology is carried out in the BIOS setup program. This setting is displayed on the first page of the setup screen.
  • Page 131: Chapter 8 Using The Remote Controller, Front Operation Panel And Qosmioplayer

    Chapter 8 Using the Remote Controller, Front operation panel and QosmioPlayer This chapter explains how to use the Remote Controller as well as provides information about QosmioPlayer. The state where Windows XP is active is referred to as Windows mode, whereas the state where QosmioPlayer is active is referred to as QosmioPlayer mode.
  • Page 132: Front Operation Panel

    Using the Remote Controller, Front operation panel and QosmioPlayer Front operation panel This section describes the buttons on the front operation panel in Windows mode. Please do not press the buttons too strenuously. Eleven buttons are available for use: TV, CD/DVD, Play/Pause, Stop, Previous, Next, Record, Brightness down, Brightness up, DOLBY, TV-out.
  • Page 133 Record button Press this button to manually record a TV program while using Live TV in Media Center. The button’s setting can be changed in TOSHIBA Controls properties. To access the TOSHIBA Controls properties, click start, click the Control Panel, click Printers and the Software and select the TOSHIBA Controls icon.
  • Page 134 Using the Remote Controller, Front operation panel and QosmioPlayer Windows Media Center Edition Icon Front operation Media Center - Media Center - Media Center - button My TV (TV) Play DVD (DVD) My Music (CD) Run Media Center and start My TV.
  • Page 135: Remote Controller

    Using the Remote Controller, Front operation panel and QosmioPlayer Remote Controller Your computer includes a Remote Controller which enables you to perform some functions of your computer from a distant location. The following figure shows the buttons on the Remote Controller. You can use your Remote Controller with Media Center to play CDs, DVDs and videos, to view pictures and to watch and record television programs.
  • Page 136 Using the Remote Controller, Front operation panel and QosmioPlayer My music My pictures Power Access indicator My TV My videos Stop Pause Play Record Fast Forward Rewind Skip More info Replay Back Start Arrows Volume + Channel/Page Volume - Mute Recorded TV DVD Menu Live TV...
  • Page 137 Power Off state of your computer. To change the setting, click start, select Control panel -> Performance and Maintenance ->TOSHIBA Power Saver -> Setup Action -> Manual Setup. The following five options are available: No action, Ask me what to do, Standby, Hibernate and Shut down.
  • Page 138 Using the Remote Controller, Front operation panel and QosmioPlayer Back Displays the previous window. More Info The button provides more details on a TV program than is listed in the Guide. Arrows Moves the cursor to navigate within Media Center windows. Selects the desired action or menu option.
  • Page 139: Using The Remote Controller

    Using the Remote Controller, Front operation panel and QosmioPlayer Using the Remote Controller This computer includes a remote control unit, which allows you to control some of your computer’s functions from a distant location. ■ The Remote Controller is designed specifically for this computer. ■...
  • Page 140 Using the Remote Controller, Front operation panel and QosmioPlayer 2. Connect the external infrared Remote control receiver to one of the computer’s USB ports. USB port Connecting the USB cable to the computer’s USB port 3. Connect the infrared transmitter cable to the external infrared Remote control receiver.
  • Page 141 Using the Remote Controller, Front operation panel and QosmioPlayer 30 degrees Infrared receiver window 30 degrees 15degrees (vertically) 15degrees (vertically) Remote Controller Operational range of the remote control * The appearance of the provided Remote Controller may vary from model to model.
  • Page 142: Installing/Removing Batteries

    Using the Remote Controller, Front operation panel and QosmioPlayer Installing/Removing batteries Be sure to install the dry batteries provided with your computer before using the Remote Controller. The procedures for installing and removing the batteries vary depending on the type of the Remote Controller. Check the type and then install or remove the batteries as instructed.
  • Page 143: Installing The Batteries

    Using the Remote Controller, Front operation panel and QosmioPlayer Installing the batteries 1. Open the battery cover on the back side of the Remote Controller. Push the tab in the direction of the arrow (1) to open the cover (2). Battery cover Opening the battery cover 2.
  • Page 144: Watching Tv

    Using the Remote Controller, Front operation panel and QosmioPlayer Replacing the batteries When the batteries in the Remote Controller reach the end of their life, the Remote Controller may not operate correctly or work only within a short distance from your computer. In this instance, you should purchase new batteries and replace the discharged ones.
  • Page 145 Using the Remote Controller, Front operation panel and QosmioPlayer Connecting the set-top box 1. Connect the VIDEO-IN cable that is bundled with the computer. 2. Insert the output cable plug for connecting to the set-top box to the audio input terminals (red: audio right, white: audio left) and the video input connector (yellow) of the VIDEO-IN cable.
  • Page 146: Qosmioplayer

    Using the Remote Controller, Front operation panel and QosmioPlayer Connecting the VIDEO-IN port This port allows you to import video data from analog video cameras or video decks by connecting your computer to this type of device. Imported video can be edited or written to a DVD disk. 1.
  • Page 147: Qosmioplayer Mode

    Using the Remote Controller, Front operation panel and QosmioPlayer QosmioPlayer mode Nine buttons are available for use: TV, CD/DVD, Play/Pause, Stop, Previous, Next, Record, Brightness down, Brightness up. These buttons allow you to manage Audio/Video functions, run applications and access utilities. Front operation panel Refer to the Front operation button in the Front operation panel...
  • Page 148 Using the Remote Controller, Front operation panel and QosmioPlayer My music My pictures Power Access indicator My TV My videos Stop Pause Play Record Fast Forward Rewind Skip More info Replay Back Start Arrows Volume + Channel/Page Volume - Mute Recorded TV DVD Menu Live TV...
  • Page 149 Power Off state of your computer. To change the setting, click start, select Control panel -> Performance and Maintenance -> TOSHIBA Power Saver -> Setup Action -> Manual Setup. The following five options are available: No action, Ask me what to do, Standby, Hibernate and Shut down.
  • Page 150 Using the Remote Controller, Front operation panel and QosmioPlayer Back Displays the previous window. More Info The button provides more details on a TV program than is listed in the Guide. Arrows Moves the cursor to navigate within Media Center windows. Selects the desired action or window option.
  • Page 151 Using the Remote Controller, Front operation panel and QosmioPlayer Functions via the Remote Controller and the keyboard in the QosmioPlayer mode The list shows how the functions available from the keyboard correspond to those available from the Remote Controller in the QosmioPlayer mode. Note that some functions of the Remote Controller in the list may not be supported by the Remote Controller you are using.
  • Page 152 Using the Remote Controller, Front operation panel and QosmioPlayer BACK Menu cancel or Menu cancel or hides back or return MORE Changes the Changes the CD Changes the channel display playback time status display mode display mode mode Move the cursor Move the cursor DOWN Move the cursor...
  • Page 153 Using the Remote Controller, Front operation panel and QosmioPlayer LIVE TV Start Terminate Terminate QosmioPlayer QosmioPlayer QosmioPlayer (TV) (CD) (DVD) -> Start -> Start QosmioPlayer QosmioPlayer (TV) (TV) DVD MENU Displays the top menu DVD MENU Terminate Start Start QosmioPlayer QosmioPlayer QosmioPlayer (TV) ->...
  • Page 154 Using the Remote Controller, Front operation panel and QosmioPlayer LCD Brightness LCD Brightness LCD Brightness Fn + F7 Switch TV/Line LCD Brightness LCD Brightness LCD Brightness Down Down Down Fn + F6 Display/Do Not Display/Do Not Display Settings Display Settings Menu Menu Ctrl + K...
  • Page 155: List Of Language Codes

    Using the Remote Controller, Front operation panel and QosmioPlayer List of language codes When inputting the QosmioPlayer language codes, refer to the list shown below. Code English Name of Code English Name of Language Language Modern Greek Afar Abkhazian English Afrikaans Esperanto Amharic;...
  • Page 156 Using the Remote Controller, Front operation panel and QosmioPlayer Code English Name of Code English Name of Language Language Interlingue Maori Inupiaq Macedonian Malayalam Indonesian Icelandic Mongolian Italian Moldavian Marathi Hebrew Japanese Malay Yiddish Maltese Myanmar; Javanese Burmese Georgian Nauruan Kazakh Nepali Greenlandic;...
  • Page 157 Using the Remote Controller, Front operation panel and QosmioPlayer Code English Name of Code English Name of Language Language Russian Tajiki Kinyarwanda; Thai Rwanda Sanskrit Tigrinya Turkmen Sindhi Sangho Tagalog Serbo-Croatian Setswana; Tswana Sinhalese; Tonga Singhalese Slovak Turkish Slovenian Tsonga Samoan Tatar Shona;...
  • Page 158: Operational Range Of The Remote Control

    Using the Remote Controller, Front operation panel and QosmioPlayer Operational range of the remote control Point the remote control at your computer and press a button. The operational angle and distance are described below. Within 5 m from the infrared receiver window. Distance Within about 30 degrees horizontally and about Angle...
  • Page 159: Restrictions Of The Qosmioengine

    WinDVD and the QosmioEngine feature of QosmioPlayer. Users can select from three video quality modes depending on their preferences for watching videos. A dedicated utility (TOSHIBA Picture Enhancement Utility) running on Windows is developed to allow users to select a mode and a sharpness level.
  • Page 160: Nvidia Geforce Go 7300

    Using the Remote Controller, Front operation panel and QosmioPlayer nVIDIA GeForce Go 7300 TOSHIBA Picture Enhancement Utility on nVIDIA GeForce Go 7300 model Available image quality modes Three image quality modes are available Dynamic: To enjoy a vivid picture Standard: To enjoy a calm atmosphere in a room...
  • Page 161 Using the Remote Controller, Front operation panel and QosmioPlayer Available noise reduction levels Three noise reduction levels are available: Low, Medium, High Image noise is reduced and the screen image becomes smooth and sharp if a higher level is chosen. This function is available InterVideo WinDVD.
  • Page 162 Using the Remote Controller, Front operation panel and QosmioPlayer 8-32 User’s Manual...
  • Page 163: Chapter 9 Optional Devices

    Chapter 9 Optional Devices Optional devices can expand the computer’s capabilities and its versatility. This chapter describes connection or installation of the following devices, which are available from your TOSHIBA dealer: Cards/memory ■ PC card ■ ExpressCard ■ Bridge media slot ■...
  • Page 164: Pc Card

    The computer is equipped with a PC card slot that can accommodate one 5 mm Type II card. Any PC card that meets industry standards (manufactured by TOSHIBA or other vendor) can be installed. The slot supports 16-bit PC cards, including PC card 16’s multifunction card and CardBus PC cards.
  • Page 165: Expresscard

    ExpressCard The computer is equipped with an ExpressCard slot. Any ExpressCard that meets industry standards (manufactured by TOSHIBA or other vendor) can be installed. The slot supports hot plug connection and utilizes the PCI- Express interface that supports the reading and writing of data at a theoretical maximum rate of 2.5 Gbps.
  • Page 166: Removing An Expresscard

    Optional Devices To insert an ExpressCard, follow the steps below: 1. Insert an ExpressCard in the ExpressCard card slot. 2. Press gently to ensure a firm connection. ExpressCard slot ExpressCard Inserting an ExpressCard 3. After inserting the ExpressCard, refer to the ExpressCard’s documentation and check the configuration in Windows to make sure it is appropriate for your ExpressCard.
  • Page 167: Bridge Media Slot

    TOSHIBA SD memory card format utility, not with the format commands provided within Windows. In order to run TOSHIBA SD memory card format, click start, point to All Programs, point to TOSHIBA, point to Utilities and click SD memory card Format.
  • Page 168: Inserting An Sd Card

    Optional Devices The TOSHIBA SD memory card format utility does not format the protected area of the SD memory card. Should you need to format all areas of the memory card, including the protected area, you will need to obtain an appropriate application that applies the copy protection system.
  • Page 169: Sd Card Care

    Optional Devices ■ Make sure the Bridge media slot indicator is out before you remove the SD card or turn off the computer’s power. If you remove the SD card or turn off the power while the computer is accessing the SD card you may lose data or damage the card.
  • Page 170: Write Protection

    Optional Devices Write protection Memory Stick can be write protected to safeguard your data. To write-protect a Memory Stick, slide the lock on the back of the Memory Stick to the lock position. Inserting a Memory Stick To insert a Memory Stick, follow the steps below. 1.
  • Page 171: Xd Picture Card

    Optional Devices xD picture card The computer is equipped with a Bridge media slot that can accommodate xD picture cards with various memory capacities. The xD picture card let you easily transfer data from devices, such as digital cameras that use xD picture card flash-memory.
  • Page 172: Memory Card Care

    Optional Devices Memory card care ■ Memory cards are consumable items, so make sure you back up important data. ■ Do not twist or bend memory cards. ■ Do not expose memory cards to liquids or store in humid areas or lay media close to containers of liquid.
  • Page 173 Optional Devices 2. Press gently to ensure a firm connection. MultiMediaCard Bridge media slot Inserting a MultiMediaCard Make sure the MultiMediaCard is oriented properly before you insert it. Removing a MultiMediaCard To remove a MultiMediaCard, follow the steps below. 1. Open the Safely Remove Hardware icon on the Task Bar. 2.
  • Page 174: Memory Expansion

    When you install or remove a memory module, ensure that you do not touch any other internal areas of the computer. ■ Use only memory modules approved by TOSHIBA. ■ Do not try to install or remove a memory module under the following...
  • Page 175: Installing A Memory Module

    Optional Devices If you install a memory module that is not compatible with the computer, a beep will sound when you turn on the power. If the incompatible module is installed in slot A, there will be a long beep (1 second) followed by one short beep (0.5 seconds), while if the incompatible module is in slot B, there will be a long beep followed by two short beeps.
  • Page 176 Optional Devices 6. Align the notch of the memory module with that of the memory slot and gently insert the module into the slot at about a 45 degree angle before pressing it down until the latches on either side snap into place. Slot B Slot A Seating the memory module...
  • Page 177: Removing A Memory Module

    Optional Devices 9. Turn your computer over. 10. Turn the power on and make sure the added memory is recognized. Click start, click Control Panel, click Performance and Maintenance and select the System icon. Open System Properties window and click General tab. Removing a memory module To remove the memory module, make sure the computer is in boot mode then:...
  • Page 178: Battery Packs

    Optional Devices 8. Seat the memory module cover and secure it with one screw. Be sure that the cover is closed firmly. 9. Install the battery pack. Refer to Replacing the battery pack section in Chapter 6, Power, for details. 10.
  • Page 179: Installing The Hard Disk Drive Pack

    Optional Devices 5. Lift the cover up and out to remove it. Screw Hard disk drive cover Removing the Hard disk drive cover 6. With the hard disk drive in a vertical position, lift it straight up and away from the connector. Hard disk drive pack Removing the Hard disk drive pack...
  • Page 180: Usb Floppy Disk Drive

    Optional Devices 4. With the connector connected, lower the hard disk drive down to the storage position. Hard disk drive pack Installing a Hard disk drive pack 5. Seat the cover and press down until the latches click into place. 6.
  • Page 181: Using The Usb Floppy Disk Drive

    Optional Devices Floppy disk slot Insert a floppy disk in this slot. Eject button When a floppy disk is fully seated in the drive, the eject button pops out. To remove a floppy disk, push in the eject button and the floppy disk pops out partially for removal.
  • Page 182: External Monitor

    Optional Devices If you connect the floppy disk drive after turning on the computer, it will take about 10 seconds for the computer to recognize the drive. Do not disconnect and reconnect before 10 seconds has elapsed. Disconnecting a USB floppy disk drive When you have finished using the floppy disk drive, follow the procedures below to disconnect it: 1.
  • Page 183 Optional Devices 3. Turn the monitor’s power on. 4. Turn the computer on. When you turn on the power, the computer automatically recognizes the monitor and determines whether it is color or monochrome. To change the display settings, press Fn + F5. If you disconnect the monitor before you turn the computer off, be sure to press Fn + F5 to switch to the internal display.
  • Page 184: Settings For Display Video On Tv

    Optional Devices Connection via the D-Video out port 1. Plug one end of the D-Video out cable into the D-Video out port of your computer. D-Video out port Connecting the D-Video out port 2. Insert the other end of the D-Video out cable into the video input terminal of the TV set (Use your computer’s speakers or a headphone to get sound.
  • Page 185: Hdmi

    Optional Devices Changing the resolution After you connect a TV (NTSC), follow the steps below to set the Display resolution to 640 × 480. 1. Open Display properties and select the Settings tab. 2. Select Advanced. 3. Select the Adapter tab, then select List All Modes..4.
  • Page 186: Settings For Display Video On Hdmi

    Optional Devices Settings for display video on HDMI To view video on the HDMI device, be sure to configure the following settings otherwise you may find that nothing is displayed. ■ Be sure to use the Fn + F5 HotKey to select the display device before starting to play video.
  • Page 187: S-Video-In

    Optional Devices c. From the Full screen device drop down menu, select Primary display or Secondary display to enable movie display on an external TV or CRT monitor. Primary Device: Movies will be displayed full screen on the computer’s internal LCD and in a window on the TV or CRT monitor. Secondary Device: Movies will be displayed full screen on the TV or CRT monitor and in a window on the computer’s internal LCD.
  • Page 188: I.link (Ieee1394)

    There is a possibility that the original data will be damaged. There is a particular risk that some frames will be deleted in the case of digital video transfer. TOSHIBA assumes no liability for such loss of data. ■ Do not transfer data in areas where static electricity is easily generated or in areas subjected to electronic noise.
  • Page 189: Bluetooth Usb Adaptor

    Bluetooth USB Adaptor A Bluetooth adaptor that has a USB connector. Wireless communications can be carried out with Bluetooth-compatible equipment by connecting to the USB port of the computer. You can buy the module from TOSHIBA dealer. User’s Manual 9-27...
  • Page 190: Security Lock

    Optional Devices Security lock Security locks enable you to anchor your computer a desk or other heavy object to help prevent unauthorized removal of the computer. Attach one end of a cable to a desk and the other end to the security lock slot on the right side of the computer.
  • Page 191: Troubleshooting

    Chapter 10 Troubleshooting TOSHIBA designed the computer for durability. However, should problems occur, following the procedures in this chapter can help to determine the cause. All readers should become familiar with this chapter. Knowing what might go wrong can help prevent problems from occurring.
  • Page 192: Preliminary Checklist

    Troubleshooting Preliminary checklist Consider the simplest solution first. The items in this checklist are easy to fix and yet can cause what appears to be a serious problem. ■ Make sure you turn on all peripheral devices before you turn on the computer.
  • Page 193: Hardware And System Checklist

    Before using a peripheral device or application software that is not an authorized Toshiba part or product, make sure the device or software can be used with your PC. Use of incompatible devices may cause injury or may damage your PC.
  • Page 194: Self Test

    This message remains on the screen for a few seconds. If the self test is successful, the computer tries to load the operating system, depending on how the Boot Priority is set in the TOSHIBA HW Setup program. If any of the following conditions are present, the self test failed: ■...
  • Page 195: Ac Power

    Troubleshooting AC power If you have trouble turning on the computer with the AC adaptor connected, check the DC IN indicator. Refer to Chapter 6, Power, for more information. Problem Procedure AC adaptor doesn’t Check the connections. Make sure the cord is power the computer firmly connected to the computer and a power (DC IN indicator does...
  • Page 196: Real Time Clock

    Fully discharge the battery, then try to charge it again. Check the power consumption settings in TOSHIBA Power Saver utility. Consider using a power saving mode. Real Time Clock Problem Procedure The following The RTC battery charge has expired.
  • Page 197: Internal Lcd Display Panel

    Troubleshooting Password Problem Procedure Cannot enter Refer to the TOSHIBA Password Utility section in password Chapter 6, Power. Keyboard Keyboard problems can be caused by your setup configuration. For more information refer to Chapter 5, Keyboard. Problem Procedure Some letter keys...
  • Page 198: Hard Disk Drive

    Troubleshooting Hard disk drive Problem Procedure Computer does not Check if a floppy disk is in the floppy disk drive or boot from hard disk a CD-ROM is in the optical media drive. Remove drive any floppy disk and/or CD-ROM and check the Boot priority.
  • Page 199 Troubleshooting Some CD/DVDs run The software or hardware configuration may be correctly, but others do causing a problem. Make sure the hardware configuration matches your software’s needs. Check the CD/DVD’s documentation. Check the type of CD/DVD you are using. The drive supports: DVD-ROM: DVD-ROM, DVD-Video...
  • Page 200 Troubleshooting ExpressCard Refer also to Chapter 9, Optional Devices. Problem Procedure ExpressCard error Reseat the ExpressCard to make sure it is firmly occurs connected. Make sure the connection between the external device and the card is firm. Check the card’s documentation. If problems persist, contact your dealer.
  • Page 201: Infrared Receiver Window

    Troubleshooting xD picture card Refer also to Chapter 9, Optional Devices. Problem Procedure xD picture card error Reseat the xD picture card to make sure it is occurs firmly connected. Check the card’s documentation. You cannot read a file Make sure the target file is on the xD picture card inserted in the slot.
  • Page 202: Touch Pad

    Troubleshooting Pointing device If you are using a USB mouse, also refer to the USB section in this chapter and to your mouse documentation. Touch Pad Problem Procedure On-screen pointer The system might be busy. If the pointer is does not respond to shaped as an hourglass, wait for it to return to its Pad operation normal shape and try again to move it.
  • Page 203: Usb Mouse

    Troubleshooting USB mouse Problem Procedure On-screen pointer The system might be busy. If the pointer is shaped as an hourglass, wait for it to resume its does not respond to normal shape and try again to move it. mouse operation Make sure the mouse is properly connected to the USB port.
  • Page 204 Troubleshooting Memory expansion Refer also to Chapter 9, Optional Devices, for information on installing memory modules. Problem Procedure Beep sounds. Make sure the memory module installed in the expansion slot is compatible with the computer. (Two beeps, a dash and a dot, for a If an incompatible module has been installed, defective memory follow the steps below.
  • Page 205 Troubleshooting External monitor Refer also to Chapter 9, Optional Devices, and to your monitor’s documentation. Problem Procedure Monitor does not turn Make sure that the external monitor’s power switch is on. Confirm that the external monitor’s power cable is plugged into a working power outlet.
  • Page 206: Wireless Lan

    Troubleshooting Problem Procedure Character display In data transmission, make sure the parity bit and becomes garbled stop bit settings correspond with those of the during a remote computer. communication Check the flow control and communication protocol. You cannot receive an Check the rings before auto answer setting in incoming call your communications application.
  • Page 207: Tv Output Signal

    Troubleshooting Bluetooth For more information on wireless communication, refer to Chapter 4, Operating Basics. Problem Procedure Cannot access Make sure the computer’s wireless Bluetooth device communication switch is set to on. Make sure the Bluetooth Manager is running and the power to the Bluetooth device is turned on. Make sure no optional Bluetooth PC card is installed in the computer.
  • Page 208: Video Playback

    Troubleshooting i.LINK (IEEE1394) device Problem Procedure i.LINK device does not Make sure the cable is securely connected to the function computer and to the device. Make sure the device’s power is turned on. Click start, click Control Panel and double-click the Add Hardware icon.
  • Page 209: Disposing Of Pc And Pc Batteries

    Troubleshooting Disposing of PC and PC batteries ■ Discard this PC in accordance with ordinances or rules of local regulations. For further information, contact your local government. ■ This PC contains rechargeable batteries. After repeated use, the batteries will finally lose their ability to hold a charge and you will need to replace them.
  • Page 210: Toshiba Support

    Troubleshooting TOSHIBA support If you require any additional help using your computer or if you are having problems operating the computer, you may need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience may be related to software or the operating system, it is important to investigate other sources of assistance first.
  • Page 211: Chapter 11 Legal Footnotes

    Chapter 11 Legal Footnotes This chapter states the Legal Footnotes information applicable to TOSHIBA computers. In the text in this manual, *XX is used to show which Legal Footnotes description is related to TOSHIBA computers. Description(s) related to this computer are marked with a blue *XX in this manual.
  • Page 212 Published battery life numbers are achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power.
  • Page 213 Legal Footnotes HDD Drive Capacity 1 Gigabyte (GB) means 10 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 2 = 1,073,741,824 bytes, and therefore shows less storage capacity.
  • Page 214 Legal Footnotes Copy Protection Copy protection technology included in certain media may prevent or limit recording or viewing of the media. TV Tuner TV Tuner will function only in the country where the computer was purchased. Images All images are simulated for purposes of illustration. Qosmio™...
  • Page 215: Specifications

    Appendix A Specifications This appendix summarizes the computer’s technical specifications. Physical Dimensions Weight 4.8 kilograms, configured with: 17" WUXGA, 2GB × 2, 120GB (maximum) HDD ×2, DVD-Super Multi drive with Double Layer, modem, LAN (100M Bit), Wireless LAN, Bluetooth, TV tuner. Weight will vary with other configurations.
  • Page 216: Power Requirements

    Specifications Power Requirements AC adaptor 100-240 volts AC 50 or 60 hertz (cycles per second) Computer 15 VDC 8.0 amperes Built-in Modem Network control unit (NCU) Type of NCU Type of line Telephone line (analog only) Type of dialing Pulse Tone Control command AT commands...
  • Page 217 Specifications Transmitting level -10 dBm Receiving level -10 to -40 dBm Input/output 600 ohms ±30% impedance Error correcting MNP class 4 and ITU-T V.42 Data compression MNP class 5 and ITU-T V.42bis Power supply +3.3V (supplied by computer) User’s Manual...
  • Page 218 Specifications User’s Manual...
  • Page 219: Display Controller And Modes

    Appendix B Display Controller and Modes Display controller The display controller interprets software commands into hardware commands that turn particular parts on the screen on or off. As indicated below, there are two types of LCD Internal Panels. Various video modes can be displayed on each LCD Internal panel. Refer to the table on the next page which describes in detail supported video modes.
  • Page 220: Video Modes

    Display Controller and Modes Video modes The computer supports video modes defined in the tables below. If your application offers a selection of mode numbers that do not match the numbers on the table, select a mode based on mode type, resolution, character matrix, number of colors and refresh rates.
  • Page 221 Display Controller and Modes Table1 Video modes (VGA) continued Video Type Resolution Character Colors Scanning mode matrix (pels) frequency Vertical (Hz) 320 × 200 8 × 8 16 of 256K Grph Pels 640 × 200 8 × 8 16 of 256K Grph Pels 640 ×...
  • Page 222 Display Controller and Modes Table 3 Video modes (WXGA) ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 223 Display Controller and Modes Table 3 Video modes (WXGA) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 224 Display Controller and Modes Table 3 Video modes (WXGA) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 225 Display Controller and Modes Table 3 Video modes (WUXGA) ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 226 Display Controller and Modes Table 3 Video modes (WUXGA) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 227 Display Controller and Modes Table 3 Video modes (WUXGA) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 228: Powermizer

    Display Controller and Modes PowerMizer The PowerMizer function is only available in nVIDIA models. PowerMizer is a graphics processor installed on this computer. The performance of PowerMizer can be configured in three ways. To define the performance, select the menu options shown below: Display Property ->...
  • Page 229: Wireless Lan

    Appendix C Wireless LAN This appendix is intended to help you get your Wireless LAN network up and running, with a minimum of parameters. Card Specifications Form Factor PCI Express Mini Card ■ IEEE 802.11 Standard for Wireless LANs Compatibility ■...
  • Page 230: Radio Characteristics

    Wireless LAN Radio Characteristics Radio Characteristics of Wireless LAN Cards may vary according to: ■ Country/region where the product was purchased ■ Type of product Wireless communication is often subject to local radio regulations. Although Wireless LAN wireless networking products have been designed for operation in the license-free 2.4GHz and 5GHz band, local radio regulations may impose a number of limitations to the use of wireless communication equipment.
  • Page 231: Supported Frequency Sub-Bands

    Wireless LAN Supported Frequency Sub-bands Subject to the radio regulations that apply in the countries/regions, your Wireless LAN card may support a different set of 5 GHz/2.4 GHz channels. Consult your Authorized Wireless LAN or your dealer for information about the radio regulations that apply in the countries/regions.
  • Page 232 Wireless LAN Wireless IEEE 802.11 Channels Sets (Revision A) Frequency Range 5150-5850 MHz Note Channel ID* 5180 5200 5220 5240 5260 5280 5300 5320 5500 5520 5540 5560 5580 5600 5620 5640 5660 5680 5700 5745 5765 5785 5805 5825 Factory-set default channels Refer to the sheet Approved Countries/Regions for use for the countries/regions that in which these channels can be used.
  • Page 233: Toshiba Raid

    Appendix D TOSHIBA RAID TOSHIBA RAID (Redundant Array of Independent Disks) realizes high performance or fault tolerance, which are configured by arraying multiple independent hard disk drives. 2 hard disk drives can be used to construct a RAID configuration (RAID-1: mirroring or RAID-0: Striping).
  • Page 234: Setting Up Windows Manually

    Creating the TOSHIBA RAID Driver Floppy Disk 1. Connect the USB floppy disk drive (optional) and insert a floppy disk. 2. Locate the TOSHIBA RAID Driver in the Tools & Drivers Depository on your hard disk drive (“C:\TOOLSCD\RAID driver” folder).
  • Page 235 Therefore, to ensure that such situations do not happen, perform RAID-1 media checks regularly. The TOSHIBA RAID Console is set by default to perform media checks once a month. ■ When using RAID-0 (Striping) configuration, the size seen by the OS is twice that of the smaller of the two HDD units in the RAID configuration.
  • Page 236: Starting, Modifying And Ending The Bios Setup Program

    TOSHIBA RAID Starting, Modifying and Ending the BIOS Setup Program Starting the BIOS Setup Program 1. Switch on your computer while pressing the Esc key. If Password = is displayed, enter either the Supervisor Password, if one is set, or the User Password and press the Enter key.
  • Page 237 TOSHIBA RAID 3. The Execute Creation message is displayed once the configuration is modified. Move the cursor to the appropriate location and press the space bar to continue. Pressing the Home key will revert the modified Create State settings back to the Current State settings.
  • Page 238 TOSHIBA RAID User’s Manual...
  • Page 239: Bluetooth Wireless Technology Interoperability

    Appendix E Bluetooth wireless technology Interoperability Bluetooth™ Cards from TOSHIBA are designed to be interoperable with any product with Bluetooth wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to: ■ Bluetooth Specification Ver2.0+EDR, as defined and approved by The Bluetooth Special Interest Group.
  • Page 240 TOSHIBA portable computers. Always use Bluetooth™ Cards from TOSHIBA in order to enable wireless networks over two or more (up to a total of seven) TOSHIBA portable computers using these cards. Please contact TOSHIBA PC product support on Web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe...
  • Page 241: Bluetooth Wireless Technology And Your Health

    Because products with Bluetooth wireless technology operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Bluetooth wireless technology is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.
  • Page 242 ■ Consult the dealer or an experienced radio/TV technician for help. TOSHIBA is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this Bluetooth™ Card from TOSHIBA, or the substitution or attachment of connecting cables and equipment other than specified by TOSHIBA.
  • Page 243 The radiated output power of the Bluetooth™ Card from TOSHIBA is far below the FCC radio frequency exposure limits. Nevertheless, the Bluetooth™ Card from TOSHIBA shall be used in such a manner that the potential for human contact during normal operation is minimized. In normal operating configuration, the LCD in the upright position, the distance between the antenna and the user should not be less than 20cm.
  • Page 244: Using Bluetoothâ„¢ Card From Toshiba Equipment In Japan

    3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations. 2. Indication The indication shown below appears on this equipment.
  • Page 245: Device Authorization

    Bluetooth wireless technology Interoperability 3. TOSHIBA Direct PC Monday - Friday : 10:00-17:00 Toll Free Tel : 0120-15-1048 Direct Dial : 03-3457-4850 : 03-3457-4868 Device Authorization This device obtains the Technical Conditions Compliance Approval, and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Telecommunications Business Law.
  • Page 246 Bluetooth wireless technology Interoperability User’s Manual...
  • Page 247: Ac Power Cord And Connectors

    Appendix F AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Length: Minimum 2 meters...
  • Page 248 AC Power Cord and Connectors In Europe, two conductors power cord must be VDE type, H05VVH2-F or H03VVH2-F and for three conductors power cord must be VDE type, H05VV-F. For the United States and Canada, two pin plug configuration must be a 2-15P (250V) or 1-15P (125V) and three pin plug configuration must be 6-15P (250V) or 5-15P (125V) as designated in the U.S.
  • Page 249: Usage Restrictions

    This configuration is designed to work with a signal from a conventional (standard or analog) TV antenna. ■ TOSHIBA does not guarantee that signals received by satellite or cable TV receivers will work properly and does not provide technical support for them.
  • Page 250 Usage Restrictions User’s Manual...
  • Page 251: If Your Computer Is Stolen

    What is your address, phone, and fax number? To register the theft on paper, please follow these procedures: ■ Fill in the TOSHIBA Theft Registration form (or a copy of it) below. ■ Attach a copy of your receipt showing where your computer was purchased.
  • Page 252: Toshiba Theft Registration

    If your computer is stolen TOSHIBA Theft Registration Send to: TOSHIBA Europe GmbH Technical Service and Support Leibnizstr. 2 93055 Regensburg Germany Fax number: +49 (0) 941 7807 921 Country stolen: Machine type: (e.g. Satellite A50) Model number: (e.g. PSA50 YXT) Serial number: (e.g.
  • Page 253 Glossary The terms in this glossary cover topics related to this manual. Alternate naming is included for reference. Abbreviations AC: alternating current AGP: accelerated graphics port ANSI: American National Standards Institute APM: advanced power manager ASCII: American Standard Code for Information Interchange BIOS: basic input output system CD-ROM: Compact Disc Read Only Memory CD-RW: Compact Disc ReWritable...
  • Page 254 Glossary IrDA: Infrared Data Association IRQ: interrupt request KB: kilobyte LCD: liquid crystal display LED: light emitting diode LSI: large scale integration MB: megabyte OCR: optical character recognition (reader) PCB: printed circuit board PCI: peripheral component interconnect RAM: random access memory RGB: red, green, and blue ROM: read only memory RTC: real time clock...
  • Page 255 Glossary analog signal: A signal whose characteristics such as amplitude and frequency vary in proportion to (are an analog of) the value to be transmitted. Voice communications are analog signals. ANSI: American National Standards Institute. An organization established to adopt and define standards for a variety of technical disciplines. For example, ANSI defined the ASCII standard and other information processing requirements.
  • Page 256 Glossary buffer: The portion of the computer’s memory where data is temporarily stored. Buffers often compensate for differences in the rate of flow from one device to another. bus: An interface for transmission of signals, data or electric power. byte: The representation of a single character. A sequence of eight bits treated as a single unit;...
  • Page 257 Glossary commands: Instructions you enter at the terminal keyboard that direct the actions of the computer or its peripheral devices. communications: The means by which a computer transmits and receives data to and from another computer or device. compatibility: 1) The ability of one computer to accept and process data in the same manner as another computer without modifying the data or the media upon which it is being transferred.
  • Page 258 Glossary data bits: A data communications parameter controlling the number of bits (binary digits) used to make up a byte. If data bits = 7 the computer can generate 128 unique characters. If data bits = 8 the computer can generate 256 unique characters. DC: Direct Current.
  • Page 259 Glossary DVD-R DL: A disc having two layers on one side with the DVD-R storage capacity about 1.8 times larger than before. The DVD-RW drive uses a laser to read data from the disc. DVD-ROM: A Digital Versatile Disc Read Only Memory is a high capacity, high performance disc suitable for play back of video and other high-density files.
  • Page 260 Fn, can be used to set system parameters, such as speaker volume. HW Setup: A TOSHIBA utility that lets you set the parameters for various hardware components. icon: A small graphic image displayed on the screen or in the indicator panel.
  • Page 261 Glossary input: The data or instructions you provide to a computer, communication device or other peripheral device from the keyboard or external or internal storage devices. The data sent (or output) by the sending computer is input for the receiving computer. instruction: Statements or commands that specify how to perform a particular task.
  • Page 262 Glossary Liquid Crystal Display (LCD): Liquid crystal sealed between two sheets of glass coated with transparent conducting material. The viewing-side coating is etched into character forming segments with leads that extend to the edge of the glass. Applying a voltage between the glass sheets alters the brightness of the liquid crystal.
  • Page 263 Glossary numeric keypad overlay: A feature that allows you to use certain keys on the keyboard to perform numeric entry, or to control cursor and page movement. OCR: Optical Character Recognition (reader). A technique or device that uses laser or visible light to identify characters and input them into a storage device.
  • Page 264 The electrical connection through which the computer sends and receives data to and from devices or other computers. Power Saver Utility: A TOSHIBA utility that lets you set the parameters for various power-saving functions. printed circuit board (PCB): A hardware component of a processor to which integrated circuits and other components are attached.
  • Page 265 TFT display: A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology with thin film transistor (TFT) to drive each cell. Touch Pad: A pointing device integrated into the TOSHIBA computer palm rest. TTL: Transistor-transistor logic. A logic circuit design that uses switching transistors for gates and storage.
  • Page 266 Glossary Universal Serial Bus: This serial interface lets you communicate with several devices connected in a chain to a single port on the computer. VGA: Video Graphics Array is an industry standard video adaptor that lets you run any popular software. volatile memory: Random access memory (RAM) that stores information as long as power is supplied to the computer.
  • Page 267 ASCII characters, 5-8 brightness increase, 5-5 controller, B-1 hinges, 2-8 Battery opening, 3-9 charging, 6-9 DLA for TOSHIBA, 1-13, 4-9 extending battery life, 6-12 Documentation list, 1-3 indicator, 2-11, 6-2 DVD Super Multi drive, 1-5 Monitoring capacity, 6-10 problems, 10-8...
  • Page 268 Index HW Setup, 1-12 accessing, 7-1 Fn + Ctrl (enhanced keyboard’s Boot Priority, 7-3 simulation), 5-3 CPU, 7-5 Fn + Enter, 5-3 device config, 7-6 Fn + Esc (sound mute), 5-3 display, 7-2 Fn + F1 (instant security), 5-4 general, 7-1 Fn + F10 (Arrow mode), 5-3 keyboard, 7-5 Fn + F11 (Numeric mode), 5-3...
  • Page 269 Index temporarily using overlay (overlay off), 5-8 Password turning on the overlays, 5-7 power on, 1-11 problems, 10-7 starting the computer by, 6-15 LAN, 1-8, 4-25 supervisor, 6-15 active indicator, 2-6 user, 6-14 cable types, 4-25 PC card, 1-7, 9-2 connecting, 4-25 inserting, 9-2 disconnecting, 4-26...
  • Page 270 Sound system, 10-14 setting, 3-11 System start-up, 10-3 System automatic, 1-11 TV output signal, 10-17 USB device, 10-13 TOSHIBA PC Diagnostic Tool, 1-13 USB floppy disk drive, 10-9 TOSHIBA Power Saver, 1-12 Video Playback, 10-18 TOSHIBA support, 10-20 Wireless LAN, 10-16...
  • Page 271 Index Wireless communication, 4-21 indicator, 2-11 switch, 1-10, 2-1, 4-24 Wireless communication switch indicator, 4-24 Wireless LAN, 1-9, 4-21 problems, 10-16 xD picture card, 9-9 inserting, 9-9 removing, 9-9 User’s Manual Index-5...
  • Page 272 Index Index-6 User’s Manual...

Table of Contents
