Page 1 Series User’s Guide If you need assistance: Toshiba’s Support Web site pcsupport.toshiba.com Toshiba Global Support Centre Calling within the United States (800) 457-7777 Calling from outside the United States (949) 859-4273 For more information, see page 174 in this guide.
Page 2 TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (“TOSHIBA”), ITS AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT OPERATION OF THE PRODUCT WILL BE UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA,...
Page 3: Critical Applications
Only Peripherals complying with the FCC Class B limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer's parallel port, monitor port, USB port, PS/2 port microphone jack (Port availability depends on model selected).
Page 4: Industry Canada Requirement
This device must accept any interference received, including interference that may cause undesired operation. Contact either: Toshiba’s Support Web site at pcsupport.toshiba.com. Or call the Toshiba Global Support Centre: Within the United States at (800) 457-7777 Outside the United States at (949) 859-4273 Industry Canada Requirement This Class B digital apparatus complies with Canadian ICES-003.
Page 5: Telephone Company Procedures
If trouble is experienced with this equipment, for repair or limited warranty information, please contact Toshiba Corporation, Toshiba America Information Systems, Inc. or an authorized representative of Toshiba, or the Toshiba Support Centre within the United States at (800) 457-7777 or Outside the United States at (949) 859-4273.
Page 6: Instructions For Ic Cs-03 Certified Equipment
Alarm Equipment If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. Instructions for IC CS-03 Certified Equipment NOTICE: The Industry Canada label identifies certified equipment.
Page 7: Wireless Interoperability
Wireless Interoperability The TOSHIBA Wireless LAN Mini PCI Card products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum (DSSS) radio technology, and is compliant to: The IEEE 802.11 Standard on Wireless LANs (Revision A/B/G), as defined and approved by the Institute of Electrical and Electronics Engineers.
Page 8: Regulatory Information
The radiated output power of the TOSHIBA Wireless LAN Mini PCI Card is far below the FCC radio frequency exposure limits. Nevertheless, the TOSHIBA Wireless LAN Mini PCI Card shall be used in such a manner that the potential for human contact during normal operation is minimized. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 9: Eu Declaration Of Conformity
EU Declaration of Conformity TOSHIBA declares that this product conforms to the following Standards: This product is carrying the CE-Mark in accordance with the related European Directives. The party responsible for CE-Marking is TOSHIBA Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany.
Page 10: Modem Warning Notice
Modem Warning Notice Conformity Statement The equipment has been approved to [Commission Decision “CTR21”] for pan- European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
Page 11: Device Authorization
2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions. 3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations. 2. Indication The indication shown below appears on this equipment.
Page 12: Radio Approvals For Wireless Devices
JAPAN APPROVALS INSTITUTE FOR TELECOMMUNICATIONS EQUIPMENT Approval Number: D01-1128JP TELECOM ENGINEERING CENTER Approval Number: 03NY.A0018, 03GZDA0017 The following restrictions apply: Do not disassemble or modify the device. Do not install the embedded wireless module into other device. 5.17 GHz to 5.23 GHz for indoor use only. Radio Approvals for Wireless Devices NOTE The following information is dependent on what type of wireless device is in...
Page 13 Europe - Restrictions for use of 2.4 GHz Frequencies in European Community Countries België/ For private usage outside buildings across public grounds over less than Belgique: 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m.
Page 14 802.11a (5 GHz) Australia Canada France Ireland Luxembourg Norway Switzerland Turbo Mode (5 GHz) Canada Europe - Restrictions for Use of 5 GHz Frequencies in European Community Countries European Community Countries Austria Belgium, France, Switzerland/Lichtenstein Denmark, Finland, Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Norway, Portugal, Sweden, UK...
Page 15 This device must not be operated in ad-hoc mode using channels in the 5 GHz bands in the European Community. Ad-hoc mode provides a direct communication between two client devices without a Wireless LAN Access Point. This device must be used with Access Points that have employed and activated a radar detection feature required for European Community operation in the 5 GHz bands.
Page 16 802.11a (5 GHz) Australia Canada France Ireland Luxembourg Norway Switzerland Turbo Mode (5 GHz) Canada Approved Countries/Regions for use for the Intel Wireless LAN 2100 3B Mini PCI Adapter This equipment is approved to the radio standard by the countries/regions in the following table.
Page 17: Wireless Lan Card
Approved Countries/Regions for use for the Toshiba Mini PCI Wireless LAN Card This equipment is approved to the radio standard by the countries/regions in the following table. Do not use this equipment except in the countries/regions in the following table.
Page 18 11a, 11b, 11g and 11n wireless are based on IEEE 802.11a, 802.11b, 802.11g and 802.11n respectively. The IEEE 802.11n specification has not been finalized and is currently in draft release. The TOSHIBA 11a/b/g/n Wireless LAN Adapters are based on the Draft Release, Version 1.0, of the IEEE 802.11n specification.
Page 19: Bluetooth Wireless Technology Interoperability
Always use Bluetooth cards from TOSHIBA in order to enable wireless networks over two or more (up to a total of seven) TOSHIBA portable computers using these cards. Please contact TOSHIBA computer product support on Web site http://www.toshiba-europe.com/computers/tnt/ bluetooth.htm in Europe or pcsupport.toshiba.com in the United States for...
Page 20: Bluetooth Wireless Technology And Your Health
Approved Countries/Regions for use (Bluetooth technology) ® Bluetooth Card from Toshiba equipment is approved to the radio standard by the countries/regions in the following table. Do not use this equipment except in the countries/regions in the following table. Australia Bulgaria...
Page 21: Regulatory Statements
The radiated output power of the Bluetooth Card from TOSHIBA is far below the FCC radio frequency exposure limits. Nevertheless, the Bluetooth Card from TOSHIBA shall be used in such a manner that the potential for human contact during normal operation is minimized.
Page 22 2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions. 3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations. 2. Indication The indication shown below appears on this equipment.
Page 23 CD-RW drive, Multi-drive or any other optical drive. You could damage the drive. You would also be exposed to laser light or other safety hazards, resulting in serious injury. Always contact an authorized Toshiba service provider, if any repair or adjustment is required.
Page 24: Location Of The Required Label
Copyright This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.
Page 25: Export Administration Regulation
EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO ANY OF THE FOREGOING. TOSHIBA ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED DIRECTLY OR INDIRECTLY FROM ANY TECHNICAL OR TYPOGRAPHICAL ERRORS OR OMISSIONS CONTAINED HEREIN OR FOR DISCREPANCIES BETWEEN THE PRODUCT AND THE MANUAL.
Page 26 Card is a trademark of Fuji Photo Film, Co., Ltd. Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. Other trademarks and trade names are those of their respective owners.
Page 27: Table Of Contents
Keeping yourself comfortable ...40 Precautions...40 Important information on your computer’s Setting up your computer ...42 Setting up your software...42 Registering your computer with Toshiba ...43 Adding optional external devices...43 Connecting to a power source ...44 Charging the main battery...46 cooling fan ...41...
Page 28 Contents Using the computer for the first time ...47 Opening the display panel ...47 Your computer’s features and specifications ...48 Turning on the power ...48 Adding memory (optional) ...49 Installing a memory module ...49 Removing a memory module...55 Checking total memory ...56 Using the TouchPad™...57 Scrolling with the TouchPad™...
Page 29 Playing optical media ...100 Creating a CD/DVD/HD DVD...100 Removing a disc with the computer on...101 Removing a disc with the computer off ...101 Caring for CD or DVD discs ...101 Toshiba’s online resources ...102 keyboard ...81 ® keys ...82 ®...
Page 30 Contents Chapter 3: Mobile Computing...103 Toshiba’s energy-saver design...103 Running the computer on battery power ...103 Battery Notice ...104 Power management ...105 Using additional batteries ...105 Charging batteries...105 Charging the main battery...106 Charging the RTC battery...106 Monitoring main battery power...107 Determining remaining battery power...109 What to do when the main battery runs low ...109...
Page 31 Using a user password ...146 Deleting a user password...147 TOSHIBA Security Assist ...148 TOSHIBA PC Diagnostic Tool Utility...150 TOSHIBA HDD Protection Utility ...151 TOSHIBA SD™ Memory Card Format Utility ...152 Mouse Utility ...153 the Internet ...130 ® port ...137 Contents...
Page 32 Contents Toshiba Hardware Setup...154 TOSHIBA Zooming Utility...156 TOSHIBA Button Support...157 CD/DVD Drive Acoustic Silencer ...158 TOSHIBA Accessibility ...159 Fingerprint Authentication Utility...160 Fingerprint utility limitations ...160 Fingerprint Enrollment ...160 Fingerprint Logon ...162 Power-on Security ...162 Control Center...163 Password Bank ...165 Care and maintenance of your fingerprint Fingerprint reader limitations ...170...
Page 33 If you need further assistance...204 Before you contact Toshiba ...204 Contacting Toshiba ...204 Other Toshiba Internet Web sites...205 Toshiba’s worldwide offices...206 Appendix A: Hot Keys/TOSHIBA Cards ... 208 Hot Key Cards ...208 Using the Hot Key Cards ...209 Application Cards...210 Using the Application Cards...211 Card Case...211...
Page 34 Contents Appendix B: Power Cord/Cable Connectors...224 Glossary...225 Index...239...
Page 35: Introduction
Introduction Welcome to the world of powerful, portable, multimedia computing. With your Toshiba notebook computer, your work and entertainment can accompany you wherever you go. NOTE This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE.
Page 36: This Guide
Toshiba’ s Web site at pcsupport.toshiba.com. While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice.
Page 37: Safety Icons
Safety icons This manual contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Page 38: Other Documentation
To stay current on the most recent software and hardware options for your computer, and for other product information, be sure to regularly check the Toshiba Web site at pcsupport.toshiba.com. If you have a problem or need to contact Toshiba, see Goes Wrong” on page 174.
Page 39: Chapter 1: Getting Started
Chapter 1 Getting Started This chapter provides tips for working comfortably, summarizes how to connect components, and explains what to do the first time you use your notebook computer. Selecting a place to work Your computer is portable and designed to be used in a variety of circumstances and locations.
Page 40: Keeping Yourself Comfortable
Extreme heat, cold, or humidity. Liquids and corrosive chemicals. Keeping yourself comfortable The Toshiba Instruction Manual for Safety and Comfort, that shipped with your computer, contains helpful information for setting up your work environment and tips for working comfortably throughout the day.
Page 41: Important Information On Your Computer's Cooling Fan
Never turn off the computer if a drive light indicates a drive is active. Turning off the computer while it is reading from or writing to a disk/disc or flash media may damage the disk/disc or flash media, the drive, or both. Keep the computer and disks away from objects that generate strong magnetic fields, such as large stereo speakers.
Page 42: Setting Up Your Computer
Getting Started Setting up your computer Setting up your computer TECHNICAL NOTE: You must complete all setup steps up to and including external or internal components to your computer. These components include, but are not limited to, a mouse, keyboard, printer, memory, and PC Cards.
Page 43: Registering Your Computer With Toshiba
If you decide not to register at that time, you can either double-click the Toshiba Registration icon on your desktop or go to the Toshiba Web site at www.register.toshiba.com Product Registration will not diminish Customer rights under the Toshiba limited Warranty.
Page 44: Connecting To A Power Source
TOSHIBA Battery Charger (that may have been provided with your computer), or use AC adaptors and battery chargers specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor or Battery Charger could cause fire or damage to the computer possibly resulting in serious injury.
Page 45 To connect AC power to the computer: Connect the power cord/cable to the AC adaptor. (Sample Illustration) Connecting the power cord/cable to the AC adaptor Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.
Page 46: Charging The Main Battery
Getting Started Charging the main battery The computer’s main battery light gives you an indication of the main battery’s current charge: Glows amber while the main battery is being charged (AC adaptor connected) Glows blue when the main battery is fully charged Is unlit when the main battery has discharged, the battery is not charging, or the AC adaptor is not plugged into the computer or AC outlet...
Page 47: Using The Computer For The First Time
NOTE Battery life and charge time may vary depending on the applications, power management settings, and features used. Using the computer for the first time The computer is now ready for you to turn it on and begin using it. Opening the display panel Press the display release button.
Page 48: Your Computer's Features And Specifications
Getting Started Using the computer for the first time technology. When the computer is operated on battery power, the screen will dim and you may not be able to increase the brightness of the screen while on battery power. Your computer’s features and specifications Certain notebook chassis are designed to accommodate all possible configurations for an entire product Series.
Page 49: Adding Memory (Optional)
NOTE Before adding external devices or memory, Toshiba recommends setting up your software. See Installing a memory module Memory modules can be installed in the memory module slot on the base of the computer.
Page 50 Getting Started Adding memory (optional) Before you install or remove a memory module, turn off the computer using the Start menu. If you install or remove a memory module while the computer is in Sleep or Hibernation mode, data will be lost. NOTE For this model, Slot A is the bottom slot.
Page 51 Close the display panel and turn the computer upside down to locate the memory module slot cover. (Sample Illustration) Locating the memory module slot cover Using a small Phillips screwdriver, loosen the captive screws that secure the memory module slot cover. Front of computer (Sample Illustration) Removing the memory module slot cover Remove the memory module slot cover.
Page 52 Getting Started Adding memory (optional) Avoid touching the connector on the memory module or on the computer. Grease or dust on the connector may cause memory access problems. Carefully remove the new memory module from its antistatic packaging, without touching its connector. Locate an empty memory module slot on the underside of the computer.
Page 53 Firmly press the memory module into the memory slot’s socket at approximately a 30-degree angle (to the horizontal surface of the computer). (Sample Illustration) Inserting the memory module into the socket Once the module’s connector is fully inserted into the socket, press downward on the top edge of the module to seat the module into the latches at the sides of the socket.
Page 54 Getting Started Adding memory (optional) Slot A (Sample Illustration) Inserting the memory module into the slot NOTE For this model, Slot A is the bottom slot. Slot B is the top slot. If only one memory module is to be installed, it must be installed in Slot A. Replace the memory module slot cover and secure it using the screws.
Page 55: Removing A Memory Module
Removing a memory module If you need to remove a memory module: Complete steps page 49 to shut down the computer and open the memory module slot cover. Do not try to remove a memory module with the computer turned on. You can damage the computer and the memory module.
Page 56: Checking Total Memory
Getting Started Adding memory (optional) Gently lift the memory module to a 30-degree angle and slide it out of the slot. Front of computer (Sample Illustration) Removing the memory module Replace the memory module slot cover and secure it using the screws.
Page 57: Using The Touchpad
(complete steps and then check that the module is inserted completely into the socket and lined up squarely with the socket latches. NOTE From time to time, Windows “Windows feature to prevent programs or people from doing things on your computer without your permission.
Page 58: Control Buttons
Getting Started Using external display devices Control buttons When a step instructs you to click or choose an item, move the cursor to the item, then press and release the primary (left-hand) button. To double-click, press the primary button twice in rapid succession.
Page 59: Connecting The Display Device
S-video cables and HDMI cables are not included with your computer. For the best video quality, always use a properly shielded cable. HINT: Toshiba recommends using a cable no longer than 20 feet (approximately 6 meters). Using a poor-quality cable may result in a dull or fuzzy picture, poor color, ghosting, video noise, or loss of video.
Page 60 Getting Started Using external display devices Connecting an HDMI-compatible television or VCR/DVD player To connect an HDMI-compatible television or VCR/DVD player to the computer: Connect one end of an HDMI cable (not included with your computer) to the HDMI Out port on the back of your computer, and then connect the other end of the cable to your television.
Page 61 Connecting a standard television, projector, or VCR/DVD player To connect a standard television, projector, or VCR/DVD player: Connect one end of an S-video cable (not included with your computer) to the external video device. Refer to the documentation provided with the device for the location of its Video In port.
Page 62: Directing The Display Output When You Turn On The Computer
Getting Started Using external display devices Click and drag the Screen resolution slider to the left to select a lower screen resolution. TECHNICAL NOTE: Most televisions use or support an 800 x 600 standard resolution. Click Apply, then click OK to close the Display Settings window.
Page 63 The quickest way to change the display output settings is to use the display hot key ( Fn + F5 While holding down each press, until the setting you want takes effect. This hot key cycles through the settings in the following order: Built-in display only Built-in display and external monitor simultaneously External monitor only...
Page 64: Adjusting The Quality Of The External Display
Getting Started Using an external keyboard Adjusting the quality of the external display To obtain the best picture quality from your television (or other video display device), you may need to adjust the video settings. See the video device documentation for additional configuration steps.
Page 65: Setting Up A Printer
If your printer supports Plug and Play, your computer may automatically recognize the printer; the printer is then ready for use. Refer to your printer documentation for further instructions. TECHNICAL NOTE: To determine if your printer supports Plug and Play, check its documentation. If your printer does not support Plug and Play, you can set up the printer as described in To connect a printer to your computer:...
Page 66: Connecting An Optional External Diskette Drive
Getting Started Connecting an optional external diskette drive Connecting an optional external diskette drive Some operations, such as creating a password service diskette, require a diskette drive designed for use with 3.5-inch diskettes. (Sample Illustration) Optional external USB diskette drive To connect an optional external USB diskette drive, connect the cable to one of the computer’s USB ports.
Page 67: Options For Turning Off The Computer
Options for turning off the computer Depending on the operating system installed, you have more than one option available for turning off the computer: Shut Down, Hibernate, and Sleep. Each option has its advantages. Use the Shut Down or Hibernate command if you will not be using the computer for several days or if you must turn off your computer.
Page 68: Sleep Mode
Getting Started Turning off the computer For information on how to use and configure Hibernation mode see “Using and configuring Hibernation mode” on page Sleep mode The Sleep command places the computer into a power-saving mode. Sleep saves the current state of the computer to memory so that, when you restart the computer, you can continue working from where you left off.
Page 69: Using The Shut Down Command
Using the Shut Down command The Shut down command completely shuts down the computer without saving your work or the current state of the computer. This command closes all open programs, shuts down the operating system, and then turns off your computer. Use the following steps to turn off your computer using the Shut Down command: Click Start, and then click the arrow next to the Lock button in...
Page 70 Getting Started Turning off the computer Click Change advanced power settings. The Advanced settings tab of the Power Options window appears. (Sample Image) Advanced settings tab of Power Options screen Click Power buttons and lid to display the actions that you can configure.
Page 71: Using And Configuring Hibernation Mode
Once the computer is configured, you can turn it off by either pressing the power button or closing the display panel, depending on the options set. Restarting your computer To start the computer up again, press the power button until the on/off light glows blue.
Page 72 Getting Started Turning off the computer Click Start, Control Panel, System and Maintenance, and then Power Options. The Power Options window appears. Click Change plan settings under the power plan to be customized. The Edit Plan Settings window appears. Click Change advanced power settings. The Advanced settings tab of the Power Options window appears.
Page 73: Using And Configuring Sleep Mode
Power button action Set this option to Hibernate if you want the computer to go into Hibernation mode when you press the power button. Start menu power button Set this option to Hibernate if you want the computer to go into Hibernation mode when you click the power button in the Start menu.
Page 74 Getting Started Turning off the computer Click Sleep. The computer saves the status of all open programs and files to the memory, turns off the display, and enters into a low-power mode. The on/off light blinks amber indicating the computer is in Sleep mode.
Page 75 Click Change advanced power settings. The Advanced settings tab of the Power Options window appears. (Sample Image) Advanced settings tab of Power Options screen Click Power buttons and lid to display the actions that you can configure. Select Sleep for the options you want. NOTE These options can be set separately for how they operate while the computer is running on battery power or while connected to AC...
Page 76: Closing The Display Panel
Never use harsh or caustic chemical products to clean the computer. To keep your computer clean, gently wipe the display panel and exterior case with a lightly dampened cloth. “Power Plans” on page 116. 111. There are “Toshiba Utilities”...
Page 77: Moving The Computer
You may want to secure your computer to a heavy object such as your desk. The easiest way to do this is to purchase an optional computer lock cable. For more information on purchasing a cable lock, visit accessories.toshiba.com. (Sample Illustration) Computer lock cable To secure the computer: Wrap the cable through or around some part of a heavy object.
Page 78 Getting Started Caring for your computer Insert the cable’s locking end into the security lock slot on your computer, then engage the locking device. The computer is now securely locked. (Sample Illustration) Attaching security lock cable...
Page 79: Chapter 2: Learning The Basics
Chapter 2 Learning the Basics This chapter gives some computing tips and provides important information about basic features. Computing tips Save your work frequently. Your work stays in the computer’s temporary memory until you save it to the disk. If the network you are using goes down and you must restart your computer to reconnect, or your battery runs out of charge while you are working, you will lose all work since you last saved.
Page 80 Learning the Basics Computing tips Back up your files to disks (or other removable media) on a regular basis. Label the backup copies clearly and store them in a safe place. It is easy to put off backing up because it takes time. However, if your hard disk suddenly fails, you will lose all the data on it unless you have a separate backup copy.
Page 81: Using The Keyboard
Using the keyboard Your computer’s keyboard contains character keys, control keys, function keys, and special Windows functionality of a full-size keyboard. (Sample Illustration) Keyboard Character keys Typing with the character keys is very much like typing on a typewriter, except that: The space bar creates a space character instead of just passing over an area of the page.
Page 82: Ctrl, Fn, And Alt Keys
Learning the Basics Using the keyboard Ctrl, Fn, and Alt keys (Sample Illustration) Ctrl, Fn, and Alt keys Ctrl , and program you are using. For more information, see your program documentation. Function keys The function keys (not to be confused with the keys at the top of the keyboard.
Page 83: Overlay Keys
Overlay keys The keys with gray numbers and symbols on the front of them form the numeric and cursor overlay. This overlay lets you enter numeric data or control the cursor as you would using the 10-key keypad on a desktop computer’s keyboard. (Sample Illustration) Numeric and cursor control overlay Using the overlay to type numeric data The keys with the numbers on their right front are the numeric...
Page 84: Starting A Program
Learning the Basics Starting a program Starting a program The easiest way to start a program is to double-click the name of the file that contains the information you want to work on. To find the file, use the Start menu or Windows If you prefer to open the program first, you have four options.
Page 85: Starting A Program From Windows
Starting a program from Windows If a program is not listed in the All Programs menu, you can start it from Windows your computer’s contents as a hierarchy or “tree.” You can easily see the contents of each drive and folder on your computer. To use this method, you should know the file name and location of the program’s executable file (this file ends with .exe).
Page 86: Starting A Program Using The Start Search Field
Learning the Basics Saving your work Starting a program using the Start Search field This example uses the Start menu’s Start Search field to start WordPad: Click Start to display the Start menu. The Start Search field appears at the bottom of the Start menu. Start Search field...
Page 87 Saving files ® In your Windows Click Browse folders. If you are working with a document that already has a file name, this is all you need to do. If you created a new document, your program displays a Save As dialog box. Use this dialog box to specify where to store the document and to give it a file name.
Page 88: Printing Your Work
Learning the Basics Printing your work Using a file extension Most programs assign an extension to the file name that identifies the file as being created in the program with a particular format. For example, Microsoft file name with an extension of “.doc” is assumed to be a Microsoft Word file.
Page 89: Backing Up Your Work
Specify the print parameters. For example, the range of pages and number of copies to print. Click Print. Backing up your work Back up all the files you create in case something happens to your computer. You can back up your files to different types of media such as CDs, DVDs, diskettes, or to a network, if available.
Page 90: Using Windows Media Center In Windows Vista
Learning the Basics Using Windows® Media Center in Windows Vista™ ® Using Windows The Windows where you can play your entire library of audio, video, and picture media on your computer, using either your computer’s keyboard, mouse, or the remote control. With the Media Center, you can: Watch TV or a DVD movie Automatically record TV shows Play back your digital videos...
Page 91 Using Windows® Media Center in Windows Vista™ If you are using S-video output, you will also need to connect an audio cable (not included with your computer or system) from the TV’s audio connection to the headphone jack on the right side of your computer.
Page 92: Starting The Media Center
TV, such as a cable TV Set-top box, satellite Set-top box, VCR/DVD player, etc. This allows the Toshiba Remote Control to control the device using the Media Center. To connect the IR Blaster: Connect the IR Blaster cable (small 3.5 mm) connector to one...
Page 93: Using The Optical Drive
The first time you open Media Center, the program displays a setup NOTE wizard. You will use the wizard to test your remote control and configure your Internet connection, TV signal, Television Program Guide, and speakers. To complete the setup procedure you need to: Log on as an administrator.
Page 94: Optical Drive Components
Learning the Basics Using the optical drive NOTE For optimum HD DVD and/or DVD performance, it is recommended that you play DVDs while running the computer on AC power. Optical drive components The optical drive is located on the front of the computer. The Media control buttons are located above the keyboard and can be accessed when the display panel is open.
Page 95 TV interface, when the computer is powered on and Windows running. While Media Center is running, the TV button has the same function as the My TV button on the Toshiba Remote Control. The Media button launches Windows Media Center and plays the...
Page 96 Learning the Basics Using the optical drive ® Qosmio AV controller ® The Qosmio provides for easy navigation within Windows place of the remote control. (Sample Illustration) Qosmio The following table lists the functionality of the above buttons/regions on the controller. Button Name Right Down...
Page 97: Inserting A Compact Disc
Inserting a compact disc To insert a compact disc into the drive: Make sure the computer is turned on. The drive will not open if the computer’s power is off. Make sure the drive’s in-use indicator light is off. Press the drive’s eject button. The disc tray slides partially out of the drive (about 1 inch).
Page 98 If you insert the disc incorrectly, it may jam the drive. If this happens, contact Toshiba support for assistance. Push the disc tray in by pressing gently on the center of the tray until it clicks into place.
Page 99: Playing An Audio Cd
Playing an audio CD Insert an audio CD and close the disc tray. If the computer is turned on, Windows Media CD begins to play. You can use the Windows Media program to control the CD. To access the Windows Media Start menu.
Page 100: Playing Optical Media
These problems are not due to any defect in your Toshiba computer or optical drive. Please refer to your computer's product specification for listing of specific format compatibilities.
Page 101: Removing A Disc With The Computer On
Removing a disc with the computer on To remove a disc (CD or DVD) with the computer turned on: Press the eject button on the drive. Do not press the eject button while the in-use indicator light is glowing. Doing so could damage the disc or the drive. Also, if the disc is still spinning when you open the disc tray, wait for it to stop spinning before you remove it.
Page 102: Toshiba's Online Resources
Toshiba’s online resources Toshiba maintains a number of online sites to which you can connect. These sites provide information about Toshiba products, give help with technical questions and keep you up to date with future upgrades.
Page 103: Chapter 3: Mobile Computing
Mobile Computing This chapter covers all aspects of using your computer while traveling. Toshiba’s energy-saver design Your computer enters a low-power suspension mode when it is not being used, thereby conserving energy and saving money in the process. It has a number of other features that enhance its energy efficiency.
Page 104: Battery Notice
This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba Web site at accessories.toshiba.com. Use only batteries designed to work with your Toshiba notebook computer.
Page 105: Power Management
Never leave batteries in the battery charger for more than a week at a time. Doing so may reduce the potential charge of the battery. Always use the battery charger specified by Toshiba. You can order a Toshiba battery charger from Toshiba’s Web site at accessories.toshiba.com.
Page 106: Charging The Main Battery
Mobile Computing Charging batteries Charging the main battery To charge the main battery while it is in your computer, plug the computer into a live electrical outlet. The battery charges whether the computer is on or off. TECHNICAL NOTE: The recharging of the battery cannot occur when your computer is using all of the power provided by the AC adaptor to run applications, features, and devices.
Page 107: Monitoring Main Battery Power
NOTE The above error message may vary by computer model. The RTC battery does not charge while the computer is turned off even when the AC adaptor is charging the computer. The RTC battery charges when the computer is powered on. If the RTC battery is low, the real-time clock and calendar may display the incorrect time and date, or stop working.
Page 108 Mobile Computing Monitoring main battery power NOTE If the AC power light flashes amber during charging, either a battery pack is malfunctioning, or it is not receiving correct input from the AC power supply. Disconnect the AC power cord/cable and remove the battery pack. “Changing the main battery”...
Page 109: Determining Remaining Battery Power
Determining remaining battery power Wait at least 16 seconds after turning on the computer before trying NOTE to monitor the remaining battery power. The computer needs this time to check the battery’s remaining capacity and perform its calculations. Highlight the power icon in the Notification Area. A pop-up message displays the remaining battery power as a percentage.
Page 110: Setting Battery Notifications
Mobile Computing Monitoring main battery power Setting battery notifications You can set two notifications. Each notification can be set to alert you when a specified percentage of remaining battery power has been reached. You can also set the computer to enter Sleep mode or Hibernation mode or to completely power down when the notification goes off.
Page 111: Power Plans
How much you use the hard disk, optical drive, diskette drives, or other optional devices Where you are working, since operating time decreases at low temperatures There are various ways in which you can conserve power and extend the operating time of your battery: Enable Sleep or Hibernation, which saves power when you turn off the computer and turn it back on again Use the Windows...
Page 112: Using A Hot Key To Set The Power Plan
Mobile Computing Monitoring main battery power Select an appropriate plan for your work environment or create your own custom plan. Click Create a Power Plan to set up a new plan. To edit a plan or to edit advanced settings, continue to the following NOTE steps.
Page 113: Changing The Main Battery
While continuing to press desired Power Plan. The Power Plan options are: Balanced, Power Saver, and High Performance. Release the The hot key card disappears. You are now in the selected mode. Changing the main battery When your main battery has run out of power, you have two options: plug in the AC adaptor or install a charged main battery.
Page 114 Mobile Computing Changing the main battery Slide the battery release lock to the unlocked position. (Sample Illustration) Unlocking the battery release lock Slide the battery release latch to release the battery. Pull the discharged battery out of the computer. (Sample Illustration) Removing the battery If the battery is leaking or its case is cracked, put on protective gloves to handle it, and discard it immediately.
Page 115: Inserting A Charged Battery
Inserting a charged battery To insert a battery: Wipe the terminals of the charged battery with a clean cloth to ensure a good connection. Insert the charged battery into the slot until the latch clicks. The battery pack has been designed so that you cannot install it with reverse polarity.
Page 116: Taking Care Of Your Battery
If a battery is leaking or damaged, replace it immediately. Use protective gloves when handling a damaged battery. To replace the main battery, use an identical battery that you can purchase through the Toshiba Web site at accessories.toshiba.com. A reverse polarity condition should be avoided with all batteries.
Page 117: Maintaining Your Battery
Maintaining your battery Fully discharging your battery pack will allow better accuracy of the battery meter. To fully discharge your battery pack: Periodically, disconnect the computer from a power source and operate it on battery power until the battery pack fully discharges.
Page 118 If you cannot find the information you need elsewhere, call Toshiba at: (800) 457-7777. Toshiba is dedicated to preserving the environment by sponsoring Call2Recycle™, a program of the Rechargeable Battery Recycling...
Page 119: Traveling Tips
Never leave your computer on a sunny ledge or in a place where it could get wet or covered in dust. Always travel with the computer in a carrying case. Toshiba offers a choice of carrying cases for the computer. They all provide plenty of extra space for manuals, power cords, and compact discs.
Page 120: Chapter 4: Exploring Your Computer's Features
Chapter 4 Exploring Your Computer’s Features In this chapter, you will explore some of the special features of your notebook computer. Exploring the desktop The desktop is the launching pad for everything you can do in the ® Windows operating system. You use its features to start programs, find documents, set up system components, and perform most other computing tasks.
Page 121: Finding Your Way Around The Desktop
Finding your way around the desktop Your computer’s desktop includes several standard features: icons, Start button, Taskbar, Notification Area, and background pattern. Icons Start button (Sample Image) Windows Icons An icon represents a folder, file, or program that can be quickly activated by double-clicking the icon.
Page 122 Exploring Your Computer’s Features Exploring the desktop NOTE If you place the cursor over an icon, a popup description of the file contents appears. Your desktop may contain other icons depending on your configuration. See Windows information on each icon and how to use it. Start button You use the Start button to: Start programs...
Page 123: Setting Up For Communications
Setting up for communications To connect to the Internet, use an online service, or communicate across the telephone lines with another computer, you need: A modem (available on certain models) A telephone line A browser or communications program An Internet Service Provider (ISP) or online service if you plan to use the Internet Determining the COM port Your modem (available on certain models) is connected to one of...
Page 124: Connecting A Modem To A Telephone Line
Send a fax directly from your computer For more detailed information regarding your computer’s modem, visit Toshiba’s Web site at accessories.toshiba.com. Before you can communicate using the modem, you need to connect it to a telephone line. Your computer’s built-in modem port provides an RJ-11 jack, allowing you to connect the modem to a standard voice-grade telephone line.
Page 125: Connecting Your Computer To A Network
Connect the other end to the RJ-11 wall jack. (Sample Illustration) Connecting to a wall jack NOTE Connect the built-in modem only to ordinary analog phone lines. Never connect the built-in modem to a digital line (ISDN). Never connect the built-in modem to the digital connector on a public telephone or to a digital private branch exchange (PBX).
Page 126 Exploring Your Computer’s Features Setting up for communications Setting up the connection To set up an office connection, consult your network administrator for network settings and additional considerations. To set up a dial-up connection, use the Connect to the Internet Wizard: Click Start, Control Panel, Network and Internet, and then Connect to the Internet.
Page 127: An Overview Of Using The Internet
Using Wireless LAN connectivity NOTE Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access points may be limited. Your system may come with an optional wireless LAN module. This is a technology that expands wireless communication beyond networking equipment, and can connect many different kinds of electronic devices without the need for cables.
Page 128: The World Wide Web
Exploring Your Computer’s Features An overview of using the Internet The World Wide Web The World Wide Web (or “Web”) is a subset of the Internet—a collection of interlinked documents (located on computers connected to the Internet) that work together using a specific Internet protocol called Hypertext Transfer Protocol (HTTP).
Page 129: Surfing The Internet
Surfing the Internet Once connected to the Internet, the Web browser displays a home page, for example, your ISP’s home page on the Internet or your company’s Web site home page. To visit a desired Web site, type in the Web address. The Web address, or Uniform Resource Locator (URL), is a unique identifier for that computer system linked to the Internet.
Page 130: Uploading To, And Downloading Files From, The Internet
Exploring Your Computer’s Features Exploring audio features Uploading to, and downloading files from, the Internet Transferring files from one computer to another is termed uploading (transferring data from your computer to a site on the Web), or downloading (transferring data from a site on the Web to your computer).
Page 131: Using External Speakers Or Headphones
Using external speakers or headphones Your computer is equipped with a full stereo sound system with internal speakers. Instead of using the internal speakers, you can connect headphones or a pair of external stereo speakers. Before putting on headphones to listen, turn the volume down. Do not set the volume too high when using headphones.
Page 132: Using Pc Cards
Exploring Your Computer’s Features Using PC Cards Using PC Cards TECHNICAL NOTE: For PCMCIA-compatible PC Cards, check the package to make sure they conform to the PCMCIA 2.1 standard (or later). Other cards may work with your computer, but are likely to be much more difficult to set up and use.
Page 133: Removing A Pc Card
Removing a PC Card Be sure to disable the PC Card prior to removing it. Otherwise, the system may be damaged. NOTE Before removing a PC Card, make sure that no applications or system services are using the card. Prepare the card for removal by clicking the Safely Remove Hardware icon in the Notification Area and then selecting the card or device you want to remove.
Page 134: Using An Expresscard
Exploring Your Computer’s Features Using an ExpressCard™ Using an ExpressCard The ExpressCard slot also supports hot swapping, which allows you to replace one ExpressCard with another while the computer is on. Inserting an ExpressCard Before you insert an ExpressCard comes with the card to see if you need to do anything before you insert it.
Page 135: Using The Bridge Media Adapter Slot
PDAs, digital cameras, digital video camcorders, etc. The Bridge Media Adapter slot may also support other types of media. For a complete list of supported media, visit Toshiba’s Web site at accessories.toshiba.com. NOTE Do not use the Copy Disk function for this type of media. To copy...
Page 136: Removing Memory Media
Exploring Your Computer’s Features Using the Bridge Media Adapter Slot Push the media into the adapter until it locks in place. (Sample Illustration) Inserting memory media When inserting memory media, do not touch the metal contacts. You could expose the storage area to static electricity, which can destroy data.
Page 137: Using The I.link ® Port
Exploring Your Computer’s Features ® Using the i.LINK port ® Using the i.LINK port ® The i.LINK port on the side of the computer provides an extremely fast data transfer rate. ® In addition to high speed, the i.LINK port also supports isochronous data transfer (the delivery of data at a guaranteed rate).
Page 138: Chapter 5: Toshiba Utilities
TOSHIBA Assist Supervisor password User password TOSHIBA Security Assist TOSHIBA PC Diagnostic Tool Utility TOSHIBA HDD Protection Utility TOSHIBA SD™ Memory Card Format Utility Mouse Utility Toshiba Hardware Setup TOSHIBA Zooming Utility TOSHIBA Button Support CD/DVD Drive Acoustic Silencer TOSHIBA Accessibility Fingerprint Authentication Utility ConfigFree™...
Page 139: Toshiba Assist
TOSHIBA Assist The TOSHIBA Assist provides quick access to computer functions and allows you to customize a range of computer settings. To access TOSHIBA Assist, do one of the following: Double-click the TOSHIBA Assist shortcut icon on the desktop. Click Start, All Programs, Toshiba, Utilities, and then TOSHIBA Assist.
Page 140: Connect
Toshiba Utilities TOSHIBA Assist Connect The features available in this category are: ConfigFree™ Bluetooth Bluetooth (Sample Image) TOSHIBA Assist window – Connect tab Connectivity Doctor ® Settings ® Local COM Settings...
Page 141: Secure
Secure The features available in this category are: Supervisor password User password (Sample Image) TOSHIBA Assist window – Secure tab Toshiba Utilities TOSHIBA Assist...
Page 142: Protect & Fix
Toshiba Utilities TOSHIBA Assist Protect & Fix The features available in this category are: TOSHIBA PC Diagnostic Tool Utility (Sample Image) TOSHIBA Assist window – Protect & Fix tab...
Page 143: Optimize
Optimize The features available in this category are: Mouse Utility TOSHIBA Accessibility TOSHIBA Zooming Utility TOSHIBA Button Support CD/DVD Drive Acoustic Silencer Toshiba Hardware Setup (Sample Image) TOSHIBA Assist window – Optimize tab Toshiba Utilities TOSHIBA Assist...
Page 144: Setting Passwords
When you set a password, you must enter the password before you can work on your computer again. Toshiba supports several types of passwords on your computer: An instant password—Secures your open programs and files when leaving the computer temporarily.
Page 145: Using A Supervisor Password
Toshiba is not responsible for any losses that may occur to you, your organization or others as a result of the inability to access your computer.
Page 146: Using A User Password
Toshiba is not responsible for any losses that may occur to you, your organization or others as a result of the inability to access your...
Page 147: Deleting A User Password
To register a password for the power-on password functions: Click Start, All Programs, Toshiba, Utilities, and then TOSHIBA Password Utility. The TOSHIBA Password Utility window appears. (Sample Image) TOSHIBA Password Utility window Click Set. Enter your password, and then enter it again to verify.
Page 148: Toshiba Security Assist
TOSHIBA Security Assist TOSHIBA Security Assist The TOSHIBA Security Assist Utility acts as a “command center” where you can set up various passwords or other security features, and see how these features can be used with each other to increase security even further, or to simplify the ways that you protect your system.
Page 149 Advanced—Select this category to check advanced security options (available on certain models). Wireless Key Logon: Configure your computer to allow a ® Bluetooth -compatible cell phone to send an unlock code. Toshiba Utilities TOSHIBA Security Assist ® accounts on this ® account password, ® screen saver.
Page 150: Toshiba Pc Diagnostic Tool Utility
Refer to the online Help documentation within the application for additional help. NOTE The TOSHIBA PC Diagnostic Tool utility may show tests for features you do not have. This is normal and does not indicate a problem. To use the TOSHIBA PC Diagnostic Tool utility:...
Page 151: Toshiba Hdd Protection Utility
TOSHIBA HDD Protection Utility The TOSHIBA HDD Protection utility controls your computer’s hard disk drive (HDD) protection feature, which parks the HDD whenever motion is detected on the computer. Using this utility, you can enable or disable hard disk drive (HDD) protection, and set the motion detector’s sensitivity level for AC power and battery...
Page 152: Toshiba Sd™ Memory Card Format Utility
This utility is used to format SD Adapter slot. To format an SD memory card using this utility: Click Start, All Programs, Toshiba, Utilities, and then SD Memory Card Format. The TOSHIBA SD Memory Card Format screen appears. (Sample Image) TOSHIBA SD Memory Card Format screen Select the drive corresponding to the SD memory card.
Page 153: Mouse Utility
The settings you can change are divided into these categories: Buttons Pointers Pointer options Wheel Hardware Device Settings You may see additional categories depending on your particular pointing device. Adjust the settings as desired, then click OK. Assist. Toshiba Utilities Mouse Utility...
Page 154: Toshiba Hardware Setup
Toshiba Hardware Setup is the Toshiba configuration management tool available through the Windows Click Start, All Programs, Toshiba, Utilities, and then HWSetup, or click the Toshiba Hardware Setup icon in the Optimize tab of The Toshiba Hardware Setup screen appears.
Page 155 Apply, you can reconfigure that function. Any options that you change will become default settings when you restart your system. Toshiba Utilities Toshiba Hardware Setup key. Enter function key and access the wake-on keyboard key, or the right or...
Page 156: Toshiba Zooming Utility
Adobe Acrobat Icons on the desktop To access the TOSHIBA Zooming Utility: Click Start, All Programs, Toshiba, Utilities, and then TOSHIBA Zooming Utility. The TOSHIBA Zooming Utility Properties screen appears. (Sample Image) TOSHIBA Zooming Utility Properties screen Select the desired option(s).
Page 157: Toshiba Button Support
For more information about how to use the TOSHIBA Zooming utility, right-click the click Help. Click OK. TOSHIBA Button Support TOSHIBA Button Support allows you to customize the TV button. This button is located above the keyboard. To access TOSHIBA Button Support:...
Page 158: Cd/Dvd Drive Acoustic Silencer
Toshiba Utilities CD/DVD Drive Acoustic Silencer CD/DVD Drive Acoustic Silencer This utility can slow the speed of your optical drive to make it run more quietly. You can use this utility to make listening to music CDs more enjoyable. NOTE When you change the optical drive to “Quiet”...
Page 159: Toshiba Accessibility
TOSHIBA Accessibility The TOSHIBA Accessibility utility allows you to use the create a hot key combination with one of the function keys without pressing the two keys simultaneously as is usually required. Using Accessibility lets you make the press it once, release it, and then press a function key to activate the hot key function.
Page 160: Fingerprint Authentication Utility
Toshiba does not guarantee that the fingerprint utility will accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of the fingerprint software or utility.
Page 161 Error reading fingerprint—the movement was too fast. Swipe your finger again at a slower speed. Error reading fingerprint—the movement was too short. Swipe your finger again using a longer motion. Toshiba Utilities Fingerprint Authentication Utility ® password, you will be prompted to...
Page 162: Fingerprint Logon
Toshiba Utilities Fingerprint Authentication Utility Fingerprint Logon The fingerprint utility enables logon to your computer using fingerprints. During user enrollment, fingerprint samples are saved and associated with the user’s Windows user attempts to log on again, the user’s fingerprint is read and compared with the user’s enrolled fingerprints;...
Page 163: Control Center
The Control Center contains various functions for fingerprint management and for setting up your fingerprint software. Available options depend on the software status, used hardware, and installed applications. (Sample Image) Main Fingerprint Control Center Window Toshiba Utilities Fingerprint Authentication Utility...
Page 164 Toshiba Utilities Fingerprint Authentication Utility Fingerprints Enroll or edit current user’s fingerprint templates—Runs the fingerprint enrollment wizard. You can enroll, edit, or delete fingerprints for the current user and, if power-on security is implemented, control whether they are stored in the fingerprint device memory.
Page 165: Password Bank
Web browser, click it in the list. Register—Registers a new window (dialog or Web page). Lock/unlock My Safe—Opens or closes My Safe folder. Control Center—Displays Control Center. Help—Displays this help file. Toshiba Utilities Fingerprint Authentication Utility Shift key while swiping your finger.
Page 166 Toshiba Utilities Fingerprint Authentication Utility Registering a new Web page or dialog You are logged on to the computer and want to register a new Web page. To create a new registration: Display a Web page you want to register.
Page 167 Deleting a registration You are logged on to the computer and want to delete an existing registration. To delete an existing registration: Click the Settings topic in the Control Center. Click User Settings. Verify your fingerprint. Toshiba Utilities...
Page 168: Care And Maintenance Of Your Fingerprint Reader
Select a registration. Click Delete. How to Delete the Fingerprint Data Fingerprint data is stored in the non-volatile memory. If the computer changes ownership, Toshiba recommends the following procedure: Click Start, All Programs, Protector Suite QL, and then Control Center.
Page 169 The fingerprint for each finger is different and unique. Please ensure that only the registered or enrolled fingerprint or fingerprints are used for identification. Check sliding position (see illustration below). (Sample Illustration) Aligning the finger on the reader Toshiba Utilities...
Page 170: Fingerprint Reader Limitations
Toshiba does not guarantee that the fingerprint reader will recognize the enrolled user or accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of this fingerprint recognition software or utility.
Page 171: Getting Started
Click Start, All Programs, Toshiba, Networking, and then ConfigFree. Double-click the ConfigFree icon Press the TOSHIBA Assist button (if applicable to your system) to open the TOSHIBA Assist, and then click the ConfigFree icon. Click the ConfigFree icon then click the desired utility. NOTE If your computer is not connected to a network, the ConfigFree icon in the Notification Area is displayed with an “X.”...
Page 172 Toshiba Utilities ConfigFree™ Status of Wireless Connection switch (Sample Image) Connectivity Doctor screen Profile Settings The Profile Settings utility lets you save network settings in “profiles.” ConfigFree profiles are useful for easily switching network settings and devices.You can switch network settings simply by selecting the profile with the desired settings.
Page 173 To create a profile: Click the icon in the Notification Area. Move the pointer to Profile. Click Open Settings. The ConfigFree Profile Settings window appears. (Sample Image) ConfigFree Profile Settings window Click Add to start the Create Profile Wizard. Toshiba Utilities ConfigFree™...
Page 174: Chapter 6: If Something Goes Wrong
This chapter aims to help you solve many problems by yourself. It covers the problems you are most likely to encounter. If all else fails, contact Toshiba. You will find information on Toshiba’s support services at the end of this chapter.
Page 175: Problems When You Turn On The Computer
Click the Applications tab. If a program has stopped responding, the words “not responding” appear beside its name in the list. Select the program you want to close, then click End Task. Closing the failed program should allow you to continue working.
Page 176 If Something Goes Wrong Problems when you turn on the computer If you are using an AC adaptor, verify that the computer is receiving power from the external power source by looking at the AC power light. If the indicator is glowing, the computer is connected to a live external power source.
Page 177 Try turning the computer on again. If the computer starts normally, the AC adaptor may be defective and will need to be replaced (see the Toshiba Web site at accessories.toshiba.com). If the AC power light starts flashing, remove the battery, and continue with the steps below.
Page 178: The Windows Operating System Is Not Working
If Something Goes Wrong The Windows Verify that the AC adaptor is the correct unit for your computer model. The computer may not be able to start from an AC adaptor that is rated for less current (amperage) than the computer requires, even if the rated voltage is correct, and the plug fits correctly in the DC-IN socket.
Page 179: Internet Problems
The Windows Safe Mode with Command Prompt Enable Boot Logging Enable low-resolution video (640x480) Last Known Good Configuration (advanced) Directory Services Restore Mode Debugging Mode Disable automatic restart on system failure Disable Driver Signature Enforcement Start Windows When you highlight each option using the arrow keys, Windows displays information about each option at the bottom after Description.
Page 180: The Windows Operating System Can Help You
Click one of the options listed in the window and then follow the on-screen instructions. You can connect to Support Online by clicking Microsoft Customer Support or by going to Toshiba support at pcsupport.toshiba.com. Resolving a hardware conflict If you receive an error message telling you there is a device driver conflict or a general hardware problem, try using Windows and Support to troubleshoot the problem first.
Page 181: Fixing A Problem With Device Manager
The device most recently connected to the system is the one most likely to be causing a conflict. Resolving conflicts There are several things you can do to resolve hardware conflicts: Get the most recent drivers from the manufacturer. Disable the device. For an older device, remove it from the computer.
Page 182: Memory Problems
If Something Goes Wrong Resolving a hardware conflict The Resources tab, which lists resources assigned to the monitor, optional external optical drive, optional external diskette drive, and other power-using functions. This tab does not appear if the device is not using resources. The Driver tab, which displays the drivers being used by the device.
Page 183: Power And The Batteries
NOTE For this model, Slot A is the bottom slot. Slot B is the top slot. If only one memory module is to be installed, it must be installed in Slot A. Power and the batteries Your computer receives its power through the AC adaptor and power cord/cable or from the system batteries (battery, optional secondary battery, and real-time clock (RTC) battery).
Page 184: Keyboard Problems
After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see your accessories information that shipped with your computer, or visit the Toshiba Web site at accessories.toshiba.com.
Page 185: Display Problems
Click Start, and then click the arrow next to the Lock button in the lower-right part of the Start menu. The Shut Down menu appears. Click Restart. The computer will restart and recognize the device. Display problems Here are some typical display problems and their solutions: The screen is blank.
Page 186 If Something Goes Wrong Resolving a hardware conflict The screen does not look right. You can change the display settings by clicking a blank area of the desktop with the secondary control button, then clicking Personalize. This opens the Personalization window. Click Windows Color and Appearance to choose the colors for the screen.
Page 187: Disk Drive Problems
the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology. When the computer is operated on battery power, the screen will dim and you may not be able to increase the brightness of the screen while on battery power.
Page 188: Optical Drive Problems
If Something Goes Wrong Resolving a hardware conflict Your hard disk seems very slow. If you have been using your computer for a long time, your files may have become fragmented. Run Disk Defragmenter. To do this, click Start, All Programs, Accessories, System Tools, and then Disk Defragmenter.
Page 189 Open the tray and remove the disc. Make sure the tray is clean. Any dirt or foreign object can interfere with the laser beam. Examine the disc to see if it is dirty. If necessary, wipe it with a clean cloth dipped in water or a neutral cleaner. Replace the disc in the tray.
Page 190: Sound System Problems
If Something Goes Wrong Resolving a hardware conflict Sound system problems No sound is coming from the computer’s speakers. Adjust the volume control. Try pressing Fn + Esc Check that the volume control on the computer is turned up. If you are using external headphones or speakers, check that they are securely connected to your computer.
Page 191 Resolving PC Card problems Here are some common problems and their solutions: The slot appears to be dead. PC Cards that used to work no longer work. Check the PC Card status: Click Start, Control Panel, System and Maintenance, and then Device Manager.
Page 192 If Something Goes Wrong Resolving a hardware conflict The system does not recognize your PC Card. Refer to the PC Card documentation. Removing a malfunctioning card and reinstalling it can correct many problems. A PC Card error occurs. Reinsert the card to make sure it is properly connected. If the card is attached to an external device, check that the connection is secure.
Page 193: Express Card Tm Problems
Resolving Express Card Here are some common problems and their solutions: The slot appears to be dead. Express Cards that used to work no longer work. Check the Express Card status: Click Start, Control Panel, System and Maintenance, and then Device Manager. Double-click the PCMCIA adapter.
Page 194: Printer Problems
If Something Goes Wrong Resolving a hardware conflict The system does not recognize your Express Card. Refer to the Express Card documentation. Removing a malfunctioning card and reinstalling it can correct many problems. An Express Card error occurs. Reinsert the card to make sure it is properly connected. If the card is attached to an external device, check that the connection is secure.
Page 195: Modem Problems
The other system may be busy or off line. Try making a test transmission to someone else. For more information regarding your system’s V.92 modem, visit the Toshiba Web site at pcsupport.toshiba.com. Wireless networking problems This section provides general troubleshooting tips for networking...
Page 196 If Something Goes Wrong Resolving a hardware conflict NOTE To determine if your computer has an internal Wi-Fi the device list in Device Manager (part of the Windows Panel, Hardware and Sound). Some Toshiba models may have a ® Wi-Fi ® Wi-Fi...
Page 197 Enter IPCONFIG /ALL The IP address for each active network adapter will be displayed. Connect your computer directly to your router or broadband modem, by plugging a standard CAT5 Ethernet patch cable (sold separately) into your computer's RJ45 Ethernet port. If your connection problem disappears, the problem lies in the ®...
Page 198: Dvd Operating Problems
“Checking device properties” on page 181 on using Device Manager to view the optical drive properties. Check the Toshiba Web site for new information on optical drives and their operation. A blank screen appears while watching a DVD-ROM movie or title.
Page 199: Develop Good Computing Habits
Click Save changes. The screen saver runs while you are watching a movie or title. If the screen saver is enabled, it runs on top of any movie or title you are watching. To disable the screen saver: Right-click on the desktop and click Personalize in the menu. Select None for the screen saver.
Page 200: Data And System Configuration Backup In The Windows
If Something Goes Wrong Develop good computing habits Read the user’s guides. It is very difficult to provide a fail-safe set of steps you can follow every time you experience a problem with the computer. Your ability to solve problems will improve as you learn about how the computer and its software work together.
Page 201 In the input field, enter a name that is descriptive enough to be easily understood in the future, such as “Before installing Brand X Accounting app.” Then click Create. The Windows automatically stamps it with the current date and time, and displays a message that the restore point was successfully created.
Page 202 DVDs, or hard drives. An external hard drive is recommended in case the internal hard drive fails. No additional software is required. Most of the CD and DVD drives built into recent Toshiba portable computer models can write to (or ‘burn’) as well as read from CDs.
Page 203 then be able to easily restore the Windows the state it was in prior to the installation, undoing any changes that the installation process introduced. Back up your critical data (see entire computer with the Windows® operating system” on page 201).
Page 204: If You Need Further Assistance
Go to the Tech Support Center, select your particular model from the list and go to the Detailed Specifications for that model. For the number of a Toshiba dealer near you in the United States, call: (800) 457-7777. Contacting Toshiba If you still need help and suspect that the problem is hardware- related, Toshiba offers a variety of resources to help you.
Page 205: Other Toshiba Internet Web Sites
Information about what you were doing when the problem occurred Exact error messages and when they occurred For technical support, call the Toshiba Global Support Centre: Within the United States at (800) 457-7777 Outside the United States at (949) 859-4273 Other Toshiba Internet Web sites toshiba.com...
Page 206: Toshiba's Worldwide Offices
Germany Japan Toshiba Corporation, PCO-IO 1-1, Shibaura 1-Chome Minato-Ku, Tokyo, 105-8001 Japan Mexico Toshiba de México S.A. de C.V. Sierra Candela No.111, 6to. Piso Col. Lomas de Chapultepec. CP 11000 Mexico, DF. United Kingdom Toshiba Information Systems (U.K) Ltd. Toshiba Court...
Page 207 United States Toshiba America Information Systems, Inc. 9740 Irvine Boulevard Irvine, California 92618 United States For more information on additional Toshiba worldwide locations, please visit: www.toshiba.co.jp/index.htm. If Something Goes Wrong Toshiba’s worldwide offices The Rest of Europe Toshiba Europe (I.E.) GmbH...
Page 208: Appendix A: Hot Keys/Toshiba Cards
Appendix A Hot Keys/TOSHIBA Cards Hot keys and TOSHIBA Cards provide a quick way to modify selected system functions and to launch applications. There are two types of TOSHIBA Cards: Hot Key Cards and Application Cards. Hot Key Cards The Hot Key Cards are used to modify the following system...
Page 209: Using The Hot Key Cards
To use the Hot Key Cards using the pointing device: Move the cursor to the top center edge of the screen. The TOSHIBA Cards appear along the top of the screen. (Sample Image) Hot Key Card display Double-click the Card for the system function to be modified.
Page 210: Application Cards
170. Bluetooth settings This Application Card launches your Bluetooth settings. Disc Creator utility This Application Card launches the TOSHIBA Disc Creator utility. Toshiba Hardware Setup utility For more information, refer to Hardware Setup” on page TOSHIBA Button Support utility For more information, refer to Support”...
Page 211: Using The Application Cards
211). To use the Card Case: Move the cursor to the top center edge of the screen. The TOSHIBA Cards appear at the top of the screen. An icon appears momentarily in the top-right corner. Click the (Sample Image) Starting Card Case...
Page 212: Hot Key Functions
Hot Keys/TOSHIBA Cards Hot key functions The Card Case displays two rows of Cards. Cards that appear solid (not transparent) in the top row are enabled and can be selected when the Application Cards are displayed. The top row contains all of the disabled cards.
Page 213: Volume Mute
Volume Mute This TOSHIBA Card or hot key enables/disables volume mute on your computer. When volume mute is enabled, no sound will come from the speakers or headphones. Selecting this Card or pressing the hot key displays the following options:...
Page 214: Password Security
Hot Keys/TOSHIBA Cards Hot key functions Password security This TOSHIBA Card or hot key blanks the display. Selecting this Card or pressing the hot key displays the following options: (Sample Image) Security options hot key function activates instant security. The user...
Page 215: Power Plan
Hot Keys/TOSHIBA Cards Hot key functions Power plan This TOSHIBA Card or hot key displays the power plans and cycles through the power plans. The properties of each power plan, and the power plans that are displayed by this function, are set in the Power Options window.
Page 216: Sleep Mode
Hot Keys/TOSHIBA Cards Hot key functions Sleep mode This TOSHIBA Card or hot key places the computer into Sleep mode. For more information about Sleep mode, please see and configuring Sleep mode” on page Selecting this Card or pressing the hot key displays the...
Page 217: Hibernation Mode
Hibernation mode This TOSHIBA Card or hot key places the computer into Hibernation mode. If Hibernation mode is disabled, this hot key will not respond. For more information on Hibernation mode, see “Using and configuring Hibernation mode” on page Selecting this Card or pressing the hot key displays the...
Page 218: Display Modes
Hot Keys/TOSHIBA Cards Hot key functions Display modes This TOSHIBA Card or hot key cycles through the power- on display options. The display modes are: To use a simultaneous mode, you must set the resolution of the internal display panel to match the resolution of the external display device.
Page 219: Display Brightness
Display brightness This TOSHIBA Card decreases or increases the screen brightness. This hot key decreases the screen brightness. This hot key increases the screen brightness. Selecting this Card or pressing either hot key displays the following options: (Sample Image) Display brightness Move the slider or press the appropriate hot key repeatedly to decrease or increase the display brightness.
Page 220: Disabling Or Enabling Wireless Devices
Hot Keys/TOSHIBA Cards Hot key functions Disabling or enabling wireless devices This TOSHIBA Card or hot key enables/disables the optional wireless devices installed in your computer. The wireless modes are: Selecting this Card or pressing the hot key displays the...
Page 221: Disabling Or Enabling The Touchpad
Disabling or enabling the TouchPad This TOSHIBA Card or hot key enables/disables the TouchPad. For more information on using the TouchPad, see the TouchPad™” on page Selecting this Card or pressing the hot key displays the following options: (Sample Image) Disable or Enable TouchPad options...
Page 222: Changing Screen Resolution
Hot Keys/TOSHIBA Cards Hot key functions Changing screen resolution This TOSHIBA Card or hot key switches screen resolution. Selecting this Card or pressing the hot key displays the following options: [Space bar] (Sample Image) Screen resolution options Cycle through the screen resolutions, then select the desired...
Page 223: Keyboard Hot Key Functions
This hot key turns the numeric overlay on and off. This hot key turns the scroll lock feature on and off. This hot key turns the Zooming utility to zoom-out. This hot key turns the Zooming utility to zoom-in. Hot Keys/TOSHIBA Cards Hot key functions...
Page 224 Appendix B Power Cord/Cable Connectors Your notebook computer features a universal power supply you can use worldwide. This appendix shows the shapes of the typical AC power cord/cable connectors for various parts of the world. USA and Canada UL approved CSA approved Australia AS approved...
Page 225 Glossary TECHNICAL NOTE: Some features defined in this glossary may not be available on your computer. Acronyms The following acronyms may appear in this user’s guide. BIOS CD-ROM CD-RW CMOS COM1 COM2 DIMM alternating current basic input/output system bits per second compact disc compact disc read-only memory compact disc rewrite memory...
Page 226 Glossary DSTN DVD-ROM digital versatile (or video) disc read-only memory EPROM HTML IEEE LPT1 MIDI PCMCIA SCSI disk operating system dots per inch dual supertwist nematic digital versatile (or video) disc enhanced capabilities port erasable programmable read-only memory file allocation table Federal Communications Commission gigabyte hard disk drive...
Page 227 SDRAM SRAM SVGA Terms The following terms may appear in this user’s guide. active-matrix display — A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology. Also known as a “TFT display,” in its simplest form there is one thin film transistor (TFT) for each cell.
Page 228 Glossary baud rate — The speed at which a communication device, such as a printer or modem, transmits information. Baud rate is the number of signal changes per second (not necessarily the same as bits per second). See also bits per second. BIOS (basic input/output system) —...
Page 229 central processing unit (CPU) — The chip that functions as the “brain” of the computer. It takes information from outside sources, such as memory or keyboard input, processes the information, and sends the results to another device that uses the information. character —...
Page 230 Glossary device — A component attached to the computer. Devices may be external (outside the computer’s case) or internal (inside the computer’s case). Printers, disk drives, and modems are examples of devices. device driver — A program (called a “driver”) that permits a computer to communicate with a device.
Page 231 double-density diskette — A 3.5-inch diskette that can hold up to 720 KB of information (half the capacity of a high-density diskette). See also diskette, high-density diskette. download — (1) In communications, to receive a file from another computer through a modem or network. (2) To send font data from the computer to a printer.
Page 232 — The physical components of a computer system. Compare software. Hibernation — A feature of many Toshiba notebook computers that saves to the hard disk the current state of your work, including all open files and programs, when you turn the computer off. When you turn on the computer again, your work is returned to the same state it was when the computer was turned off.
Page 233 hot key — (1) A feature in which certain keys in combination with the key can set system options or control system parameters, such as the battery save mode. (2) A key or combination of keys that activates a memory resident program. hot swapping —...
Page 234 Glossary local area network — See LAN. logical drive — A section of a disk that is recognized by the operating system as a separate disk drive. A system’s logical drives may differ from its physical drives. For example, a single hard disk drive may be partitioned into two or more logical drives.
Page 235 non-system disk — A disk for storing programs and data that cannot be used to start the computer. Compare system disk. online — Available through the computer. Online may refer to information being read from your own computer’s hard disk, such as online documentation or online Help, or to information coming from another company on a company network or the Internet.
Page 236 Glossary port — A socket on the computer where you plug in a cable for connection to a network or a peripheral device. processor — See central processing unit (CPU). program — A set of instructions that can be executed by a computer. The general classes of programs (also called software) are operating system, application, and utility.
Page 237 select — To highlight or otherwise specify text, data, or graphics with the intent to perform some operation on it. serial — Processes that occur one at a time. In communications, it means the transmission of one bit at a time sequentially over a single channel.
Page 238 Glossary Web — See World Wide Web. ® Wi-Fi — A registered trademark term of the Wi-Fi Alliance that stands for Wireless Fidelity, and is another term for the communication protocol to permit an Ethernet connection using wireless communication components. World Wide Web (www) —...
Page 239 183 notification 110 power plan 215 power plan hot key 112 real-time clock (RTC) 104 removing 113 BIOS Setup see Toshiba Hardware Setup Bridge Media Adapter inserting memory media 135 removing memory media 136 button power 48 start 122...
Page 240 Index set up 123 compact disc positioning 98 compact discs handling 98 inserting 97 removing 101 compact disk drive using 93 computer caring for 76 cleaning 76 moving 77 non-system disk or disk error message 177 not accessing disk drives 176 running on battery power 103 setting up 42 warning resume failure message...
Page 241 external monitor not working 186 mouse 64 external diskette drive connecting 66 external display adjusting the picture quality 64 FAT (File Allocation Table) 187 file extensions 88 file, backing up 80 files backing up 89 printing 88 restoring 89 saving 86 fingerprint authentication 160 enrollment 160...
Page 242 Index hot keys 223 not working 176 overlay keys 83 special Windows® keys 82 troubleshooting 184 using 81 keyboard, external 64 keyboard, full-size 81 lock computer, using 77 main battery removing 113 memory adding 49 problem solving 182 removing expansion slot cover 51 memory module inserting 52 installation 49...
Page 243 186 checking device properties 181 computer hangs when PC Card inserted 191 computer will not power up 175 contacting Toshiba 204 corrupted/damaged data files 188 Device Manager 181 disk drive is slow 188 display is blank 185...
Page 244 124 television connecting 59 Toshiba registering computer 43 worldwide offices 206 TOSHIBA Assist 139 Toshiba Hardware Setup 154 Toshiba online resources 102 Toshiba utilities 138 traveling tips 119 troubleshooting DVD player general problems 198 external keyboard 184...
Page 245 warranty limited warranty 38 Web 128 Web sites 204 Wi-Fi® wireless networking 127 Windows Media® Player 99 Windows® Explorer 85 Windows® operating system Help and Support 180 problem solving 178 Windows® operating system desktop Windows® Start menu 84 wireless networking 127 Wizards Dial-Up Networking Wizard 125 World Wide Web 128...

This manual is also suitable for:

G45-av690 Qosmio g45 Qosmio g45-av series

Toshiba G45-AV680 User Manual

Chapter 1: Getting Started

Chapter 2: Learning the Basics

Chapter 3: Mobile Computing

Chapter 4: Exploring Your Computer's Features

Chapter 5: Toshiba Utilities

Chapter 6: If Something Goes Wrong

Appendix A: Hot Keys/Toshiba Cards

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toshiba G45-AV680

Summary of Contents for Toshiba G45-AV680
