Toshiba Qosmio F45-AV411 Specifications

Qosmio F45-AV411 Detailed Product Specification
Model Name F45-AV411
:
C1 2
Operating System
• Genuine Windows Vista™ Ultimate (32-bit version)
3
Processor and Chipset
Intel® Centrino® Duo processor technology featuring:
• Intel® Core™ 2 Duo Processor T5450
o 1.66GHz, 2MB L2, 667MHz FSB with 64-bit
• Mobile Intel® GM965 Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
6
Memory
• Configured with 2048MB PC2-5300 DDR2 SDRAM (both memory slots
may be occupied). Maximum capacity 4096MB
• Intel® Turbo Memory
o 1024MB
7
Hard Disk Drive
• 200GB Serial ATA hard disk drive
8
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) with Labelflash™ drive supporting 11
formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x), CD-
RW (4x), DVD-ROM (8x), DVD-R (Single Layer, (8x)), DVD-R
(Double Layer, (4x)), DVD-RW (4x), DVD+R (Single Layer, (8x)),
DVD+R (Double Layer, (4x)), DVD+RW (4x), DVD-RAM (5x)
o Supports Labelflash™ media to burn high quality labels directly on
the disk.
9
Display
• 15.4" diagonal widescreen TruBrite®TFT active-matrix LCD display at
1280x800 native resolution (WXGA)
o Maximum Brightness – up to 200 Cd/m
o Contrast Ratio: 300:1
o Horizontal Viewing Angle: 120 Degree
o Vertical Viewing Angle: 100 Degree
10
Graphics
• Mobile Intel® Graphics Media Accelerator X3100 with 8MB-256MB
dynamically allocated shared graphics memory
Sound
• Two built-in harman/kardon® stereo speakers with subwoofer
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 86 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next Track)
Communications
• Webcam and microphone built into LCD bezel
• Modem
11
• 10/100 Ethernet
• Integrated Wi-Fi® compliant wireless:
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi Media
Card, xD Picture Card [shared slots]
Ports
• Video
Part Number: PQF43U-007004
4
C1
5
2
12
5
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio F45-AV411 Rev. 1.10 2007-07-30 DM T20070420 CB1.10
This product specification is variable and subject to change prior to product launch.
1
o RGB (monitor) output port
o S-Video output port
• Audio
o S/P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 4 ports
• Security
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.9" x 11.0" x 1.50" /1.77" without
feet
• Weight: Starting at 6.6 lbs depending upon configuration
• LCD Cover Color: Cosmic Black
Power
• 90W (19V x 4.74A) 100-240V AC Adapter
• Dimensions (WxDxH): 5.24" x 1.21" x 2.28"
• Weight: starting at 0.89 lb
14
Battery
• 4000mAh Lithium Ion battery pack
• Dimensions (WxDxH): 4.72" x 3.31" x 1.06"
• Weight: starting at 0.73 lb
C1 15
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree®
o TOSHIBA Management Console
o TOSHIBA Assist
o TOSHIBA Security Assist
o TOSHIBA Disc Creator
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Recovery Disc Creator
o TOSHIBA DVD Player
o TOSHIBA Speech System
o TOSHIBA Remote Control Manager
• Third-party Software
o TOSHIBA Game Console
o Microsoft Works Version 8.5
o Sun® Java™ 2 Runtime Environment
o Adobe® Acrobat® Reader 8.0
o InterVideo®WinDVD® 8
o Google™ Desktop
o Google™ Toolbar
o Google Picasa™
o Yahoo! Music™ Jukebox
o Infineon TPM Software Professional Package 3.0
o Protector Suite™ QL by UPEK®
o Ulead® DVD MovieFactory® 5 for TOSHIBA
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day trial)
o McAfee® Internet Security Suite (30-day trial)
• Special Offers
o Microsoft Office Live
o Shutterfly digital photo service
o Napster® music subscription service
o eMusic MP3 music subscription service
SM
o VONGO internet video download service
o ebay®
o Computrace® LoJack® for Laptops (BIOS enabled)
o CNN Pipeline
o Skype™ internet communications
UPC: 032017913813
13
32
Page 2 of 5
