Toshiba Portege R400-S4833 Specifications

Portégé R400-S4833 Detailed Product Specification
Model Name Description
R400-S4833 Genuine Windows Vista™ Ultimate, Intel® Core™ Duo Processor U2500, 2048MB
DDR2, 80GB 4200rpm (ATA-6), 12.1" WXGA 12.1" WXGA LED Backlight High
Brightness Display with Wide View Angle, Intel Graphics Media Accelerator 950, Intel
PRO/Wireless 3945ABG (802.11a/b/g), Bluetooth v2.0+EDR, Integrated EVDO (Verizon
Wireless), 3-year standard limited warranty
Section 1.01 Operating System
• Genuine Windows Vista™ Ultimate
Section 1.02 Processor and Chipset
Intel® Centrino® Duo Mobile Technology featuring:
• Intel® Core™ Duo Processor U2500
1.20GHz, 2MB L2, 533MHz FSB
• Chipset
o Mobile Intel® 945GM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
4
Section 1.03 Memory
• Configured with 2048MB PC4200 DDR2 SDRAM (both memory
slots are occupied)
• 2048MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 DDR2 memory modules. Dual-channel support
requires two memory modules of same capacity and clockspeed.
Section 1.04 Hard Disk Drive
• 80GB (4200 RPM) Enhanced IDE (ATA-6) hard disk drive; 8mm
height
6
Section 1.05 Display
o 12.1" diagonal widescreen LED backlight High Brightness
display at 1280x800 native resolution (WXGA) with Wide
Viewing Angle.
Section 1.06 Graphics
• Intel® Graphics Media Accelerator 950 with 8MB-256M dynamically
allocated shared graphics memory
Section 1.07 Sound
• Built-in monaural speaker
• Sound Volume Control
• Built-in microphone
Section 1.08 Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Email button
o Security button
o Rotation button
o Cross-Functional button (TOSHIBA Mobility Center)
2CPU_64
3
5
7
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R400-S4833 BTS Rev. 1.02 2007-01-22 cm/sk T20061025 CB1.00
1
Section 1.09 Communications
• Intel® PRO/1000 Network Connection - 10/100/1000 Base-TX
Ethernet
• Integrated Wireless-LAN:
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
• Integrated EVDO Verizon Wireless
Section 1.10 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
Section 1.11 Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o USB v2.0 – 2 ports
o RJ-45 LAN port
Section 1.12 Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 12.0" (304.0mm) x 9.43"
(239.5mm) x 1.18" (29.9mm)[F]/1.26" (31.9mm)[R] without feet
• Weight: Starting at 3.79 lbs (1.72 kg) depending upon
10
configuration
• Chassis Description
o Case material: Magnesium + Polycarbonate ABS
o LCD Cover Color: Cloud
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Main HDD
o Fingerprint reader
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Section 1.13 Power Supply
• 60W (15V x 4A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 4.51" (114.5mm) x 1.14" (29.0mm) x 1.95"
(49.5mm)
• Weight: starting at 0.58 lbs (262 g)
Section 1.14 Battery
• 6-cell (4000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Dimensions (WxDxH): 8.74" (221.9mm) x 3.29" (83.67mm) x 0.47"
(11.9mm)
• Weight: starting at 0.65 lbs (295 g)
Part Number UPC
PPR40U-00N013 032017793576
8
9
11
Page 1 of 5
