Toshiba Portege R400-S4831 Specifications

Portégé R400-S4831 Detailed Product Specification
Model Name Description
R400-S4831 Genuine Windows Vista™ Business, Intel® Core™ Duo Processor U2500, 1024MB
DDR2, 80GB 4200rpm (ATA-6), 12.1" WXGA LED Backlight High Brightness Display
with Wide View Angle, Intel Graphics Media Accelerator 950, Intel PRO/Wireless
3945ABG (802.11a/b/g), Bluetooth v2.0+EDR, 3-year standard limited warranty
Section 1.01 Operating System
• Genuine Windows Vista™ Business
Section 1.02 Processor and Chipset
Intel® Centrino® Duo Mobile Technology featuring:
• Intel® Core™ Duo Processor U2500
1.20GHz, 2MB L2, 533MHz FSB
• Chipset
o Mobile Intel® 945GM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
4
Section 1.03 Memory
• Configured with 1024MB PC4200 DDR2 SDRAM (both memory
slots are occupied)
• 1024MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 DDR2 memory modules. Dual-channel support
requires two memory modules of same capacity and clockspeed.
Section 1.04 Hard Disk Drive
• 80GB (4200 RPM) Enhanced IDE (ATA-6) hard disk drive; 8mm
height
6
Section 1.05 Display
• 12.1" diagonal widescreen LED backlight High Brightness display at
1280x800 native resolution (WXGA) with Wide Viewing Angle.
Section 1.06 Graphics
• Intel® Graphics Media Accelerator 950 with 8MB-256MB
dynamically allocated shared graphics memory
Section 1.07 Sound
• Built-in monaural speaker
• Sound Volume Control
• Built-in microphone
Section 1.08 Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Email button
o Security button
o Rotation button
o Cross-Functional button (TOSHIBA Mobility Center)
Section 1.09 Communications
• Intel® PRO/1000 Network Connection - 10/100/1000 Base-TX
Ethernet
2CPU_64
3
5
7
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R400-S4831 BTS Rev. 1.03 2007-01-22 cm/sk T20061025 CB1.00
1
• Integrated Wireless-LAN:
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
Section 1.10 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
Section 1.11 Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o USB v2.0 – 2 ports
o RJ-45 LAN port
Section 1.12 Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 12.0" (304.0mm) x 9.43"
(239.5mm) x 1.18" (29.9mm)[F]/1.26" (31.9mm)[R] without feet
• Weight: Starting at 3.79 lbs (1.72 kg) depending upon
9
configuration
• Chassis Description
o Case material: Magnesium + Polycarbonate ABS
o LCD Cover Color: Cloud
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Main HDD
o Fingerprint reader
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Section 1.13 Power Supply
• 60W (15V x 4A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 4.51" (114.5mm) x 1.14" (29.0mm) x 1.95"
(49.5mm)
• Weight: starting at 0.58 lbs (262 g)
Section 1.14 Battery
• 6-cell (4000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Dimensions (WxDxH): 8.74" (221.9mm) x 3.29" (83.67mm) x 0.47"
(11.9mm)
• Weight: starting at 0.65 lbs (295 g)
• Battery Life (measured by MobileMark™)
• Recharge Time
o Main Battery Off/On – approximately 3.5 hrs/approximately
3.5 to 4.0 hrs
Part Number UPC
PPR40U-00K012 032017793552
8
10
11
TBD
Page 1 of 5
