Toshiba Portege M700-S7008 Specifications

Portégé M700-S7008 Detailed Product Specification
Model Name Description
M700-S7008 Genuine Microsoft Windows Vista® Business (32-bit version), Intel® Core™ 2 Duo
Processor T7250, 1024MB DDR2 memory, 80GB 5400rpm (S-ATA) hard drive, DVD
SuperMulti dual layer drive, 12.1" LED Backlit LCD WXGA Display supporting Digital
Pen , Intel® Graphics Media Accelerator x3100, Intel® Wireless WiFi Link 4965AGN
(802.11a/g/n), WebCam, Bridge Media Adapter, 1-year standard limited warranty
2
C1
Operating System
• Genuine Windows Vista® Business (32-bit version)
Processor and Chipset
Intel® Centrino® Pro processor technology featuring:
• Choice of Processor
o Intel® Core™ 2 Duo Processor T7250
2.0GHz, 2MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7500
2.2GHz, 4MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7700
2.4GHz, 4MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7800
2.6GHz, 4MB L2, 800MHz FSB with 64-bit
• Chipset
o Mobile Intel® GM965 Express Chipset
• Wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Wired LAN
o Intel® Pro 82566MM 10/100/1000 Ethernet
5
Memory
• Configured with 1024MB (512MB x 2) PC2-5300 DDR2 SDRAM
• 2 memory slots
• 1024MB (Min)/4096MB (Max), with 512MB, 1024MB or 2048MB PC2-
4200 or PC2-5300 DDR2 memory modules
• Optional 1024MB Intel® Turbo Memory
Hard Disk Drive Options
• 80GB, 120GB,160GB (5400 RPM) or 120GB (7200 RPM), Serial ATA
hard disk drive; 9.5mm height
Ultra SlimBay Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
8
Display
• 12.1" diagonal widescreen LED backlight LCD display at 1280 x 800
native resolution(WXGA) supporting digital pen and touch with
indoor/outdoor viewing
• 12.1" diagonal widescreen LED backlight LCD display at 1280 x 800
native resolution(WXGA) supporting digital pen with indoor/outdoor
viewing
9
Graphics
• Mobile Intel® Graphics Media Accelerator X3100 with 8MB-251MB
dynamically allocated shared graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
3
C1
C1
C1
C1
4
6
7
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this in\formation, which is subject to change without notice.
Portégé M700-S7008, v1.02 2007.12.17 KR T20070828 CB1.00
1
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Windows Mobility Center Button
o Toshiba Assist button
o Windows Security button
o Display Rotation button
o Cross-Functional button
o Power Button Lock
Communications
• Integrated Webcam® and microphone
10
• Modem
• Intel® Pro 82566MM 10/100/1000 Ethernet w/AMT 2.6
• Integrated Wi-Fi® compliant wireless:
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
Expandability
• One PCMCIA – Type II/Type I Card Slot
• Bridge Media Adapter
o Secure Digital, miniSD, Memory Stick™, Memory Stick PRO™,
Memory Stick Duo™, Multi Media Card, xD Picture Card [shared
slots]
o Secure Digital slot supports SDIO
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o Modem-RJ11
o Ethernet-RJ45
o USB v2.0 – 3 ports
• Supported on optional Toshiba Express Port Replicator
o RGB (monitor) output Port
o DVI-D output port
o USB v2.0 – 4 ports
o Ethernet port
Physical Description
• Dimensions (WxDxH Front/H Rear): 12.0" x 9.41" x 1.47" /1.55" without
feet
• Weight: Starting at 4.4 lbs depending upon configuration
• LCD Cover Color: Titanium Silver
Power
• 75W (15V x 5A) 100-240V AC Adapter.
• Dimensions (WxDxH): 5" x 2.01" x 1.20"
• Weight: starting at 0.78 lbs
14
Battery
• (4700mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 4.98" x 2.74" x 0.80"
Part Number UPC
PPM70U-01R01D 883974043385
11
12
13
Page 1 of 6
