Toshiba Portege A605-P210 Specifications

Portégé A605 Detailed Product Specification
Model Name A605-P210
:
C1 2

Operating System

• Genuine Windows Vista ®
Home Premium (SP1, 32-bit version)

Processor and Chipset

® ®
Intel Centrino 2 Processor Technology featuring:
• Intel
®
Core™ 2 Duo Processor SU9400
o 1.40GHz, 3MB L2 Cache, 800MHz FSB
• Mobile Intel
®
GS45 Express Chipset
• Intel
®
WiFi Link 5100AGN (802.11 a/g/n)
5

Memory

• Configured with 3GB PC 6400 DDR2 SDRAM (1GB on motherboard
with 2GB in single available memory slot). Maximum capacity 5GB
6

Storage Drive

• 320GB (5400 RPM) Serial ATA hard disk drives
Fixed Optical Disk Drive
• DVD SuperMulti (+/- double layer) drive with Labelflash™ supporting 11
formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
o Supports Labelflash™ media to burn high quality labels directly
8
Display
• 12.1" diagonal widescreen display at 1280 x800 native resolution
(WXGA)
LED backlight
o
9
Graphics
• Intel
®
Graphics Media Accelerator 4500MHD with 128MB-1340MB
dynamically allocated shared graphics memory
Sound
• Built-in speaker (mono)
• Sound volume control dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o TOSHIBA Assist button
o TOSHIBA Mobility Center button
Communications
• Webcam built into LCD bezel
• Bluetooth
®
version 2.1 plus Enhanced Data Rate(EDR)
• 10/100/1000 Ethernet
• Integrated Wi-Fi
®
compliant wireless:
®
Intel WiFi Link 5100AGN (802.11 a/g/n)
o
Expandability
• 1 main memory slots. Slot is occupied.
• ExpressCard™ slot (ExpressCard/54)
• SD Card reader- Secure Digital, Secure Digital High Capacity
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o 3 USB v2.0 ports
o 2 x USB v2.0 ports
Part Number: PPA60U-037029
3
4
7
10
11
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
o RJ-45 LAN port
• Security
o Fingerprint reader
Physical Description
• Cosmic Black
• Dimensions (WxDxH ): 11.3" x8.8" x 1.2"
• Weight: Starting at 3.22 lbs, depending upon configuration
Power
• 45W (15V x 3A) Auto sensing ,100-240V/50-60Hz AC Adapter
o Dimensions (WxDxH): 3.67" x 1.10" x 1.57"
o Weight: starting at 0.42 lbs
14

Battery

• 5800 mAh(6 cell) Lithium Ion battery pack
C1
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree
o TOSHIBA Disc Creator
o TOSHIBA DVD Player
o TOSHIBA Face Recognition
o TOSHIBA Recovery Disc Creator
o Hard disc(HDD) recovery
o TOSHIBA Resources
• Third-party Software
o Microsoft
o Windows Live™ Home
o Windows Live™ Mail
o Windows Live™ Photo Gallery
o Windows Live™ Writer
o Google™ Toolbar
o Google™ Picasa™
o Google™ Desktop
®
o Ulead
®
o Sun Java™ 2 Runtime Environment
o Adobe
• Trial Software
o Microsoft
o Norton Internet Security™ 2009
• Special Offers
o Amazon.com-Online Shopping
®
o Intuit
o Skype™
o eMusic
o Computrace
Environmental Specifications
16
Temperature
Relative Humidity
(non-condensing)
Thermal Gradient
Altitude
(relative to sea level)
Shock
Vibration
• This product is RoHS
• Energy Star 4.0 Compliant
Portégé A605-P210 1.0
Page 1 of 4
UPC: 883974185849
o 1 x eSATA/USB combo port with USB Sleep and
12
Charge
15
®
®
Works 9
®
DVD MovieFactory 5 for TOSHIBA
® ®
Acrobat Reader
®
Office Home and Student 2007 Edition 60-day trial
®
Quickbooks Financial Center
® ®
LoJack for Laptops(BIOS enabled)
Operating
5° to 35° C
(41° to 95° F)
20% to 80%
15° C per hour (max)
-60 to 3,000 meters
10G
0.25G
17
compatible
13
Non-operating
-20° to 65° C
(-4° to 149° F)
10% to 90%
20° C per hour (max)
-60 to 10,000 meters
60G
1.0G
