American Signature VCF 1913-111SHKR Assembly Instruction

PARTS LIST
NO. DESCRIPTION
A HEADBOARD BOOKCASE
B LEG (R)
C LEG (L)
D FRONT STRETCHER
E REAR STRETCHER
STEP 1
D
MADE IN MALAYSIA
ASSEMBLY INSTRUCTION
ITEM # : 1913-111SHKR KG BKCS HDBD-DAKOTA GRAY
NOTE : THIS ITEM NOT RECOMMENDED FOR COMMERCIAL USE
KEEP THIS DOCUMENT FOR REFERENCE IN CASE PARTS ARE NEEDED
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED ! !
TOOLS REQUIRED (NOT PROVIDED)
QTY PHILIP SCREW DRIVER
1
1
1
NO.
1 1
1 2
3
4
5
6
STEP 2
E
HARDWARE LIST
DESCRIPTION
BOLT M6 x 35
SPRING WASHER
FLAT WASHER M6 x 19
ALLEN KEY
PANHEAD M4 x 32
STRAIGHT ALLEN KEY
A
3
1 2
4
OR
6
B
1 PC
QTY
12
M6 12
12
M4 1
4
M4 1
C
PAGE: 1/5
