Operating Instructions
Micromag HP/50NPT
High Intensity Magnetic Filter
V3
Advertisement
Table of Contents
Related Manuals for Eclipse Magnetics Micromag HP/50NPT
Summary of Contents for Eclipse Magnetics Micromag HP/50NPT
- Page 1 Operating Instructions Micromag HP/50NPT High Intensity Magnetic Filter Representative: www.eclipsemagnetics.com/na Eclipse Tools North America Inc. 442 Millen Road, Unit #9, Stoney Creek, ON L8E 6H2 T 1(800) 260-2124 F 1(800) 260-1410 sales@eclipsetoolsinc.com www.eclipsemagnetics.com/na While every effort has been made to ensure the accuracy of the information in this publication please note that specifications may...
-
Page 2: Table Of Contents
1 Introduction 1.1 Range of application 1.2 Used symbols The Micromag HP/50NPT follows on from the standard Micromag family and has all the same 1.3 Overview incredible benefits. The unit was developed to suit high pressure/temperature applications. 2 Technical data Micromag HP/50NPT can be installed anywhere in the fluid delivery system and can remove 2.1 Performance data... -
Page 3: Overview
1.3 Overview Technical data 2.1 Performance data Application ambient temperature: 32°F to 284°F (0°C to 140°C) Design temperature: 302°F (150°C) Operating design pressure: 725 psi (50 bar) Throughput: MM5/HP/50NPT 18 gallons/minute MM10/HP/50NPT 26 gallons/minute MM20/HP/50NPT 40 gallons/minute Vessel: Aluminium Magnetic characteristics max. -
Page 4: Design And Method Of Operation
Design and method of operation Safety 3.1 Method of operation 4.1 Intended use The single magnetic core is integrated in an aluminium housing and forms one unit e.g. fitted The inline liquid filter is designed for installation into pressurised pipe lines working at up to in series with the pipe-line. -
Page 5: Notes On Residual Risks
• Oppositional poles of magnets attract each other with high clamping forces Micromag HP/50NPT is to be installed vertically with the bowl pointing upwards, this allows • Do not use steel/iron tools or other ferrous parts in the flux field of the system fluid to drain out of the bowl and into the line prior to cleaning. -
Page 6: Maintenance
Spare parts/service If operated and cleaned correctly your Micromag HP/50NPT will give many years of trouble free filtration with no consumable parts. The filter will remove even the smallest particle due 7.1 Spare parts list to its high magnetic field strength. Cleaning should take no more than a few minutes. -
Page 7: Shipping, Preservation, Waste Disposal, Transport, Storage
Shipping, preservation, waste disposal, transport, storage 8.1 Shipping, preservation, waste disposal 2c. Sea freight should be packed in seaworthy export crates. The size of the Suitable packaging should be selected according to the mode of transport (road/air/sea). The goods should be packed in such a way that crates should accurately relate to the volume of the goods. -
Page 8: Transport
8.2 Transport 8.3 Storage • In order to avoid injury or damage to the unit it must be handled • If possible the unit should be stored in a closed room until final properly. In addition to following the instructions below, general health installation.
