ATTACHING A VIZIO SOUNDBAR TO THE DUAL-HEIGHT STAND

The dual-purpose stand lets you raise your TV to accommodate a VIZIO Soundbar
underneath, or to mount your soundbar directly to your wall-mounted TV for the
ultimate streamlined look and finish .
To attach to a traditionally mounted TV:
1 . Place the TV face-down on a clean, flat, stable surface . Be sure the surface is
clear of debris that could scratch or damage the TV .
Use the included screws with the holes on the feet matching your desired height:
These arrows should be facing
down/towards the screen .
Dual-Height Adjustable Stand
OR
Soundbar Mode Low-Profile Mode
• Low Profile Mode: Use the bottom two screw holes . Using this mode with a
soundbar may cause the bottom of the TV screen to be blocked .
• Soundbar Mode: Use the top two screw holes . Using this mode will allow
the soundbar to sit beneath the TV without obstructing the view of the
screen .
2 . After setting the mount to your desired Profile Mode, place your TV upright in
the desired location .
3 . Rest your soundbar centered between the mount feet .
Low Profile Mode
Soundbar Mode
11
