60" x 24" Clamp-on Desk Privacy Panel
Instruction Manual
SKU: PP-1-V060G/D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/pp-1-v060g
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo PP-1-V060G/D
Summary of Contents for Vivo PP-1-V060G/D
- Page 1 60” x 24” Clamp-on Desk Privacy Panel Instruction Manual SKU: PP-1-V060G/D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/pp-1-v060g GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. - Page 3 ABOVE DESK ASSEMBLY STEP 1 OPTION A: Flush Fit Attach Clamps (B) to Panel (A) using M6x30mm Screws (S-C) and Washers (S-B). Tighten with a Phillips screwdriver. OPTION B: Gap-Fit for Cables and Devices Attach Clamps (B) to Panel (A) using M6x40mm Screws (S-D), Washers (S-B) and Spacers (S- A).
- Page 4 STEP 2 Place the assembled panel on the edge of the desk, and tighten the clamps to secure. NOTE: Over-tightening the clamps will cause the panel to lean forwards.
- Page 5 BELOW DESK ASSEMBLY STEP 1 OPTION A: Flush Fit Attach Clamps (B) to Panel (A) using M6x30mm Screws (S-C) and Washers (S-B). Tighten with a Phillips screwdriver. OPTION B: Gap-Fit for Cables and Devices Attach Clamps (B) to Panel (A) using M6x40mm Screws (S-D), Washers (S-B) and Spacers (S- A).
- Page 6 STEP 2 Place the assembled panel on the edge of the desk, and tighten the clamps to secure. NOTE: Over-tightening the clamps will cause the panel to lean forwards.
- Page 7 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
