Summary of Contents for EKO KSB600BT
- Page 1 2.0CH SOUNDBAR KSB600BT INSTRUCTION MANUAL Please read this manual carefully before using, and keep it for future reference.
-
Page 3: Table Of Contents
CONTENTS General Safety Instructions Remote Control Product Overview Controls and Connections First Time Setup General Operations Pairing your soundbar Wall Mounting Soundbar Troubleshooting Specifications Customer Support Last Page... -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS Read this manual thoroughly before you start using the Soundbar. Store this manual, the completed warranty card, your receipt and the product packaging. The safety precautions instructions reduces the risk of fire, electric shock and injury when correctly complied to. - Page 5 GENERAL SAFETY INSTRUCTIONS (Cont.) Please follow instruction when installing this product in accordance with the instruction manual. This product must be positioned in a sufficiently stable location, it can be potentially hazardous due to falling when mounted and can cause injury, particularly to children if it positioned incorrectly. •...
- Page 6 GENERAL SAFETY INSTRUCTIONS (Cont.) • If you notice any unusual odors or smoke around the unit, immediately disconnect the unit from the outlet and contact the service center. Failure to do so may result in fire or electric shock. • When not using the unit for long periods of time or when you are moving the unit please ensure to disconnect the power supply from the power adapter.
-
Page 7: Remote Control
REMOTE CONTROL • The remote control has a reception range of approximately 5m. Be sure to point the remote control directly at the sensor at the front of the soundbar. • Make sure there are no obstacles in the way. This will interfere with the sensor strength. •... - Page 8 REMOTE CONTROL (Cont.) CAUTION! Battery Precautions • Do not use other batteries other than the one specified in this manual. • Danger of explosion if incorrectly replaced by a battery other than the one specified. • Do not store battery with other metallic objects, doing so can cause the battery to short-circuit, leak or explode.
-
Page 9: Product Overview
PRODUCT OVERVIEW SOURCE: SHORT PRESS TO POWER ON WHEN OFF, AFTER POWER ON SHORT PRESS FOR FUNCTION CHANGE, LONG PRESS TO TURN OFF. VOL+: SHORT OR LONG PRESS FOR VOLUME UP; VOL-: SHORT OR LONG PRESS FOR VOLUME DOWN; PAIR: PRESS TO DISCONNECT THE BLUETOOTH CONNECTION;... -
Page 10: Controls And Connections
CONTROLS AND CONNECTIONS HDMI Connect a HDMI cable (not supplied) from your TV HDMI/ARC port to the HDMI socket on the soundbar. Then change the mode on your soundbar to HDMI Mode. Note: To enable the Audio Return Channel (ARC) feature, the HDMI must be connected to an ARC enabled HDMI on your TV. -
Page 11: First Time Setup
CONTROLS AND CONNECTIONS (Cont.) AUDIO RETURN CHANNEL (ARC) / HDMI ARC function is used for connecting the Soundbar to the TV with a HDMI cable through an audio return channel. This means you can listen to the TV sounds through your Soundbar via HDMI cable. -
Page 12: General Operations
GENERAL OPERATION During On mode, press “M” on the Remote Control repeatedly to select between AUX (L&R), BT (Bluetooth ®), OPTICAL, HDMI (ARC), LINE IN and USB modes. Operate your audio device directly for playback features. Turning on/off the unit 1. -
Page 13: Pairing Your Soundbar
2. Now that the unit has entered pairing mode, on your smart device, select to search for devices. 3. Select “KSB600BT” in the list of devices that appear. The Soundbar LED showing BT mode will stay on and stop flashing once their is a successful connection. -
Page 14: Wall Mounting Soundbar
WALL MOUNTING SOUNDBAR 1. Align the Soundbar in your chosen location and use a pencil to mark the drilling positions. 2. Drill the holes as marked. 3. Push 2 wall anchors into the holes. Insert 2 screws into the wall anchors and tighten Take care to leave enough space between the screw heads and the wall. -
Page 15: Troubleshooting
TROUBLESHOOTING Never try to repair the soundbar yourself. If you encounter any problems when using this unit, check the following points before seeking for service. Problem Solution No Power • Ensure that the Switching Adaptor is connected to power socket outlet. •... -
Page 16: Specifications
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Ayonz Pty Ltd is under license. Other trademarks CUSTOMER SUPPORT: and trade names are those of their respective owners. help@eko-entertainment.com.au DISTRIBUTED BY: Ayonz Pty Ltd CUSTOMER HELPLINE: help@eko-entertainment.com.au...
