- Page 1 4.1CH SOUNDBAR WITH WIRELESS SUBWOOFER & DETACHABLE REAR SPEAKERS KSB9400H INSTRUCTION MANUAL Please read this manual carefully before using, and keep it for future reference.
-
Page 3: Table Of Contents
CONTENTS General Safety Instructions Remote Control Product Overview Assembling the Rear Speakers Product Overview - Rear Speakers Additional End Caps for Rear Speakers Location Options - Rear Speakers Controls and Connections First Time Setup with SUBWOOFER General Operations Pairing your soundbar Wall Mounting Soundbar Troubleshooting Specifications... -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS Read this manual thoroughly before you start using the Soundbar. Store this manual, the completed warranty card, your receipt and the product packaging. The safety precautions instructions reduces the risk of fire, electric shock and injury when correctly complied to. - Page 5 GENERAL SAFETY INSTRUCTIONS (Cont.) Please follow instruction when installing this product in accordance with the instruction manual. This product must be positioned in a sufficiently stable location, it can be potentially hazardous due to falling when mounted and can cause injury, particularly to children if it positioned incorrectly. •...
- Page 6 GENERAL SAFETY INSTRUCTIONS (Cont.) • If you notice any unusual odors or smoke around the unit, immediately disconnect the unit from the outlet and contact the service center. Failure to do so may result in fire or electric shock. • When not using the unit for long periods of time or when you are moving the unit please ensure to disconnect the power supply from the wall socket.
-
Page 7: Remote Control
REMOTE CONTROL • The remote control has a reception range of approximately 5m. Be sure to point the remote control directly at the sensor at the front of the soundbar. • Make sure there are no obstacles in the way. This will intefere with the sensor strength. •... - Page 8 REMOTE CONTROL (Cont.) CAUTION! Battery Precautions • Do not use other batteries other than the one specified in this manual. • Danger of explosion if incorrectly replaced by a battery other than the one specified. • Do not store battery with other metallic objects, doing so can cause the battery to short-circuit, leak or explode.
-
Page 9: Product Overview
PRODUCT OVERVIEW SOUNDBAR SUBWOOFER INPUT: SHORT PRESS TO POWER ON WHEN OFF, AFTER POWER ON SHORT PRESS FOR FUNCTION CHANGE, LONG PRESS TO TURN OFF. VOL-: SHORT OR LONG PRESS FOR VOLUME DOWN; VOL+: SHORT OR LONG PRESS FOR VOLUME UP; PAIR: SHORT OR LONG PRESS BLUETOOTH PAIR;... -
Page 10: Assembling The Rear Speakers
ASSEMBLING THE REAR SPEAKERS Power on the Main Unit by connecting the DC input, and also power on the REAR Speakers (smaller) by clicking power switch on the back to ON. Attach the 2x Rear speakers and align to each ends of the soundbar. Please make sure the Rear Speakers are aligned correctly to the soundbar and push into place. - Page 11 ASSEMBLING THE REAR SPEAKERS...
-
Page 12: Product Overview Rear Speakers
PRODUCT OVERVIEW REAR SPEAKERS RIGHT SPEAKER LEFT SPEAKER ON/OFF SWITCH DC IN (USB-C) END CAP FOR REAR SPEAKERS Additional END CAPS are provided to attach onto the base of the rear speakers, once they are detached from the main soundbar. Then the rear speakers can be mounted onto stands that contain a tripod screw. -
Page 13: Location Options - Rear Speakers
LOCATION OPTION - REAR SPEAKERS... -
Page 14: Controls And Connections
CONTROLS AND CONNECTIONS HDMI Connect a HDMI cable (not supplied) from your TV HDMI/ARC port to the HDMI socket on the soundbar. Then change the mode on your soundbar to HDMI Mode. Note: To enable the Audio Return Channel (ARC) feature, the HDMI must be connected to an ARC enabled HDMI on your TV. -
Page 15: First Time Setup With Subwoofer
CONTROLS AND CONNECTIONS (Cont.) AUDIO RETURN CHANNEL (ARC) / HDMI ARC function is used for connecting the Soundbar to the TV with a HDMI cable through an audio return channel. This means you can listen to the TV sounds through your Soundbar via HDMI cable. -
Page 16: General Operations
GENERAL OPERATION During On mode, On the Remote Control choose either to select between AUX, (Bluetooth ®), OPTICAL, HDMI (ARC). Operate your audio device directly for playback features. Turning on/off the unit 1. Insert the output cable from the DC adaptor into power socket on the rear of the Sound Bar. -
Page 17: Pairing Your Soundbar
2. Now that the unit has entered pairing mode, on your smart device, select to search for devices. 3. Select “KSB9400H” in the list of devices that appear. The Soundbar will make a tone once their is a successful connection. -
Page 18: Wall Mounting Soundbar
WALL MOUNTING SOUNDBAR At the back of the soundbar, locate and remove the screws from the back side of the sound bar (2x per side - 4 Total) Using the screwdriver, attach the mounting bracket (included) to the soundbar using the screws removed in step 1. -
Page 19: Troubleshooting
TROUBLESHOOTING Never try to repair the soundbar yourself. If you encounter any problems when using this unit, check the following points before seeking for service. Problem Solution No Power • Ensure that the Switching Adaptor is connected to power socket outlet. •... -
Page 20: Specifications
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Ayonz Pty Ltd is under license. Other trademarks and trade names are those of their respective owners. CUSTOMER HELPLINE: help@eko-entertainment.com.au DISTRIBUTED BY: Ayonz Pty Ltd...
