- Page 1 2.0.2CH DOLBY ATMOS SOUNDBAR KSB202DA INSTRUCTION MANUAL Please read this manual carefully before using, and keep it for future reference.
-
Page 3: Table Of Contents
CONTENTS General Safety Instructions Remote Control Product Overview Product Placement Controls and Connections General Operations Pairing your soundbar DOLBY ATMOS Troubleshooting Specifications Support Last Page... -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS Read this manual thoroughly before you start using the Soundbar. Store this manual, the completed warranty card, your receipt and the product packaging. The safety precautions instructions reduces the risk of fire, electric shock and injury when correctly complied to. - Page 5 GENERAL SAFETY INSTRUCTIONS (Cont.) Please follow instruction when installing this product in accordance with the instruction manual. This product must be positioned in a sufficiently stable location, it can be potentially hazardous due to falling when mounted and can cause injury, particularly to children if it positioned incorrectly. •...
- Page 6 GENERAL SAFETY INSTRUCTIONS (Cont.) • If you notice any unusual odors or smoke around the unit, immediately disconnect the unit from the outlet and contact the service center. Failure to do so may result in fire or electric shock. • When not using the unit for long periods of time or when you are moving the unit please ensure to disconnect the power supply from the wall socket.
-
Page 7: Remote Control
REMOTE CONTROL • The remote control has a reception range of approximately 5m. Be sure to point the remote control directly at the sensor at the front of the soundbar. • Make sure there are no obstacles in the way. This will intefere with the sensor strength. •... - Page 8 REMOTE CONTROL (Cont.) CAUTION! Battery Precautions • Do not use other batteries other than the one specified in this manual. • Danger of explosion if incorrectly replaced by a battery other than the one specified. • Do not store battery with other metallic objects, doing so can cause the battery to short-circuit, leak or explode.
-
Page 9: Product Overview
PRODUCT OVERVIEW DISPLAY PANEL INCREASE VOLUME STANDBY / ON INPUT - SELECT INPUT MODE DECREASE VOLUME FOR SOUNDBAR AC IN - CONNECT POWER SUPPLY HDMI IN 2 - CONNECT TO HDMI OUT PORT OF YOUR Set-top box, dvd player, Blu-ray Player, media player. HDMI IN 1 - CONNECT TO HDMI OUT PORT OF YOUR Set-top box, dvd player, Blu-ray Player, media player. -
Page 10: Product Placement
PRODUCT PLACEMENT SOUNDBAR Please make sure to place Dolby Atmos Soundbar ontop of a TV unit. Not inside. Make sure to align it in the centre of the TV DO NOT place it inside a TV cabinet, you must allow for airflow and best sound output, you will not be able to fully utilize Dolby Atmos sound quality while placing it in an enclosed TV unit. -
Page 11: Controls And Connections
CONTROLS AND CONNECTIONS HDMI Connect a HDMI cable (not supplied) from your TV HDMI/ARC port to the HDMI socket on the soundbar. Then change the mode on your soundbar to HDMI ARC Mode. Note: To enable the Audio Return Channel (ARC) feature, the HDMI must be connected to an ARC enabled HDMI on your TV. - Page 12 CONTROLS AND CONNECTIONS (Cont.) AUDIO RETURN CHANNEL (ARC) / HDMI ARC function is used for connecting the Soundbar to the TV with a HDMI cable through an audio return channel. This means you can listen to the TV sounds through your Soundbar via HDMI cable.
- Page 13 HDMI PORTS - HOW TO USE To connect 2 different devices to your soundbar, seperate from getting the Audio from your TV to soundbar, you can plug in a Media player and a DVD player to pass through audio and video to your TV with either HDMI IN 1 or HDMI IN 2 Ports.
-
Page 14: General Operations
GENERAL OPERATION POWER ON / OFF Plug in the power cord into the power outlet and turn on. The Soundbar will go into standby mode when powered. Switch on the soundbar by pressing the on the unit or RC. Default input mode will appear after around 10 seconds. Press and hold the button on the RC or unit to power off. -
Page 15: Pairing Your Soundbar
2. Now that the unit has entered pairing mode, on your smart device, select to search for Bluetooth devices. 3. Select “KSB202DA” in the list of devices that appear. The Soundbar will make a tone once their is a successful connection. -
Page 16: Dolby Atmos
DOLBY ATMOS IF YOUR TV DOES NOT SUPPORT DOLBY ATMOS, THEN YOU MUST PLUG YOUR DOLBY ATMOS SUPPORTED MEDIA PLAYER OR CONSOLE INTO THE SOUNDBAR DIRECTLY, WITH ONE OF THE HDMI (IN) PORTS. PLEASE REFER TO PAGE 13 (HDMI PORTS - HOW TO USE) MUST USE A HDMI 2.0 CABLE, OTHERWISE DOLBY ATMOS WILL NOT WORK. -
Page 17: Troubleshooting
TROUBLESHOOTING Never try to repair the soundbar yourself. If you encounter any problems when using this unit, check the following points before seeking for service. Problem Solution No Power • Ensure that the AC Plug is connected to power socket outlet. •... -
Page 18: Specifications
SPECIFICATIONS Power Supply 100-240V~ 50/60Hz Output Power Total: 30W × 4 = 120W R.M.S. Frequency Response 70Hz-20Khz Driver Unit 2.5” x 4 + 2” × 2 Bluetooth 5.0, A2DP, AVRCP Bluetooth Range Up to 10m Dimensions 960 (w) x 108 (d) x 81 (h) mm The Bluetooth®... - Page 20 CUSTOMER HELPLINE: info@ayonz.com DISTRIBUTED BY: Ayonz Pty Ltd...
