Daikin 3MXM40N2V1B9 Installer's Reference Manual page 39

2MXM68+3(A)MXM+3(A)MXF+4MXM+5MXM
R32 Split series
4P600463-1D – 2021.03
Port
B + C (Ø12.7mm)
3MXM68
A (Ø9.5 mm)
B + C (Ø12.7mm)
3MXF52, 3AMXF52, 3MXF68
A (Ø9.5 mm)
B + C (Ø12.7mm)
4MXM68
A + B (Ø9.5 mm)
C + D (Ø12.7mm)
4MXM80
A (Ø9.5 mm)
B (Ø12.7mm)
C + D (Ø15.9 mm)
5MXM90
A + B (Ø9.5 mm)
C (Ø12.7mm)
D + E (Ø15.9 mm)
(a)
Only in case of connection with FTXM42R.
1 2
Reducer type
1
2
3
4
Class
15, 20, 25, 35
42, 50
(a)
15, 20, 25, 35, (42)
15, 20, 25, 35, 42
50, 60
20, 25, 35
20, 25, 35
(a)
15, 20, 25, 35, (42)
(a)
15, 20, 25, 35, (42)
42, 50, 60
(a)
15, 20, 25, 35, (42)
(a)
15, 20, 25, 35, (42)
42, 50, 60
(a)
15, 20, 25, 35, (42)
42, 50, 60
71
(a)
15, 20, 25, 35, (42)
(a)
15, 20, 25, 35, (42)
42, 50, 60
(a)
15, 20, 25, 35, (42)
42, 50, 60
71
3 4 5
Connection
Ø15.9 mm → Ø12.7 mm
Ø12.7 mm → Ø9.5 mm
Ø15.9 mm → Ø12.7 mm
Ø12.7 mm → Ø9.5 mm
7 Piping installation
|
Reducer
2+4
—
—
2+4
—
—
2+4
—
2+4
—
—
2+4
—
5+6
1+3
—
—
2+4
—
5+6
1+3
—
6
