- Page 1 P2300D1 P2300D2 Play 2 300mm Subwoofer User Manual...
- Page 3 THANK YOU! Thank you for purchasing this Bass Habit subwoofer. Please read this manual in order to fully understand how to get the best result from this product and ensure that the advices on how to look after the product and the safety precautions are followed.
-
Page 4: Table Of Contents
TABLE OF CONTENT • SAFETY & WARRANTY Caution Warranty What is not covered Warning International technical enquiries • INSTRUCTIONS Installation experience Choosing subwoofer mounting locations Preparing for installation Installation precautions Installing the subwoofer Recommended subwoofer enclosure size • WIRING EXAMPLES Dual 1 ohm VC in parallel Dual 2 ohm VC in parallel Dual 1 ohm VC in series... -
Page 5: Safety & Warranty
Ensure that no moving parts get caught on the subwoofer or grill. WARRANTY All Bass Habit products carry a full warranty depending on the conditions in the country where it is sold. The warranty is valid from the date of the original receipt as proof of purchase (warranty period differs depending on local warranty laws and policies). -
Page 6: Instructions
Installation of Bass Habit subwoofer may require experience with a variety of mechanical procedures including enclosure construction. This manual only provides general installation and operation instructions. If you have any reservations about your installation skills, please contact your local authorized Bass Habit dealer for help. CHOOSING SUBWOOFER MOUNTING LOCATIONS Choosing the correct subwoofer mounting location will have the greatest effect of the sound quality of the system. -
Page 7: Installing The Subwoofer
7) Pull the wire through the subwoofer opening and connect the subwoofer. Be sure to observe proper polarity. 8) Mount the subwoofer using good quality screws. RECOMMENDED SUBWOOFER ENCLOSURE SIZE Bass Habit subwoofers need an enclosure to perform at it´s very best. Follow the suggested enclosures values below for a good over all bass experience. VENTED ENCLOSURE:... -
Page 8: Wiring Examples
WIRING EXAMPLES Your Bass Habit Elite subwoofer uses double 1 ohm or 2 ohm voice coils depending on the model. It is important to know the limits of your amplifier to optimize its performance. You can vary the impedance by altering the wiring configurations between series or parallel. -
Page 9: Specifications
SPECIFICATIONS P2300D1 P2300D2 Subwoofer Subwoofer Component 300mm (12") 300mm (12") Size 500W 500W RMS Power 1000W 1000W MAX Power 1500W 1500W PEAK Power 1+1 Ohm 2+2 Ohm Nominal Impedance 86,5dB 86,5dB Sensitivity Heavy-duty metal Heavy-duty metal Basket material Cone material Non-Pressed Paper Non-Pressed Paper Surround material... - Page 10 The crossed-out wheelie bin symbol means that the product, literature and packaging included must be taken to separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste: dispose of them at a recycling point. For info on your nearest recycling point, check with your local waste authority.
