Side View
Figure 13
Wall
Isolation Through Wall
Figure 14
Figure 15
8 Feet Maximum
Secure Suc tion Line using isolators every 8 feet .
Secure Liqu id Line directly to Suc tion Line using
tape, wire, or other approp riate method every 8 feet.
Isolation In Wall Spaces
Sealant
Insulati on
Suc tio n Line
8 Feet Maximum
DO NOT hang line sets from ductwork
6
Wall
Isolator
Line Set
Duc twork
Isolator
Line Set
