Page 1: Parts List
PARTS LIST MODELS N500 N500.3 PART # 620428 NORCOLD 01/04/2007... - Page 2 CABINET ASSEMBLY (FRONT VIEW) - N500 SERIES ART01567 N500 SERIES PARTS LIST - PAGE 2...
- Page 3 CABINET ASSEMBLY (FRONT VIEW) - N500 SERIES PART # DESCRIPTION 620195 GAS CONTROL ASSY 620881 SHROUD-UPPER CONTROL AREA 620201 CONTROL PANEL ASSY 620445 CONTROL PANEL ASSY 619070 KNOB-SELECTOR-TAUPE (SUBSTITUTE 629357 - WARM GRAY) 619069 KNOB-GAS CONTROL (USE 619070) 619103 LATCH-DOOR...
- Page 4 CABINET ASSEMBLY (REAR VIEW) - N500 SERIES N500 SERIES PARTS LIST - PAGE 4...
- Page 5 CABINET ASSEMBLY (FRONT VIEW) - N500 SERIES PART # DESCRIPTION 620222 BURNER TUBE 61686823 FINS 61728722 CLIP-FIN 61695022 CAP-HEAT DEFLECTOR 621427 NSC SYSTEM PACK-COOLING UNIT 620884 HEATER-DC/EG3 61562522 HEATER-AC/200W/110VAC 61712637 COVER ASSY-BURNER BOX 61710922 DRIP CUP-REAR 622393 DRAIN HOSE ASSY...
-
Page 6: Gas Control Assembly Area - N500 Series
GAS CONTROL ASSEMBLY AREA - N500 SERIES Art01336 PART # DESCRIPTION 620195 GAS CONTROL ASSY 617952 BRACKET-MOUNTING/THERMOSTAT/GAS VALVE 621298 GAS VALVE-THERMOSTAT CONTROL 61621622 BRASS ELBOW-UNION TUBE 619055 ADAPTOR-PIPE 622098 SAFETY VALVE 621737 INTERRUPTER 620424 THERMOCOUPLE N500 SERIES PARTS LIST - PAGE 6... - Page 7 CONTROL PANEL ASSEMBLY AREA - N500 SERIES PART # DESCRIPTION 620202 CONTROL PANEL 620206 CONTROL PANEL 620863 SWITCH-SELECTOR 621308 NUT-ATTACHMENT 619070 KNOB-SELECTOR (SUBSTITUTE 629357 - WARM GRAY) 61609022 INDICATOR LIGHT-FLAME 618040 CONNECTOR-.25"/FEMALE NS = NOT SHOWN N500 SERIES PARTS LIST - PAGE 7 N500 N500.3...
- Page 8 EVAPORATOR DOOR ASSEMBLY - N500 SERIES PART # DESCRIPTION 619117 FREEZER DOOR ASSY 61632930 MOUNTING CLIP-RH/WHITE/EVAPORATOR DOOR 61633030 MOUNTING CLIP-LH/WHITE/EVAPORATOR DOOR N500 SERIES PARTS LIST - PAGE 8 N500 N500.3...
- Page 9 DOOR ASEMBLY - N500 SERIES ART01329 PART # DESCRIPTION 620125 DOOR ASSY-CABINET 620130 PANEL RETAINER 619104 LATCH PLATE-DOOR 620200 PLATE-FILLER/DOOR ASSY 61742022 HINGE BUSHING 618746 HINGE BUSHING N500 SERIES PARTS LIST - PAGE 9 N500 N500.3...
- Page 10 BURNER ASSY-5 SLOT (USE 621955) 620462 ORIFICE ADAPTER ASSY-LP14 (USE 621955) 621955 KIT-BURNER/ORIFICE ADAPTER ASSY 621079 CONNECTOR-SWIVEL NUT (SERIAL NUMBER 783384 AND ABOVE) 621054 PRESSURE TAP (SERIAL # 783384 AND ABOVE) 61445322 PLUG-1/8"/FOR PRESSURE TAP N500 SERIES PARTS LIST - PAGE 10 N500 N500.3...
