Service Manual
Gas/Electric Refrigerators
MODELS
N500
N510
!
WARNING
DO NOT install this refrigerator in below deck marine applications. Do not
install this refrigerator in fixed indoor cabin or other dwelling applications. This
refrigerator must use only NORCOLD designed and approved outside air in-
take and exhaust ventilation for correct and safe operation. Any other ventila-
tion could cause lethal combustion exhaust fumes and or/explosive propane
gas fumes to be in the living area and/or below deck.
Publication No. 626800A (06-08-04)
© 2004 THETFORD/NORCOLD. All rights reserved.
