Page 1: Parts List
PARTS LIST DV0061 SERIES DE0061 DE0061T EV0061 PART NO.624380 NORCOLD 03/28/2007... - Page 2 DOOR - UPPER (FREEZER) - DV0061 SERIES PART # DESCRIPTION 621560 DOOR LINER ASSY-FOAMED/UPPER 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK 621519 PANEL RETAINER-BLACK/UPPER DOOR/HINGE SIDE 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK 618619 BIN-DOOR SHELF/SMALL/WHITE 621520 DOOR HANDLE ASSY-VERTICAL 621518 PANEL RETAINER-BLACK/UPPER DOOR/HANDLE SIDE 618160 CAP-HINGE PLUG/BLACK 619569...
- Page 3 DOOR - LOWER (FRESH FOOD) - DV0061 SERIES PART # DESCRIPTION 621559 DOOR LINER ASSY-FOAMED/LOWER 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK 621548 PANEL RETAINER-BLACK/LOWER DOOR/HINGE SIDE 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK 623696 BIN-DOOR-LARGE WHITE 618619 BIN-DOOR SHELF/SMALL/WHITE 621547 PANEL RETAINER-BLACK/LOWER DOOR/HANDLE SIDE 621520 DOOR HANDLE ASSY-VERTICAL 618160...
- Page 4 CABINET ASSEMBLY - FRONT VIEW - DV0061 DV0061 SERIES PARTS LIST - PAGE 4...
- Page 5 CABINET ASSEMBLY - FRONT VIEW - DV0061 PART # DESCRIPTION 169000600 POWER SUPPLY-AC (SP-298B) 169000610 POWER SUPPLY-AC (SP-298A) 621634 GRILL-TOP/VENTILATION 163011300 POWER SUPPLY-DC/SP-297 163011310 POWER SUPPLY-DC/SP-296 FUSE-BLADE/15 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) 160220100 KNOB-THERMOSTAT 623128 TRIM PIECE-SIDE/RH 619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLACK 618144 HINGE BUSHING-DOOR HINGE/BLACK 618145...
- Page 6 CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0061 SERIES DV0061 SERIES PARTS LIST - PAGE 6...
- Page 7 CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0061 SERIES PART # DESCRIPTION 169000600 POWER SUPPLY-AC (SP-298B) 169000610 POWER SUPPLY-AC (SP-298A) 163011300 POWER SUPPLY-DC/SP-297 163011310 POWER SUPPLY-DC/SP-296 FUSE-BLADE/15 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) 169000700 CIRCUIT BOARD-LIGHT CONTROL 621634 GRILL-TOP/VENTILATION 623133 CHANNEL-BOTTOM RAIL...
