Page 1: Parts List
PARTS LIST DV0041 SERIES DE0041 DE0041T EV0041 PART NO.624379 NORCOLD 02/27/2008... - Page 2 DOOR - (FRESH FOOD) - DV0041 SERIES PART # DESCRIPTION 621669 DOOR LINER ASSY-FOAMED 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK 621667 PANEL RETAINER-BLACK/HINGE SIDE 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK 623696 BIN-DOOR-LARGE WHITE 618619 BIN-DOOR SHELF/SMALL/WHITE 621668 PANEL RETAINER-BLACK/HANDLE SIDE 621520 DOOR HANDLE ASSY-VERTICAL 618160 CAP-HINGE PLUG/BLACK 619569...
- Page 3 CABINET ASSEMBLY - FRONT VIEW - DV0041 SERIES DV0041 SERIES PARTS LIST - PAGE 3...
- Page 4 CABINET ASSEMBLY - FRONT VIEW - DV0041 PART # DESCRIPTION 161013400 COOLING UNIT-DE0041/EV0041 160928900 FAN ONLY-50 CYCLE/40 WATT 169000500 POWER SUPPLY-AC (SP-243B) 169000510 POWER SUPPLY-AC (SP-260A) 621634 GRILL-TOP/VENTILATION 163011200 POWER SUPPLY-DC (SP-295) 163011210 POWER SUPPLY-DC (SP-294) FUSE-BLADE/10 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) 160220100 KNOB-THERMOSTAT 623119...
- Page 5 CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0041 SERIES DV0041 SERIES PARTS LIST - PAGE 5...
- Page 6 CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0041 SERIES PART # DESCRIPTION 169000700 CIRCUIT BOARD-LIGHT CONTROL 163011200 POWER SUPPLY-DC (SP-295) 163011210 POWER SUPPLY-DC (SP-294) FUSE-BLADE/10 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) 169000500 POWER SUPPLY-AC (SP-243B) 169000510 POWER SUPPLY-AC (SP-260A) 160928900 FAN ONLY-50 CYCLE/40 WATT 623153...
