- Page 1 WORLD BAND RADIO AR 1946 AM/FM RDS/SW/LW/ DAB radio with LCD backlight d keypad direct entry OWNER’S MANUAL Distributed by: Electus Distribution Pty Ltd 320 Victoria Rd Rydalmere NSW 2116 Australia Ph: 1300 738 555 Fax: 1300 738 500 www.electusdistribution.com.au...
- Page 3 WARNING Do not expose this appliance to rain or moisture Do not submerge or expose to water. Protect from high humidity and rain. Only operate within specified temperature range( 0 ℃to 40 ℃ Unplug immediately if liquid has been spilled or object have fallen into the apparatus.
- Page 4 Radio Identification - Front View Tuning knob Info/Light button Tone button FM band button LW band button Dial Speed selection MW band button UP button SW band button Down button DAB band button Volume up button Charge/Air Squelch/Mute button Volume down button Numeric key button AM Bandwidth/FM Stereo/Alarm button Frequency button...
- Page 5 Radio Identification - Side Views Rear Right Line out jack DAB/FM/SW External Antenna Antenna Sens Ext./Int. switch Line in jack Earphone jack (3.5mm) AM External Antenna DC In jack (5.5mm) Battery Compartment DAB/FM Whip Antenna Fine Tuning Knob Carry handle...
- Page 7 ‘ When the alarm is activated, press ‘POWER’ button to shut off alarm and snooze function.
-
Page 8: Lock Setting
LOCK SETTING Quickly press the button to lock out the operations of all buttons except back light. The “lock” icon will be displayed. Press and release the “LOCK” button for 2 seconds unlock the operations for all buttons, the “lock” icon will disappear. SETTING TIME When the radio is off, quick press “TIME”... -
Page 9: Using The Numeric Keypad
SETTING 12/24H FORMAT When the radio is off, hold 1# button (i.e. 12/24H button) down for 2 seconds, the LCD will display “12H” or “24H” by turn. SHUT DOWN ALARM OR SNOOZE FUNCTION When the alarm is activated, quick press “POWER” button to shut down alarm. When the alarm is on, press any button except POWER &... - Page 10 TUNING IN STATION When the radio ON, user has five ways of tuning into desired station. MANUAL TUNING Select your desired band, short press UP or DOWN button, the frequency will be changed as per the following step: FM step : 100kHz, LW step: 3kHz, SW step: 5kHz , AM step: 9kHz or 10kHz AUTO TUNE TUNING Select your desired band, hold down UP or DOWN button for 2 seconds,...
- Page 11 Preset/Recall Memory - FM/LW/MW/SW Each band can save 100 memories(P0~P99),total 10 pages (Page-00~ Page-09),each page can save 10 channels (PX0~PX9),”X” means page, for example, if this station is in page-01, then 10 channels mean P10~P19. Preset Station There are two methods to preset station as under: 1)ATS - Automatic Tuning System, please see ‘TUNING IN STATION’...
-
Page 12: Squelch Function
SQUELCH FUNCTION When the radio is on, hold down “SQUELCH “ button for 2 seconds. LCD displays “SQUELCH OFF or 1~9", then rotate tuning knob to select your desired squelch level (1~9) or “OFF” to shut down squelch function. Quickly press “SQUELCH” button again to exit SQUELCH function. When the strength of signal is lower than selected squelch level, the radio will be mute automatically and LCD displays “SQUELCH”. - Page 13 FM RDS/INFO FUNCTION Turn on the radio and select “FM” band, this radio supports RDS streaming while tune in FM station with RDS data, 1) If the radio tunes in FM station with RDS, icon will be displayed in the left lower side; 2) Quickly press “INFO”...
- Page 14 SAVE/RECALL/DELETE DAB PRESETS There are total 20 presets for DAB band, saved at 2 pages,10 presets for each page (P00~P19). When the radio is on, in DAB mode, quickly press “PAGE” button to switch “PAGE 00" and “PAGE 01"; Select your desired station, quickly press “PAGE” button to select one page, then long press numeric button (0~9) then LCD displays “PXX SAVE”.
- Page 15 MANUAL TUNING -DAB/DAB+ Manual tuning allows you to tune in various Band III channel from 5A to 13F: 1) In DAB mode, quickly press “MENU” button then rotate tuning knob or press “UP” button to select “MANUAL”; 2) Quickly press “ENTER” button to enter channel selection ; 3) Rotate tuning knob or short press UP or DOWN button to select the channel range from ”...
-
Page 16: Software Version
SOFTWARE VERSION The user can check software version and also the software may vary: 1) In DAB mode, quickly press “MENU” button then rotate tuning knob or press “UP” button to select “VERSION”; 2) Quickly press “ENTER” button to display software version ; 3) Quickly press “MENU”... - Page 17 ADJUST AUDIO TONE - TREBLE/BASS Quickly press “TONE” button, select Treble setting, LCD displays “TREB: XX”, rotate the FINE Tuning knob on the right side of unit to adjust treble volume; Quickly press “TONE” button, select Bass setting, LCD displays “BASS: XX”, rotate the FINE Tuning knob on the right side of unit to adjust bass volume;...
- Page 18 FM/SW/DAB EXTERNAL ANTENNAS This socket locates on the back of the radio is primarily for antennas designed to be fed with 50 or 70 ohm coaxial cable, such as dipoles or comparable antennas, It can also be used for long wire antennas. Use PAL type connector for feeding this socket.
-
Page 19: Specifications
SPECIFICATIONS: FREQUENCY COVERAGE FM Band: 87.5 - 108 MHZ (default) AM(MW) Band: 522 - 1620 kHz (9kHz step) 520 - 1710 kHz (10kHz step) SW Band: 1711 - 29999 kHz LW Band: 150 - 450 kHz Band III: 5A - 13F MEMORY PRESETS FM/MW/SW/LW : 400 total ( 100 Per Band) Band III: 20 total...
