DROP IN SIDE BURNER
Premium #304 grade stainless steel or Matt black finish
Flame Failure Device (FFD) for added safety
Electronic ignition
Convenient lid gives you extra bench space
when not in use
Stainless steel burner
Supplied fully assembled
Gas Certified to Australian Standards
Suitable for Natural Gas conversion
LCC27 REGULATOR SUPPLIED
(LPG MODELS ONLY)
This LCC27 Regulator can only be used with
the new safer industry standard LCC27 Gas
Cylinder Connection.
FOR OUTDOOR USE ONLY
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the instructions thoroughly before installing or
servicing this equipment.
WARNING! DO NOT USE AN ADAPTOR ON THE
CYLINDER CONNECTION
PHOENIX
Stainless Steel Model NO. BQ2027, BQ2027NG,
Black Model NO. BQ2027BL, BQ2027BLNG
Important: Retain these instructions for future use.
Gasmate® is a registered trademark of
Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living, N.Z. www.gasmate.co.nz
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call
your gas supplier.
Do not store or use gasoline or other flammable vapour
and liquids in the vicinity of this or any other appliance.
04579 09/23
Advertisement
Table of Contents
Related Manuals for Gasmate PHOENIX
Summary of Contents for Gasmate PHOENIX
- Page 1 WARNING! DO NOT USE AN ADAPTOR ON THE and liquids in the vicinity of this or any other appliance. CYLINDER CONNECTION Important: Retain these instructions for future use. Gasmate® is a registered trademark of 04579 09/23 Sitro Group Australia Pty Ltd www.gasmate.com.au Aber Living, N.Z. www.gasmate.co.nz...
-
Page 2: General Information
GENERAL INFORMATION materials and the gas cylinder clear of any heat source. When changing over from an empty gas cylinder to a IMPORTANT full one make sure this procedure is carried out in a well ventilated location, preferably outside, away from people Read these instruction carefully prior to use. - Page 3 before checking to ensure the burner tubes are fully seated over gas valve orifices. WARNING • Never lean over cooking surface when lighting. Failure to comply with these instructions could result • Never alter or modify the regulator or gas supply in a fire or explosion which could cause serious bodily assembly.
-
Page 4: General Assembly
GENERAL ASSEMBLY IMPORTANT Connecting & Disconnecting to the Gas Source Familiarise yourself with the general information and • Do not smoke when attempting to ignite the safety guidelines located at the front of this manual. barbecue. DO NOT USE AN ADAPTOR ON THE CYLINDER •... - Page 5 Burner Operation & Ignition System Check 1. Open the Lid of the barbecue before attempting to LCC27 Cylinder light the burner. Connection Device 2. Turn the control knobs clockwise to “OFF” position. 3. Connect the regulator to the gas bottle. Turn the gas LCC27 Regulator LCC27 Gas supply “ON”...
-
Page 6: Care And Maintenance
CARE & MAINTENANCE WARNING Care & Maintenance Beware of spiders and wasps. Burners should be As with all appliances, proper care and maintenance inspected and cleaned periodically. will keep them in top operating condition and prolong their life. Your new gas barbecue is no exception. By Should the burner extinguishes for any reason, turn following these cleaning procedures on a timely basis, off the control knob and the cylinder gas valve. - Page 7 Location of your Barbecue General Cleaning of Painted Surface DO NOT use your barbecue in garages, porches, sheds, When cleaning your BBQ use a mild dish soap combined breezeways, or other enclosed areas. Your barbecue is to with warm water and a microfiber cloth to clean the be used OUTDOORS.
-
Page 8: Routine Care
CARE AND CLEANING OF After cleaning applying a thin coating of ‘light oil’, for example baby oil, will also help protect the stainless steel STAINLESS STEEL surface from the elements. Stainless steel parts of this appliance are made from 304 Stubborn Stains and Corrosion Spots &... -
Page 9: Product Dimensions
PRODUCT DIMENSIONS 609mm 321mm (FRONT/REAR VIEW) (SIDE VIEW) FEET ADJUSTMENT Lowest Position Highest Position 278mm 522mm 609mm BENCH CUT-OUT DIMENSIONS Feet Adjustment: 4 adjustable feet are supplied with the BBQ. Please ensure all 4 feet are attached to the BBQ for height adjustment. If you plan to install the drop in BBQ in our Alfreco Plus BBQ (TOP VIEW) cabinet module, please adjust the feet of the BBQ so that... -
Page 10: Natural Gas Conversion
NATURAL GAS CONVERSION Conversion ONLY to be done by an authorised person. Overall Dimensions TO BE INSTALLED ONLY ON OR IN A NON- COMBUSTIBLE ENCLOSURE Length Width Height Note: Recommended clearances must be maintained. BQ2027 GAS PIPING BQ2027BL 609mm 321mm 236mm 1. -
Page 11: Safe Appliance Locations
SAFE APPLIANCE LOCATIONS Within a partial enclosure that includes an overhead cover and no more than two walls This appliance shall only be used in an above ground (see Example 2 & 3). open-air situation with natural ventilation, without Within a partial enclosure that includes an overhead stagnant areas, where gas leakage and products of cover and more than two walls, the following will apply: combustion are rapidly dispersed by wind and natural... - Page 12 For any queries or assistance call Customer Service (Australia Only) 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm EST Do not return to place of purchase. Keep your purchase receipt, this will be required to make any claims under the 5 year warranty.
