Summary of Contents for Furniture of America HFW-1697C6-TR
- Page 2 CHECK BEFORE STARTING Are you missing anything? Check out our Quick Tips! Double-check all parts, hardware and We recommend reviewing the pre-assembly accessories listed are all accounted handouts. Even experts need a refresher now and for. then! Prep Time! Should we send any replacements? Please review the assembly instructions and all Are there any irregularities or flaws in the diagrams prior to assembling.
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Note : Every cam lock bolt must have a cam lock connector in order to fasten the cam bolt cam lock parts together. screwdriver Screw the cam Insert the cam bolt into the bolt into panel. bolt hole of joint panel.
- Page 6 TOWER CABINET PARTS 2PCS 2PCS 2PCS ACCESSORIES HARDWARE 3SETS 2PCS 22PCS 22PCS 42PCS 4PCS 0.8" (8x30) 2.2" 22PCS 1SET 2SETS 1SET 4PCS 1.2" spring 1SET 4PCS 8SETS 0.5" 1.2" 0.7" 6 / 19...
- Page 10 Must have a dab of glue (#A1) onto these two dowels (#3).
- Page 11 Note: Wooden dowels (#3) on panel (#R) should be facing forward.
- Page 14 1. Align drawer to the product. 2. Insert the drawer at an angle. Ensure that the back drawer panel is behind dowels (#3). 3. Once aligned, slided drawer straight in.
- Page 18 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the product wobbles or feels loose, double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
- Page 19 19 / 19...
