Page 1: User Manual
User Manual TLS-3A Telephone Line Simulator 40-400-00010, Rev. B Covers Model TLS-3A-01 Teltone Corporation 22121-20th Avenue SE Bothell, Washington 98021-4408 USA Phone: 1-800-426-3926 or 425-487-1515 Fax: 425-487-2288 E-mail: info@teltone.com Website: www.teltone.com... - Page 2 This page intentionally left blank.
-
Page 3: Table Of Contents
Contents Introduction ... 3 1. Connectors and Lights ... 4 2. How to Install the TLS-3A ... 5 3. How to Operate the TLS-3A ... 6 4. Specifications ... 8 5. Warranty and Service ... 9 TLS-3A-01 Telephone Line Simulator... - Page 4 Copyright © 1995 Teltone Corporation. Teltone is a registered trademark of Teltone Corporation. Teltone Corporation 22121-20th Avenue SE...
-
Page 5: Introduction
Either telephone can be used to call the other line. In other words, the TLS-3A is a simple telephone network in a box. When a telephone connection is not available, or when installing a... -
Page 6: Connectors And Lights
The green Power indicator alternates between full and half brightness when the TLS-3A is operating. If the Power indicator is dark, no power is connected to the TLS-3A. If it lights, but does not flicker, the TLS-3A’s internal processor is not working properly. -
Page 7: How To Install The Tls-3A
2. How to Install the TLS-3A Figure 2 Typical TLS-3A Installation The TLS-3A works with analog loop start telephone sets only. It will not work with ground start, proprietary, or digital phone sets. Follow these steps to install the TLS-3A: 1. -
Page 8: How To Operate The Tls-3A
3. How to Operate the TLS-3A 40-400-00010, Rev. B The TLS-3A has one talk path between the two lines. When a telephone connected to either line goes off-hook while the other is still on-hook, the off-hook telephone receives dial tone. If the other telephone is already off-hook, the second telephone off-hook will not receive dial tone (silence). - Page 9 A dialing error occurs when less than 7 digits are dialed or if the first digit is a 1 or 0 and less than 11 digits are dialed. The TLS-3A will issue a reorder tone (aka Fast Busy) approximately 8 seconds after the last DTMF digit is entered if a dialing error occurs.
- Page 10 Use one of the two- or three-digit telephone numbers assigned to the line you want to call, or use any seven-digit telephone number. Like the public telephone network, the TLS-3A will not accept a seven-digit number with a 1 or 0 as the first digit. Such a number produces a reorder tone.
-
Page 11: Specifications
DTMF tone on/off >40 ms Talk path attenuation 6 dB (nominal) On/off-hook detect <6 mA = on-hook >18 mA = off-hook Off-hook loop current >25 mA with 400 ohms total loop resis- tance On-hook detect >400 ms TLS-3A-01 Telephone Line Simulator... -
Page 12: Warranty And Service
Return Procedures If a unit is found to be defective, contact Teltone Repair Order Entry at 1-800-426-3926 or 425-487-1515 to obtain a Material Return Authori- zation (MRA) number. When returning units, provide the following...
