- Page 1 ISDN Line Simulator ILS-C User’s Manual 40-400-00012, Rev. E...
- Page 2 Note This manual covers Models ILS-C-01 & ILS-C-02. Copyright Notice Copyright © 1996 - 2003 Teltone Corporation All Rights Reserved Trademarks Teltone is a registered trademark of Teltone Corporation. Windows is a registered trademark of Microsoft Corporation. Other company and product names may be trademarks or registered trademarks of their respective owners.
-
Page 3: Table Of Contents
Introduction...1 Unpacking ...1 Chapter 1: Quick Start ...2 ILS-2000 Operation ...5 What To Read Next ...6 Chapter 2: ISDN-BRI ...7 Technology Overview...7 Layer 1 - Physical Operation ...7 U Reference Point...7 Network Termination-1 (NT-1)...8 S/T Reference Point...8 Terminal Adapters ...8 Layer 2 - Data Link Operation...8 Packet Addressing ...8 TEI Assignment ...9... - Page 4 Call Control ...30 Configuration...32 Reference Documents ...33 Revision History ...35 Warranty and Service...36 Warranty Information ...36 Return Procedures...36 Technical Assistance...36 Maintenance...36 Cleaning...36 Servicing ...36 Specifications...37 Glossary ...39 40-400-00012, Rev. E...
- Page 5 List of Figures Figure 1. Configuration Software ...12 Figure 2. U Interface Operation ...24 Figure 3. S/T Interface Operation ...24 Figure 4. Dimensions and Panels...25 Figure 5. Call Control Message Exchange Example ...27 40-400-00012, Rev. E...
-
Page 6: Important User Safety Instructions
IMPORTANT USER SAFETY INSTRUCTIONS When using this product, basic safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock, and injury to persons. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. -
Page 7: Regulatory Compliance
REGULATORY COMPLIANCE FCC Part 15 Class A Notice: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 9: Introduction
2B+D, that is, two full duplex Bearer channels and one full-duplex Data channel combined onto a single pair of wires. The Teltone ILS-2000 (ISDN Line Simulator) is two ISDN BRI connections in a portable unit. The user interface is either a “U” or an “S/T” connection using an RJ45 modular plug. -
Page 10: Chapter 1: Quick Start
ISDN Line Simulator User’s Manual CHAPTER 1: QUICK START The ILS-2000 Line Simulator is easier to operate than most communications devices designed for ISDN-BRI applications. It functions in the background, providing two lines of end-to-end ISDN-BRI service. Because the Simulator was designed primarily for people who demonstrate, functionally test, or configure ISDN-BRI devices, you do not need to understand ISDN protocols or read the entire User’s Manual to use it. - Page 11 Step 8 Step 9 NOTE: The instructions may specify that your communications device requires power from a secondary source, such as a wall adapter. It may not be necessary to connect a power source when using the Simulator. See Specifications for more details. Step 10 Determine which ISDN-BRI interface is compatible with your IMPORTANT: Either or both Simulator ports may be used during simulation, but only one interface (S/T or U) may be selected at each...
- Page 12 ISDN Line Simulator User’s Manual Step 12 Next, you may be instructed to program one or more First device at Port 1: Second device at Port 1: First device at Port 2: Second device at Port 2: NOTE: Not all communications devices are programmed with a SPID or DN.
-
Page 13: Ils-2000 Operation
IMPORTANT: Some devices let you change the ISDN protocol to support the type of ISDN switch the telephone company has installed. If you change your device’s protocol, you must change the Simulator’s Switch Type configuration to match. If you change any one device’s ISDN protocol, then all devices connected to the Simulator must be configured for that protocol. -
Page 14: What To Read Next
ISDN Line Simulator User’s Manual devices, particularly those that support video conferencing or LAN adaptation, need both B Channels for a single call. If your communications device requests any of these services, the Simulator provides the necessary processing and resources. A special case, which uses the D Channel and X.25 packet data transmission is also supported and may occur while both B Channels are connected. -
Page 15: Chapter 2: Isdn-Bri
CHAPTER 2: ISDN-BRI Technology Overview The Integrated Services Digital Network - Basic Rate Interface (ISDN-BRI) is a technology that gives individuals affordable access to the world’s largest digital network using the copper wire currently entering their home or office. With ISDN-BRI, users may connect almost any form of personal communications device to a single phone line and establish multiple, simultaneous voice and data connections at speeds up to 128 thousand bits per second. -
Page 16: Network Termination-1 (Nt-1)
ISDN Line Simulator User’s Manual Network Termination-1 (NT-1) The U Interface terminates at a device called a Network Termination-1, or NT-1. This device converts the U Interface to an S/T Interface. It also permits loop back and testing by the telephone company and a means of routing local power to devices previously designed to receive power from the line, such as a telephone. -
Page 17: Tei Assignment
SAPI 63 addresses the Signaling Access Controller (SAC), which negotiates and assigns the second packet address number, called a Terminal Endpoint Identifier or TEI. The TEI is a unique number for each Terminating Equipment on a particular line. For example, if a packet addressed to SAPI 0 and TEI 3 is sent to four ISDN devices connected to a single line, only the Call Control function (SAPI 0) of the device assigned TEI 3 will acknowledge and process the packet. -
Page 18: Service Profile Id (Spid) Assignment
ISDN Line Simulator User’s Manual and AT&T’s 5E series. The Call Control standard to which these switches are being upgraded and to which current switches are designed is called National ISDN-1. The European Economic Community, (ECC) is currently consolidating various national versions to comply with the European Telecommunications Standards Institute (ETSI) protocol. -
Page 19: Chapter 3: Provisioning And Operation
CHAPTER 3: PROVISIONING AND OPERATION The instructions for many ISDN-BRI communications devices may specify Provisioning required of the telephone company. Provisioning is a means of configuring the ISDN switch so it knows what kind and how many calls communications devices can support, up to the limits imposed by ISDN-BRI technology. -
Page 20: Figure 1. Configuration Software
ISDN Line Simulator User’s Manual installation, a message may appear saying that a certain file could not be installed because it is already installed and in use. Continue with the installation until complete. A Program Window will be created that is labeled ILS Configuration and includes an icon labeled ILS Configuration. -
Page 21: General Operation
General Operation Provisioning of features using the ILS-2000 configuration software allow the user to select from several stored configurations, as well as allow the user to store other configurations as needed. If a stored configuration is selected, and any feature is changed, the Configuration Name changes to (Untitled). If you attempt to exit the program without saving the configuration, you will be prompted to do so. -
Page 22: D Channel X.25
ISDN Line Simulator User’s Manual Important: When the Simulator configuration is changed, always reinitialize any connected devices. All devices must be compatible with the selected switch protocol. D Channel X.25 Packet Handling Function (PHF) ISDN-BRI permits the use of the 16Kbs D Channel, usually reserved for ISDN signaling, to exchange X.25 LAP-B user data with a host system. -
Page 23: B Channel Provisioning
STEP 3 STEP 4 STEP 5 NOTE: Some terminals require that you send an X.25 RESET command manually before the terminal will establish a PVC connection. B Channel Provisioning Some ISDN-BRI communications devices, usually LAN gateways and other Terminal Adapters, do not use ISDN Call Control to establish calls or allocate B Channels. -
Page 24: Caller Id
ISDN Line Simulator User’s Manual To change the Phantom Power setting, follow these steps: STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 Caller ID This service, also referred to as Automatic Number Identification (ANI) or Calling Line Identification (CLID), allows Terminating Equipment with display support or call screening features to identify the calling party before accepting the call. -
Page 25: Electronic Key Telephone Service (Ekts)
an error. Usually the text indicates the name and Directory Number of the called or calling party. If the Terminal uses Call Appearances, the Call Appearance identifier is also displayed for the current call. Some devices specify a switch provision indicating that the Display feature be enabled or disabled. -
Page 26: Multi-Point
ISDN Line Simulator User’s Manual Information Element unique to that terminal. The EKTS terminal stores the TEI in its non-volatile memory. All subsequent SETUP messages sent to that line may then address all, some, or only one device using the TEI. If the communications device does not store a TEI, then the Simulator’s EKTS setting should be disabled. -
Page 27: Key Hold
Some devices permit programming of the Directory Number(s) into the terminal and associate one or more Call Appearances to manage each DN. The terminal indicates incoming calls using the received Called Party Number Information Element and lighting the first unused (idle) Call Appearance assigned to that DN. -
Page 28: Additional Call Offering (Aco)
ISDN Line Simulator User’s Manual If your communications device does not support these services, then the Simulator’s HDTC setting may be disabled. STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 Note: This setting is not available when EKTS is disabled. While the Simulator recognizes the CONFerence and TRANSfer call control messages, it does not perform these services at this time. - Page 29 ISDN Line Simulator User’s Manual STEP 5 Remove all communications devices from the Simulator and press the DOWNLOAD button. An automatic RESTART is issued as part of the DOWNLOAD. NOTE: This setting is not available when EKTS is disabled. 40-400-00012, Rev. E...
-
Page 30: Chapter 4: Simulator Operation
ISDN Line Simulator User’s Manual CHAPTER 4: SIMULATOR OPERATION This section refers to the operation of the ILS-2000 in more detail. Many users of the Simulator will not need to read this section. When power is first applied to the Simulator, a self-test is performed and the interfaces are initialized. -
Page 31: Reinitialize
ISDN Line Simulator User’s Manual However, some terminals are designed to report link failures to their Call Control Layer, which may then attempt to recover. If their recovery procedure is not satisfied before various timers expire, they may clear (or dump) any active calls. -
Page 32: Chapter 5: Reference
ISDN Line Simulator User’s Manual CHAPTER 5: REFERENCE Status Indications Figure 2 shows the ILS-2000 ISDN Line Simulator configured for U Interface operation. Connecting to the U Interface allows synchronization of any communications devices connected downstream. The Simulator’s U interface status is signaled by the U-SYNC LED, which changes from a blinking green LED to a solid green LED after synchronization is completed. -
Page 33: Dimensions And Panels
Dimensions and Panels Figure 4 shows the unit’s front and rear panels. 230VAC Operation The ILS-2000 is configured at the factory for 115VAC operation using a 300 mA fuse. To enable 230VAC operation replace the 300 mA fuse (and spare) with a 150 mA fuse (2 provided) and move the Voltage Setting switch to 230V. - Page 34 ISDN Line Simulator User’s Manual Message codings unique to a particular switch vendor or protocol are followed by the applicable switch type identifier. Not all recognized messages are performed by the Simulator, and are indicated with (*). For example, while the Simulator will recognize the AT&T CONFerence message, it will return a CONFerence REJect message in reply, using the appropriate Information Element Cause code to indicate the service is not available.
-
Page 35: Typical Call Control Sequence
Typical Call Control Sequence Figure 5 illustrates a common method for depicting a Call Control (Layer 3) message exchange, end-to-end, for setting up and releasing a successful call. The near-end or originating caller is shown on the left, while the far-end or terminating caller is on the right. - Page 36 2, while User 1 sends RELease COmplete to the switch, ending the call and releasing all allocated resources. EXT Clock NOTE: Contact Teltone for details regards bonding of B channels. Connected from the "EXT CLOCK OUT" of another Teltone ISDN Simulator for bonding B channels.
-
Page 37: Troubleshooting
Troubleshooting Physical Interface Problem: U-SYNC LED does not light. Solution: Solution: Solution: Solution: Solution: Problem: TE indicates no S/T synchronization. Solution: Solution: Solution: Problem: How do I loopback the S/T interface? Solution: Problem: How do I loopback the U interface? Solution: 40-400-00012, Rev. -
Page 38: Tei Assignment
ISDN Line Simulator User’s Manual TEI Assignment Problem: The TE cannot initialize TEI Solution: Solution: Solution: Solution: Problem: The TE indicates that TEIs are periodically Solution: Solution: Solution: Problem: My CPE device requires a TID to operate Solution: Example: For a CPE device connected to port 1, which requires a TID to Call Control Problem: Caller ID doesn’t work. - Page 39 Problem: TE indicates an error when attempt is Solution: Solution: Solution: Solution: Solution: Solution: Solution: Problem: Calls are routed to the same DN when a Solution: Solution: Solution: Problem: Every call indicates no channel available or Solution: Solution: Solution: Solution: Solution: 40-400-00012, Rev.
-
Page 40: Configuration
ISDN Line Simulator User’s Manual Configuration Problem: How do I select Bearer Capability or call Solution: Problem: TE continues to reinitialize (in some cases Solution: Solution: Solution: Problem: Cannot place X.25 call by dialing a Solution: Problem: I have problems using my Motorola Solution: Problem: Electronic key telephone drops calls when Solution:... -
Page 41: Reference Documents
ISDN Line Simulator User’s Manual Reference Documents The following specification documents, among others, have been used for the development of the ILS-2000 ISDN Line Simulator. ITU-T Recommendation Q.931, ISDN Call Control, Layer 3 ITU-T Recommendation Q.921, ISDN LAP-D Protocol, Layer 2 ANSI T1.601, ISDN Physical Layer Specifications, Layer 1 National ISDN Generic Guidelines for ISDN Terminal Equipment on Basic Rate Interface, Bellcore SR-NWT-002661... - Page 42 ISDN Line Simulator User’s Manual Northern Telecom, Inc. 4001 East Chapel Hill - Nelson Hwy P.O. Box 13010 Research Triangle Park, NC 27709 (800) 684-2273 40-400-00012, Rev. E...
-
Page 43: Revision History
ILS-1000 cannot be upgraded to an ILS-2000. Initial Release ILS-C-02 The ILS-C-02 replaces the ILS-C-01. Firmware Version 3.50 Bug Fix: X.25 PVD D-Channel changed from 0 to 1. Bug Fix: Configuration software incorrectly identified the unit as an ILS- 1000. -
Page 44: Warranty And Service
Teltone warrants this product to be free of defects in workmanship and materials for a period of 1 year. Return Procedures If a unit is found to be defective, contact Teltone customer service to obtain a RMA (Return Material Authorization) number and shipping instructions. When returning units, provide the following information: •... -
Page 45: Specifications
SPECIFICATIONS AC Power Input Input Voltage (Selectable via rear panel slide switch) Frequency Current Connector Output to power external devices U Interface Protocol Maximum cable drop S/T Interface Protocol Maximum cable drop Power Source 1 Power Source 2 Maximum power source voltage per ANSI T1.605 is 56.5 VDC Minimum power source voltage per ANSI T1.605 is 32.0 VDC Maximum of 6 Watts available power for external devices. - Page 46 ISDN Line Simulator User’s Manual Mechanical Specifications Dimensions Weight Regulatory Compliance Safety United States Canada United States 2.5" H x 10.0" D x 10.5" W 4 lb 15 oz. UL 1459 CSA C22.2 No. 225-M90 FCC Part 15, Class A 40-400-00012, Rev.
-
Page 47: Glossary
ISDN Line Simulator User’s Manual GLOSSARY 5ESS Medium-to-Large digital end office switch (Class 5). Manufactured by AT&T and introduced in 1981. First AT&T switch to offer Basic Interface ISDN (with the software load 5E4.2) in the 1980’s. AMI (Alternate Mark Inversion) A Layer 1 line-code scheme used in T1 carrier and ISDN PRI. - Page 48 ISDN Line Simulator User’s Manual Asynchronous Transmission Data is sent character by character. The receiver and transmitter are synchronized for each individual character via a start and stop pulse. Asynchronous transmission is normally found on dial up circuits, usually at speeds between 300 and 19,2000 bps. B Channel A 64 Kb/s (DS0) ISDN user-to-network channel.
- Page 49 ISDN Line Simulator User’s Manual CCITT (Consultative Committee on International Telephone & Telegraph) Comite Consultatif International Telegraphe et Telephone (French for “International Telephone and Telegraph Consultative Committee”). Formerly, an international standards body charted by the United Nations. Now called ITU-T (International Telecommunication Union-Telecommunication sector.) Centrex Service created by software in the telephone company’s local office which simulates...
- Page 50 ISDN Line Simulator User’s Manual ETSI (European Telecommunications Standards Institute) European Telecommunications Standards Institute. Formed in 1988 by the member administrations of CEPT to broaden European Standards participation to include manufacturers, research centers, private service providers, and user associations, as well as Post and Telecommunications Administrations.
- Page 51 ISDN Line Simulator User’s Manual ITU (Internal Telecommunications Union) The principal international standards organization chartered by the United Nations and supported by treaty agreements among member nations. The ITU is the parent organization for the ITU-T (Formerly CCITT) and the ITU-R (formerly CCIR). In addition, the ITU has two other permanent organs: the International Frequency Registration Board (IFRB), and General Secretariat;...
- Page 52 ISDN Line Simulator User’s Manual Loop Pair of wires connecting the subscriber to the Telephone Company central office. Modem (Modulator/Demodulator) A device which converts data signals into a form suitable for transmission over a communications medium and which recovers the data from the received communication link.
- Page 53 ISDN Line Simulator User’s Manual Packet A grouping of data, typically from 1 to 512 characters in size which usually represents one transaction. A packet is always associated with an address header and control information. The term “Packet” is usually used to refer to a Layer 3 data unit in X.25. PBX (Private Branch eXchange) A customer premises telephone switch connecting 20 or more station sets to each other to the public network and possibly to a private network.
- Page 54 ISDN Line Simulator User’s Manual SS7 (Signaling System Number 7) An international, standard, common channel signaling system. SS7 is used between public network switches (replacing per-trunk signaling), local exchange carrier switches, interexchange carrier switches, and (increasingly) between local and interexchange carrier networks. Switch Generic term for machines that switch telephone calls from/to telephones and/or trunks.
- Page 55 ISDN Line Simulator User’s Manual U Interface A two-wire interface required by the FCC (not the ITU-T) between the Local Exchange Carrier and the customer’s NT1. Specification completed during 1Q87 by ANSI T1D1.3. X.25 ITU-T recommendation specifying how user equipment (DTE) is to connect to a public, packet-switched network (DCE).
