Teltone TLE-A User Manual

Telephone line emulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Telephone Line Emulator
TLE-A
User's Manual
40-400-00020, Rev. M

Advertisement

Table of Contents
loading

Related Manuals for Teltone TLE-A

Summary of Contents for Teltone TLE-A

  • Page 1 Telephone Line Emulator TLE-A User’s Manual 40-400-00020, Rev. M...
  • Page 2 Note This manual covers Model TLE-A-01 and software modules TLE-ADV (Advanced Emulation), TLE-INTL (International), and TLE-ICID (International Caller ID). Copyright Notice Copyright © 1997 - 2003 Teltone Corporation All Rights Reserved Trademarks Teltone is a registered trademark of Teltone Corporation.

  • Page 3: Table Of Contents

    Overview ...1 Standard Unit Features (TLE-BASE) ...1 Options ...1 International Software Module (TLE-INTL)...1 International Caller ID Software Module (TLE-ICID) ...2 Advanced Emulation Software Module (TLE-ADV) ...2 Automated Test Software Module (TLE-TEST)...2 TLE Front and Rear Panels ...3 Getting Started ...4 Check your TLE Package ...4 Product Registration ...4 Setting up the TLE...5...
  • Page 4 Germany Defaults ...54 Greece Defaults ...55 India Defaults ...56 Ireland Defaults ...57 Italy Defaults ...58 Japan Defaults ...59 Korea Defaults ...60 Netherlands Defaults...61 Norway Defaults...62 Singapore Defaults...63 Spain Defaults...64 Sweden Defaults ...65 Switzerland Defaults ...66 UK Defaults ...67 US/Canada defaults ...68 International Caller ID Software Module (TLE-ICID)...69 Introduction ...69 Overview - TLE-ICID...69...

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using this product, basic safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock, and injury to persons. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3.

  • Page 6: Regulatory Compliance

    REGULATORY COMPLIANCE FCC Part 15 Class A Notice: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 7: Overview

    Overview The Teltone Telephone Line Emulator (TLE) is a user-configurable four-port analog telephone emulator, enabling simulation of many public switched telephone network (PSTN) conditions. The TLE is designed to work between 100 VAC and 240 VAC, enabling the TLE to be used worldwide. There is an International Software Module, an Advanced Simulation Software Module, an Automated Test Software Module, and an International Caller ID Software Module available.

  • Page 8: International Caller Id Software Module (Tle-Icid)

    Telephone Line Emulator User’s Manual International Caller ID Software Module (TLE-ICID) This module is an upgrade to TLE-INTL Software Module. • Supports Multiple Caller ID formats • • • • • Default Country Caller ID Configurations for: • • • •...

  • Page 9: Tle Front And Rear Panels

    Telephone Line Emulator User’s Manual TLE Front and Rear Panels Figure 1. Telephone Line Emulator Front and Rear Panels 40-400-00020, Rev. M...

  • Page 10: Getting Started

    9-pin male to 25-pin female adapter (1 supplied with each TLE unit) • 7.5 foot 110 VAC power cord (1 supplied with each TLE unit) If any of the items you ordered are missing or damaged, contact Teltone’s Customer Service at 425-951-3388. Product Registration Please complete the Product Registration card and mail it to Teltone Corporation.

  • Page 11: Setting Up The Tle

    The TLE uses a universal power supply that operates from 100-240 VAC, 50/60 Hz. Connect AC power to the TLE, then turn the rear panel power switch to the ON position. Grounding is assured by using the appropriate (approved) power cord.

  • Page 12: Tle Operation

    Telephone Line Emulator User’s Manual Windows 3.1 and Windows 3.11 (Windows for Workgroups) 1. Insert the CD-Rom into the drive. 2. Using the Windows Program Manager, Select File, Run. 3. Type in your drive designator, followed by Setup.exe example: r:\setup.exe 4.
  • Page 13 Telephone Line Emulator User’s Manual Figure 3. TLE Call Processing Flowchart (Part 1) 40-400-00020, Rev. M...
  • Page 14 Telephone Line Emulator User’s Manual Figure 4. TLE Call Processing Flowchart (Part 2) 40-400-00020, Rev. M...

  • Page 15: Basic Calling Operation

    Basic Calling Operation The Teltone TLE provides dial tone (Normal – default), or Ringdown (Hotline), or a quiet battery feed (Silent), when a device goes off-hook and draws sufficient loop current. When dialing is detected, DTMF or Pulse (aka Rotary dialing), dial tone stops. If an invalid sequence is dialed, the TLE will issue an Invalid Number Response of SIT + Audio (default), SIT repeating, Busy, Reorder, Ringback, Silence, or Audio.

  • Page 16: Configuring The Tle

    Telephone Line Emulator User’s Manual Configuring the TLE Using the Configuration Software, different configurations can be saved to download to the TLE. A configuration contains all the programmable parameters of the TLE. The standard TLE (TLE-BASE) unit can have 2 different configurations, while the add-on software modules can have up to 16 different configurations.

  • Page 17: Main Tle Screen

    a three beep confirmation tone (if enabled), and the display will show the new configuration following an initialization sequence. If an error in the entry occurs, the TLE will respond with a single beep error response. Selecting Active Configuration using the serial port The Active Configuration may be selected via the serial port with PC_TLE software 2.00 or greater.

  • Page 18: Copy Configurations

    Telephone Line Emulator User’s Manual configurations in the Configuration Set to the TLE. The Query button will query the settings for the current configuration in the TLE. The Query All button will query all of the stored configurations in the TLE. The Defaults button will reset any Configuration under edit to the factory default settings.
  • Page 19 Telephone Line Emulator User’s Manual Figure 7. Copy Line Screen 40-400-00020, Rev. M...

  • Page 20: Operational Screens

    Telephone Line Emulator User’s Manual Operational Screens Audio Line Monitor The Audio port on the front of the TLE is used to monitor the AC signals on any one of the lines of the TLE when this feature is enabled. Only one line may be monitored at a time. The audio line monitor port is a 3.5 mm miniature audio jack.

  • Page 21: Busy Tone

    of all recorded messages must not exceed the total length for the audio memory (8 seconds). Attenuation Attenuation is the loss of signal level. Attenuation values refer to the amount of attenuation compared to the original recording. Attenuation may be set from 0 dB to 60 dB in 1 dB increments. Busy Tone The Busy signal is an indication that the Called Line is off-hook and not available.

  • Page 22: Call Waiting

    Telephone Line Emulator User’s Manual Second Cadence on or off time may be set from 0 mS to 5000 mS in 5 mS increments, or may be set to 0 if only the First Cadence values are to be utilized. If the Second Cadence values are 0, the unit will repeat with the First Cadence values.
  • Page 23 Telephone Line Emulator User’s Manual Figure 10. Call Waiting Screen The Call Waiting signal has several variables, including: Disabled, Single Tone or Dual Tone, Type of Call Waiting Signal, and Cadence. Call Waiting Tone Levels and Frequencies Call Waiting Tones may be single or dual frequencies with individually adjustable amplitudes.

  • Page 24: Caller Id - Visual Message Waiting

    *50 102. The display for the called line will indicate VMW sent during the time when FSK is generated after the Open Switch Interval. Stuttered Dial Tone is issued to the called line until VMWI OFF is invoked or the Dial Access Audio Message is dialed.
  • Page 25 Telephone Line Emulator User’s Manual Figure 11. Caller - ID Visual Message Waiting Screen 1 Caller ID Time This may be set either by the user or can be read from the PC clock. The TLE maintains a real time clock only when power is on. Upon power up the date and time start at the time as set by this field.
  • Page 26 Telephone Line Emulator User’s Manual Caller ID Mode This feature allows the selection of the Caller ID Mode for each Line. The options include Multiple Message format (default), Single Message format, or Disabled. Select Name & Number This feature allows the selection of one of three different Groups of Names and Numbers (see Phone Numbers).
  • Page 27 Telephone Line Emulator User’s Manual Figure 12. Caller ID Visual Message Waiting Screen 2 CAS Tone CAS Tone is a CPE Alerting Signal; a Bellcore term for a tone used to alert CPE equipment of Call Waiting, asking for ACKnowledgement prior to sending Caller ID. The CAS Tone has several variables, including: Disabled, Single Tone or Dual Tone, Duration, and Time to Wait for Acknowledgement.

  • Page 28: Advanced Screen Telephony

    Telephone Line Emulator User’s Manual Open Switch Interval The Open Switch Interval is a form of DC signaling, sent during an on-hook state, prior to Visual Message Waiting. During this time, the -48 VDC is momentarily removed. Open Switch Interval may be set from 0 seconds to 5 seconds in 5 mS increments.
  • Page 29 On-hook time must exceed Hook Flash time. Hook Flash Detect Hook Flash, a.k.a. FLASH and Switch Hook Flash, is a loss of loop current for a specific duration that is used to request special features, such as Transfer, Conference, and Hold.

  • Page 30: Dial Tone

    The TLE issues a Second Dial Tone after a series of digits are dialed to emulate operation of a PABX or other switch platforms. (See Revert to Dial Tone phone number.) Other types of dial tones include Recall Dial Tone (an interrupted Dial Tone, a.k.a.

  • Page 31: Loop Parameters

    Impedance, Attenuation, and Loop Current. Impedance matching is important for many applications so that all signals sent to the switch network are absorbed and not reflected back to the caller. Attenuation is the loss in signal level (measured in dB) that occurs from one line to another.

  • Page 32: Miscellaneous

    Telephone Line Emulator User’s Manual Line Receive Attenuation This value is the attenuation of the audio signal received at a port. Line Receive Attenuation may be set from 4 dB to 60 dB in 1 dB increments. These settings only affect signals received from other lines.
  • Page 33 requesting version information from the TLE. After all valid and proper entries, a three beep sequence is issued. After an invalid entry, a longer single tone is issued. Rotary Dial Only Rotary Dial Only operation is to be used when there is a need to accept only Rotary Dialed (a.k.a.

  • Page 34: Phone Numbers

    Telephone Line Emulator User’s Manual Hunt Mode Hunt Mode is how the TLE determines which line will ring when the same Phone Number is programmed for multiple lines. The options include Ring All (default), Ring 1 Ring 1 When the unit is set to Ring All, all lines with the same phone number will ring. When it is set for Ring 1st Match, the TLE will only ring the first line which has this number programmed.
  • Page 35 Telephone Line Emulator User’s Manual Figure 17. Phone Numbers Screen Revert to Dial Tone The Revert to Dial Tone number is programmable from 0 to 16 digits in length. When this number is dialed a second dial tone is heard. Default is 9. Dial Tone - Test Number This is the telephone number dialed to access a continuous Normal Dial Tone as programmed in the Dial Tone screen.

  • Page 36: Port Configuration

    Call Progress frequencies, such as Dial Tone or SIT. Independent switch operation, ports 2 & 4 is a special mode to allow for more versatile programming of the TLE. When this mode is selected, the unit will operate with one configuration for ports 1 and 3 and a second configuration for ports 2 and 4.

  • Page 37: Reorder

    Clone Clone is used when configuring the TLE for 2x2 operation. Enabling this feature will clone (or copy) an exact duplicate of the settings for Lines 1 & 2 to Lines 3 & 4 so that the Edit Configuration is split into two identical setups. After the 2x2 Ports is selected, and the screen is closed (OK) the Clone feature is disabled.

  • Page 38: Ringing

    Telephone Line Emulator User’s Manual First Cadence off time may be set from 100 mS to 1000 mS in 5 mS increments. Second Cadence on time may be set from 100 mS to 1000 mS in 5 mS increments. Second Cadence off time may be set from 100 mS to 1000 mS in 5 mS increments. If the Second Cadence values are programmed to zero the unit will repeat the sequence with the first cadence values.

  • Page 39: Special Information Tones/Number Unobtainable Tone

    Cadence - Group 1, 2, 3 Cadence may be set for 1, 2 or 3 sequences from 0 to 3 seconds on and 0 to 10 seconds off in 5 mS increments. Ringback Ringback is the audible tone heard by a caller while ringing is applied to the called line. The TLE Ringback tone will match the Ring cadence of the Line called and is programmable as a single or dual frequency with programmable levels and is applied to all lines.

  • Page 40: Voice Messages

    The default message for Disconnect is: “Please hang up.” Dial Access The default for Dial Access is: “Today’s message is: Buy Teltone products.” Alternate The Alternate message is programmable with no default set. Figure 22. Voice Messages Screen 40-400-00020, Rev. M...

  • Page 41: References

    References Teltone has used the following references in the development of the TLE-BASE and the TLE-ADV software: Interface, Section 6.6, Issue 1, 12/94 Generic Requirements, Issue 2, 10/92 (CND), Issue 4, 12/92 Requirements (CNAM), Issue 1, 12/91 Generic Requirements FSD 01-02-2000, Issue 1, 9/93...

  • Page 42: Advanced Emulation Software Module (Tle-Adv)

    Note: This upgrade requires a software key that is generated by Teltone when the user supplies the TLE Unit ID and the TLE-ADV serial number to Teltone. The instructions are included on the Application Guide with the upgrade module.

  • Page 43: Metering Tones

    Satellite Delay Satellite Delay emulates the time it would take a signal to travel from one satellite earth station to the satellite then back to another satellite earth station. Satellite Delay can be set from 0 to 1000 mS in 125 µS increments (default is 0). Satellite Delay must be set for all lines with the same delay.

  • Page 44: Signal Level Measurement

    Telephone Line Emulator User’s Manual The tone cadence can be set from 0 to 10 seconds on, and 0 to 10 seconds off in 5 mS increments (default is 0.5 seconds on, 0.5 seconds off). If both lines have them enabled, Metering Tones are sent to both parties in the connection.

  • Page 45: International Software Module (Tle-Intl)

    Note: This upgrade requires a software key that is generated by Teltone when the user supplies the TLE Unit ID and the TLE-INTL serial number to Teltone. The instructions are included on the Application Guide with the upgrade module.

  • Page 46: References

    Telephone Line Emulator User’s Manual References Teltone has used the following references for each of the countries specified, however, you may find that certain parameters may be different for any specific country. It is up to the user to verify that operating parameters are valid for their application and usage.

  • Page 47: Country Screen

    Country Screen This screen copies the default values of the selected country into the current Edit Configuration. For example, from the Main screen, under Edit Configuration, select configuration “#16 DEFAULTS”. Then using the General Setup button or the Screens pull down menu, select Country.

  • Page 48: Call Waiting

    Australia, France, Germany, Netherlands, Singapore, Sweden, United Kingdom, and USA/Canada. Other country configurations may be available for download and import from the Teltone Web site at http://www.teltone.com. Requests for other country configurations should be directed to info@teltone.com.

  • Page 49: Metering Tones

    Metering Tones The BS6305 document (UK) states that “Meter pulses are normally provided only by special arrangement between the PTT and the user, but may be present whether or not the supply of them has been requested.” The other documents (ITU, Swedish TVT 8211-A 112E, Singapore TAS TS PSTN 1, etc.) make no mention about the circumstances under which meter pulses are provided.
  • Page 50 Telephone Line Emulator User’s Manual These tones are programmable as a single or dual frequency with programmable levels and is applied to all lines. With a selection of Single Tone the system will only generate the first tone. With a selection of Tone 1 + Tone 2 the system will generate both tones with the specified frequencies and amplitudes.

  • Page 51: Loop Parameters (Tle-Intl)

    Loop Parameters (TLE-INTL) Complex Impedance The TLE Loop Parameters were upgraded in the TLE-INTL module in TLE_PC software release Version 2.00. This upgrade, to the TLE Loop Parameters, has added complex impedance’s for Australia, Germany, and the United Kingdom. These parameters are loaded into the programmable SLIC used in the TLE.

  • Page 52: Australia Defaults

    Telephone Line Emulator User’s Manual Australia Defaults The settings for this country will be stored in configuration #2. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: Frequency: 425 Hz x 25 Hz (425 HZ modulated by 25 Hz) Level: -10 dBm Cadence:...

  • Page 53: Austria Defaults

    Austria Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Recall Dial Tone Special Dial Tone Ringing Tone Ringing Signal Busy Tone I Busy Tone II Congestion Tone SIT Tones Call Waiting Tone Metering Tones...

  • Page 54: Belgium Defaults

    Telephone Line Emulator User’s Manual Belgium Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Special Confirmation Special Dial Tone International Dial Tone Ringing Tone Ringing Signal Busy Tone Congestion Tone SIT Tones...

  • Page 55: Brazil Defaults

    Brazil Defaults The settings for this country will be stored in configuration #3. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: 40-400-00020, Rev. M Frequency: 425 Hz Level: -10 dBm Cadence: Continuous Frequency:...

  • Page 56: China Defaults

    Telephone Line Emulator User’s Manual China Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Second Dial Tone Ringing Tone Busy Tone Congestion Tone SIT Tone I SIT Tone II Number Unobtainable Call Waiting Tone...

  • Page 57: Denmark Defaults

    Denmark Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Special Dial Tone Ringing Tone I Ringing Tone II Ringing Signal I Ringing Signal II Busy Tone I Busy Tone II Congestion Tone I Congestion Tone II...

  • Page 58: Finland Defaults

    Telephone Line Emulator User’s Manual Finland Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Special Dial Tone Centrex Dial Tone (PBX) Ringing Tone Ringing Signal Busy Tone Reorder Tone SIT Tones 1400...

  • Page 59: France Defaults

    France Defaults The settings for this country will be stored in configuration #4. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: 40-400-00020, Rev. M Frequency: 440 Hz Level: -16 dBm Cadence: Continuous...

  • Page 60: Germany Defaults

    Telephone Line Emulator User’s Manual Germany Defaults The settings for this country will be stored in configuration #5. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: Frequency: 425 Hz Level: -14 dBm Cadence:...

  • Page 61: Greece Defaults

    Greece Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Ringing Tone Ringing Signal Busy Tone Reorder Tone SIT Tones/N.U.T. Call Waiting Tone Metering Tones Impedance: 600 Ω fff//fff is defined because some exchanges use the first frequency and is the default, and other exchanges use the second frequency.

  • Page 62: India Defaults

    Telephone Line Emulator User’s Manual India Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Ringing Tone I Ringing Tone II Busy Tone I Busy Tone II N.U.T.

  • Page 63: Ireland Defaults

    Ireland Defaults The settings for this country will be stored in configuration #6. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: 40-400-00020, Rev. M Frequency: 400 Hz Level: -12 dBm Cadence: Continuous...

  • Page 64: Italy Defaults

    Telephone Line Emulator User’s Manual Italy Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Special Dial Tone Ringing Tone Ringing Signal Busy Tone Reorder Tone SIT Tones Metering Tones Impedance: 600 Ω...

  • Page 65: Japan Defaults

    Japan Defaults The settings for this country will be stored in configuration #7. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: 40-400-00020, Rev. M Frequency: 400 Hz Level: -15 dBm Cadence: Continuous...

  • Page 66: Korea Defaults

    Telephone Line Emulator User’s Manual Korea Defaults The settings for this country will be stored in configuration #8. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: Frequency: 350 Hz + 440 Hz Level: -10 dBm Cadence:...

  • Page 67: Netherlands Defaults

    Netherlands Defaults The settings for this country will be stored in configuration #9. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: 40-400-00020, Rev. M Frequency: 425 Hz Level: -10 dBm Cadence: Continuous...

  • Page 68: Norway Defaults

    Telephone Line Emulator User’s Manual Norway Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Centrex Dial Tone Ringing Tone Ringing Signal Busy Tone Congestion Tone SIT Tones Call Waiting Tone Metering Tones Impedance: (120+820//110nF) Ω...

  • Page 69: Singapore Defaults

    Singapore Defaults The settings for this country will be stored in configuration #10. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: 40-400-00020, Rev. M Frequency: 425 Hz Level: -15 dBm Cadence: Continuous...

  • Page 70: Spain Defaults

    Telephone Line Emulator User’s Manual Spain Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Special Dial Tone I Special Dial Tone II Ringing Tone I Ringing Tone II Ringing Tone III Ringing Signal I Ringing Signal II...

  • Page 71: Sweden Defaults

    Sweden Defaults The settings for this country will be stored in configuration #11. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: *TLE-PC Version 3.00 or greater. 40-400-00020, Rev. M Frequency: 425 Hz Level:...

  • Page 72: Switzerland Defaults

    Telephone Line Emulator User’s Manual Switzerland Defaults To make the settings for this country available, follow the instructions in “Importing Additional Countries” on page 41. Description Dial Tone Ringing Tone I Ringing Tone II PBX Ringing Tone III Ringing Signal Busy Tone Reorder Tone SIT Tones/N.U.T.

  • Page 73: Uk Defaults

    UK Defaults The settings for this country will be stored in configuration #12. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: 40-400-00020, Rev. M Frequency: 350 Hz & 440 Hz Level: -12 dBm Cadence:...

  • Page 74: Us/Canada Defaults

    Telephone Line Emulator User’s Manual US/Canada defaults The settings for this country will be stored in configuration #1 and #13 through #16. Dial Tone: Busy Tone: Reorder Tone: Ringing Tone: Ringing: SIT or Number Unobtainable: Call Waiting Tone: Line Impedance: Line Reversal: Frequency: 350 Hz + 440 Hz...

  • Page 75: International Caller Id Software Module (Tle-Icid)

    The various Caller ID devices and telephones display the Caller ID information in different ways. Please refer to the technical documents supplied by the manufacturer for details. Teltone uses various technical references to determine the default values for specific countries. However, there are circumstances where a parameter may have several variations, or new standards may be announced.

  • Page 76: Details Of Operation

    Telephone Line Emulator User’s Manual contain the name of the calling party or other call details (Multiple Data Message Format, or MDMF). The TLE can emulate special Caller ID features (Private, Out of Area) and transmission errors (checksum error) by dialing a specific prefix prior to the telephone number. The following countries in the TLE-ICID module have the appropriate default values loaded for Caller ID.
  • Page 77 Type I Caller ID is an on-hook transmission. Type II Caller ID is an off-hook transmission, also known as SCWID or CIDCW. Type III Caller ID is an off hook interactive transmission, also known as ADSI (Analog Display Services Interface) or AST (Advanced Screen Telephony). The two message formats are Single Data Message Format (Calling Number delivery), and Multiple Data Message Format (Calling Name and Number delivery).
  • Page 78 Telephone Line Emulator User’s Manual Caller ID Configuration This is a per-line programmable parameter. Date and Time The date and time is sent by the TLE as Month, Day, Hour, and Minute. Normal Caller ID The Normal Caller ID transmission can be programmed for up to 9 parameter types. The Caller ID in Call Waiting format selection is the same as the Normal CID parameters, if enabled.

  • Page 79: Caller Id Timing Parameters

    Call Waiting Type Subscriber Alerting Signal (SAS) tone for Call Waiting is programmable with the following options: When Distinctive SAS tones are selected, the TLE will send this tone when the dialed phone number is greater than 7 digits. Otherwise, the normal (single) tone will be sent. Caller ID Timing Parameters The following timing parameters are programmable within the TLE-ICID module.

  • Page 80: Programming

    Telephone Line Emulator User’s Manual FSK Timing Parameters The following parameters are programmable in the TLE-ICID module: See the following section for more details. Programming The programming of the TLE-ICID operating parameters is supported using multiple screens. Call Waiting and Caller ID were once separate screens, but have been combined in the TLE-ICID Software Module.
  • Page 81 Reversal + Dual Tone Ring Burst Select the message format: SDMF (Single Data Message Format) MDMF (Multiple Data Message Format) Select the Alerting Sequence: Open Switch Interval (OSI) Ring Burst Dual Tone Reversal + Dual Tone Telephone Line Emulator User’s Manual...

  • Page 82: Caller Id And Cidcw Components And Sequence

    Telephone Line Emulator User’s Manual Call Waiting Options available are: If a valid Caller ID format is selected (Bellcore, Bellcore Plus, or ETSI FSK) is selected, and CIDCW / SCWID / Type II CID is enabled, then a CID transmission will occur if the proper DTMF acknowledgement tone (see Caller ID Miscellaneous Parameters Screen) is sent by a CID device within the proper time.
  • Page 83 Multiple Data Message Format MDMF format transmissions consist of the following messages for each type of call: Note: The following operation will only apply if the unit is configured for US/Canada operation; all other countries have as default, “Message Waiting” dial tone = continuous. If the ∗50 prefix plus a phone number is dialed, the TLE will issue stuttered (“Message Waiting”...
  • Page 84 Telephone Line Emulator User’s Manual Bellcore Plus ETSI FSK Calling = Test Call Calling = Unavailable or Unknown Calling = Virtual Private Network Calling Line Identity Calling Line Identity Private (E/B) Calling Line Identity Unavailable (E/B) Calling Party Name Calling Party Name Private Calling Party Name Unavailable Date/Time Dialable Directory Number (B/B+)
  • Page 85 MDMF Message Waiting Message Components Bellcore or Bellcore Plus 40-400-00020, Rev. M Calling = Ordinary Subscriber Calling = Payphone Calling = Priority Subscriber Calling = Test Call Calling = Unavailable or Unknown Calling = Virtual Private Network Calling Line Identity Calling Line Identity Private (E/B) Calling Line Identity Unavailable (E/B) Calling Party Name...

  • Page 86: Caller Id Miscellaneous Parameters

    Telephone Line Emulator User’s Manual ETSI FSK Caller ID Miscellaneous Parameters The TLE-ICID Software Module allows the user to program specific parameters for use in different standards and applications. These programmable parameters include setting the Caller ID Time, the Extension for Network Operator, a Network Message Status, three User Defined fields, the Private transmission Dial Prefix, the Out of Area Dial Prefix, and the DTMF Acknowledge digit for CIDCW.

  • Page 87: Phone Number Prefix And Group Selections

    Network Message Status Programmable as one of the following: Extension for Network Operator Defined as follows: User Defined Parameters Up to 3 User Defined single byte parameters may be defined. These are to provide for the future addition of parameter types currently reserved. For each parameter the user must provide a parameter Type byte and a parameter Value byte.

  • Page 88: Calling Party Name

    Telephone Line Emulator User’s Manual The TLE-ICID module allows the user to program parameters such as setting a 10 digit limit (Bellcore phone number display standard), a Number Prefix (used to support display of numbers beyond 16 digits), which Group of Phone numbers are used for Calling Line, Call Forward, and Redirect Number display, and the ability to program the Group 1 Name to be displayed.

  • Page 89: Caller Id And Call Waiting Tones

    Calling Line Group Assignment Call Forward Group Assignment Redirect Number Group Assignment Calling Line Prefix Enable Call Forward Prefix Enable Dialable Directory Prefix Enable Called Line Prefix Enable Note: Caller ID phones and adjunct units may display some unique characters based upon national character sets.

  • Page 90: Dtmf Cid Parameters

    Telephone Line Emulator User’s Manual CAS/Dual Tone Alerting The CPE Alerting Sequence (CAS) tone is an Alerting Signal sent down the telephone line to inform CPE that a CIDCW/SCWID message is waiting. This CAS tone is sent after the SAS tone and will wait for a DTMF ACKnowledgement before transmitting CID data. The CAS tone is programmable as Disabled, Single Tone, Tone 1 + Tone 2 or Tone 1 x Tone 2.
  • Page 91 The Information Code may be programmed to be any combination from 00 to 99. Currently Sweden uses 00 and 10 in their standard (see details below), with the balance reserved for future use. Any of the above modes may be overridden by dialing the prefix code ∗67 or ∗87 (default values) prior to the destination number.

  • Page 92: Timings

    Telephone Line Emulator User’s Manual The Row and Column signal levels are programmable from -6 to -60 dBm. The defaults of -12 dBm for the Row and -10 dBm for the Column tones are based on CEPT Recommendation, T/CS 46-02. Timings The DTMF tone timing is programmable from 0 to 1.0 Seconds ON and OFF in 5 mS increments.

  • Page 93: Dtmf/Fsk To Ring

    Telephone Line Emulator User’s Manual Dual Tone to FSK The time from the end of a Dual Tone Alerting Signal to the start of FSK is programmable from 40 mS to 5 seconds in 5 mS increments. OSI to FSK The time from the end of an OSI to the start of FSK transmission is programmable from 250 mS to 500 mS in 5 mS increments.

  • Page 94: Osi Duration

    Telephone Line Emulator User’s Manual OSI Duration The OSI is a form of DC signaling, sent during an on-hook state, prior to Visual Message Waiting. During this time, the -48 VDC is momentarily removed. OSI may be set from 0 seconds to 5 seconds in 5 mS increments.
  • Page 95 Telephone Line Emulator User’s Manual Repeat The Call Waiting Cadence may be repeated from 1 to 250 times. If Forever is selected the Call Waiting Cadence will be repeated until the originating caller goes on-hook. 40-400-00020, Rev. M...

  • Page 96: Australia Defaults

    Telephone Line Emulator User’s Manual Australia Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS) Reference Standard: Call Waiting Type: Line Impedance: 220 ohms + (820 ohms || 120 nF)
  • Page 97 Timers Ring Cadence Group 1 Ring Cadence Group 2 Ring Cadence Group 3 40-400-00020, Rev. M Ring end to FSK DTMF/FSK end to ring start OSI timer length On-hook channel Seizure On-hook Mark length Off-hook Mark length Ring burst Telephone Line Emulator User’s Manual 550 mS 200 mS 0 seconds, no OSI generated...

  • Page 98: France Defaults

    Telephone Line Emulator User’s Manual France Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS) Call Waiting Type: FSK frequency Caller ID Mode...
  • Page 99 Timers Ring Cadence Group 1 Ring Cadence Group 2 Ring Cadence Group 3 User message #1 User message #2 User message #3 40-400-00020, Rev. M Ring end to FSK DTMF/FSK end to ring start On-hook channel Seizure On-hook Mark length Off-hook Mark length Ring burst Telephone Line Emulator User’s Manual...

  • Page 100: Germany Defaults

    Telephone Line Emulator User’s Manual Germany Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS), Call Waiting Type: FSK frequency Caller ID Mode...
  • Page 101 Ring Cadence Group 3 User message #1 User message #2 User message #3 40-400-00020, Rev. M Telephone Line Emulator User’s Manual 1 sec on/1 sec off/1 sec on/ 3 sec off Set to: 13H,2;network status = 2 messages Set to: 13H,3;network status = 3 messages Set to: 13H,4;network status = 4 messages...

  • Page 102: Netherlands Defaults

    Telephone Line Emulator User’s Manual Netherlands Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS), Call Waiting Type: Caller ID Mode (Ringing) Dial Prefix for Private...

  • Page 103: Singapore Defaults

    Singapore Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS) Call Waiting Type: FSK frequency Caller ID Mode (Ringing) Normal CID Table Parameters (up to 9 maximum)

  • Page 104: Sweden Defaults

    Telephone Line Emulator User’s Manual Sweden Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS) DTMF row level DTMF column level DTMF on/off time...

  • Page 105: Uk Defaults

    UK Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS) CAS low tone: CAS high tone: CAS duration: CAS wait for acknowledge...
  • Page 106 Telephone Line Emulator User’s Manual Message Type for CID not associated with ringing Mode for CID not associated with ringing Parameters for CID not associated with ringing (up to 6 maximum) Timers Ring Cadence Group 1 Ring Cadence Group 2 Ring Cadence Group 3 User message #1 User message #2...

  • Page 107: Us/Canada Defaults

    US/Canada Defaults These items will be preset in configuration #9. Refer to the TLE-INTL section for more details. Dial Tone, Busy Tone, Reorder Tone, Ringing Tone, Ringing, SIT or Number Unobtainable, Call Waiting Tone (Subscriber alerting signal, SAS) Reference Standard: Call Waiting Type: Line Impedance: CAS low tone:...

  • Page 108: References

    Telephone Line Emulator User’s Manual Timers Ring Cadence Group 1 Ring Cadence Group 2 Ring Cadence Group 3 References ITU Fascicle II.2 Recommendation E.180, Supplement #2, 1/94 Technical Standard 002, Dec 1997, Australian Communications Authority British Standard BS 6305: 1992 ETSI 300-001, March 1992, ETSI, European Telecommunications Standard ETS 300 778-1, Sept.
  • Page 109 ETS 300 778-2, Jan. 1998, ETSI document T 11-12E, Netherlands Hoofddirectie Telecommunicatie en Post Singapore TAS TS PSTN 1, Issue 3 Rev 4, 1 April 1997 Analogue Calling Line Identity Presentation Facility for connection to Public Switched Telephone Network Swedish Specification TVT 8211-A 112E The following web site URL’s were used and are supplied for your convenience.

  • Page 110: Automated Test Software Module (Tle-Test)

    Telephone Line Emulator User’s Manual Automated Test Software Module (TLE-TEST) The TLE-TEST module for the TLE-A-01 replaces the TLE-BASE, TLE-ADV, and TLE- INTL software in the TLE hardware for those users who need total control over the operation of their Emulator. The TLE-TEST features/functions include the ability to control...
  • Page 111 Telephone Line Emulator User’s Manual Figure 43. Automated Test Screen DTMF Generation The DTMF Generation feature allows for the setting of the frequency, signal level, and on/off timing for the Row and Column tones generated by a DTMF keypad. These tone pairs include 1-9,0,#,∗,A,B,C, and D.

  • Page 112: Revision History

    Telephone Line Emulator User’s Manual Revision History Version 1.00 Version 1.01 Changes: Networked Operating Systems Win95 and WinNT use a copy of MSCOMM.VBX that is incompatible with Visual Basic 3.0 and caused an error to be displayed during startup of the Configuration software. Version 1.01 solves this problem. Additions: None Version 1.02 Changes: Corrected the Invalid Number Response in the Miscellaneous Screen to...
  • Page 113 A new feature is available as an item under the File menu option. This new option, Reconfigure, allows users who purchase the TLE-TEST module to switch between Automated Test operation and Standard operation. Also added is the ability to install an upgrade (such as TLE-ADV or TLE-INTL) while the TLE is not connected at the time of the installation.
  • Page 114 Telephone Line Emulator User’s Manual Version 3.00 Upgrades: TLE Help file upgraded. TLE-BASE - Copy Line feature added to Ringing screen for easier programming and the Edit Configuration number is now included as part of the Title Bar on every programming screen (in parentheses). Example: Dial Tone (1).
  • Page 115 Version 3.05 Changes: Incorporates all country configurations available into software install. Bug Fix: Run Time error occurred when all modules installed. 40-400-00020, Rev. M TLE_PC.EXE 9/25/01 TLE_PC V3.05 BIOS V1.00 V2.10 (TLE-TEST V2.30) V3.00 (TLE-TEST V2.20) Telephone Line Emulator User’s Manual...

  • Page 116: Troubleshooting

    Telephone Line Emulator User’s Manual Troubleshooting Note: Downloadable software updates are available on Teltone’s website at www.teltone.com. Please report any error messages not found in this section to Teltone Technical Support. Errors on Power-up Problem: Solution: Problem: Solution: Problem: Solution:...

  • Page 117: Informational And Error Messages

    A Line is reporting off-hook all the time. An internal component has been damaged causing the off-hook failure. The TLE must be returned to the factory for repair. Contact Teltone Customer Support for an MRA (Material Return Authorization) number. with defaults unavailable.
  • Page 118 Explanation: an upgrade to the TLE_PC software. For the latest version of TLE_PC software, see Teltone’s web site at www.teltone.com. Do you wish to reconfigure the unit to a compatible version now? The TLE_PC software has detected a combination of Boot Code, Microcontroller Code and DSP Code versions which are not listed in it’s...
  • Page 119 Error Message: File “filename not found!” (Audio File) Explanation: Error Message: Wrong File Type! File must be Mono 8.000 kHz 8-bit mu-law wave file. Explanation: Upgrade Error Messages Error Message: An upgrade to “upgrade type’ is available for this unit. Do you wish to Explanation: Error Message: Programming this unit requires an update to the TLE_PC Software.

  • Page 120: Telephone Wiring Variants

    Telephone Line Emulator User’s Manual Error Message: Port Timeout Error. Please check that the TLE is properly connected to Explanation: Error Message: TLE not responding. Retry? Explanation: File Errors Error Message: File “filename” is not compatible with the TLE that is currently Explanation: Error Message: File “filename”...
  • Page 121 Teltone TLE UK Phone 40-400-00020, Rev. M Telephone Line Emulator User’s Manual RJ-11 Plug (To TLE) Network Adapter RJ-11 Socket RJ-11 Plug Standard RJ-11 Cable (Twisted) RJ-11 Plug (To UK Phone) Figure 44. UK Phone Wiring Diagram Adapter 1.8 uF...

  • Page 122: Warranty And Service

    Teltone warrants this product to be free of defects in workmanship and materials for a period of 1 year. Return Procedures If a unit is found to be defective, contact Teltone customer service to obtain an RMA (Return Material Authorization) number and shipping instructions. When returning units, provide the following information: •...

  • Page 123: Ordering Information

    Ordering Information For details on how to order or to receive pricing information, call Teltone Customer Service at 425-951-3388. TLE-A-01 CA-7F CA-25F TLE-BASE TLE-ADV TLE-INTL TLE-ICID TLE-TEST 40-400-00020 40-400-00025 40-400-00020, Rev. M Telephone Line Emulator User’s Manual Four port, two voice path, test emulator with screen display.

  • Page 124: Specifications

    Telephone Line Emulator User’s Manual Specifications Telephone Interface Loop Current Battery Source Ringing Source Ring Source Accuracy Ring Trip Ring Cadence Ring Frequency Impedance Complex Impedances Insertion Loss Attenuation Off-hook Detect Time On-hook Detect Time On/Off-hook Detect Flash Line Reversal Forced Disconnect 10 to 70 mA in 1-mA increments ±10% 48 VDC ±5 V...
  • Page 125 Call Progress Tones Audible Ringback Dial Tone 1 and/or Tone 2 Busy Tone Reorder Tone 1 and 2 Special Test Tone On/Off duration Number Unobtainable tone Tone output options 40-400-00020, Rev. M Telephone Line Emulator User’s Manual Tone levels are referenced to selected impedance. Single or dual frequencies from 10 to 1000 Hz, 1-Hz resolution (unless otherwise noted) Amplitude range is -6 to -60 dBm...
  • Page 126 Telephone Line Emulator User’s Manual Dialing Characteristics Rotary Detection DTMF Detection Caller ID FSK tone level FSK low frequency (tone1) FSK high frequency(tone2) CAS tone level CAS tone 1 CAS tone 2 CAS Tone Duration Wait for ACKnowledgement VMWI Call Waiting Tone 1 Tone 2 Output level...
  • Page 127 Metering Tones Signal Level Measurement Accuracy Echo Time Level Level Accuracy Satellite Delay White Noise Source Level Accuracy Audio Monitor Port Connector Output impedance Frequency response Frequency gain Voice Messages AC Power Fuse (User Serviceable) Physical Dimensions Weight Temperature Range Humidity Altitude 40-400-00020, Rev.
  • Page 128 Telephone Line Emulator User’s Manual Regulatory Compliance Safety United States UL 3111-1 Canada CSA C22.2 No. 1010-1 European Union EN55022 Conducted & Radiated Emissions EN61000-3-2/3 Harmonic Emissions and Voltage Fluctuations EN61010 European Safety Requirements for Electrical Equipment for Measuring, Control, and Lab Use IEC 1000-4-2 Electrostatic Discharge Susceptibility (ESD) IEC 1000-4-3 Radiated Immunity IEC 1000-4-4 Electrical Transients...

  • Page 129: Glossary

    Call Progress Tone A tone sent from the switch to tell the caller of the progress of the call. Examples are audible ringing, re-order, busy, timing, etc.
  • Page 130 Telephone Line Emulator User’s Manual Customer Equipment, see CPE CEAS Customer Equipment Alerting Signal, see CAS. See Caller ID. CLIP Calling Line Identification Presentation, see Caller ID. C.O. Central Office, a term used to describe the central location of switching equipment. Customer Premise Equipment.

  • Page 131: Forced Disconnect

    Telephone Line Emulator User’s Manual DSCWID Spontaneous Call Waiting with ID and Disposition. Disposition is the ability of a screen phone to perform certain actions regarding the waiting call, such as play a voice message, send to voice mail, conference and others. Also known as Type 3 Caller ID. Forced disconnect Forced Disconnect is a method used by the telephone company to clear a line.
  • Page 132 Message Header and a Message Body containing parameter messages. Generic description is Name + Number Transmission. Open Switch Interval, a time when the DC battery is removed from Tip and Ring Polarity Reversal A line condition where the battery polarity is reversed from its current state...
  • Page 133 Telephone Line Emulator User’s Manual Terminal Equipment - see CPE TE-ACK Terminal Equipment Acknowledgement - see ACKStuttered Dial Tone Stuttered Dial Tone is a special dial tone consisting of an initial cadenced sequence (typically 10 tone bursts) followed by continuous tone. This is normally issued to notify a user that they have a voice mail message waiting.

  • Page 134: Index

    FSK Tone, 21 FSK Transmission TLE-ICID, 71 Group 1 Name, 20 Minimum Ring Off Time, 19 Mode, 20 Open Switch Interval, 22 Out of Area, 70 Private, 70 Select Name & Number, 20 Sequence, 19 Time, 19 40-400-00020, Rev. M...
  • Page 135 Timing Parameters-TLE-ICID, 73 DTMF, 73 FSK, 74 TLE-ICID, 69, 75, 86 TLE-INTL, 42 Transmissions DTMF - TLE-ICID, 71 FSK - TLE-ICID, 71 Type I Signaling TLE-ICID, 69 Type II Signaling TLE-ICID, 69 Visual Message Mode, 20 Visual Message Waiting, 18 Wait for Acknowledgement, 21 Caller ID and Call Waiting Modes, 75 Caller ID Standards...
  • Page 136 TLE-ADV, 36 echo, 36 satellite delay, 37 white noise, 36 Impedance Complex, 45 Loop Parameters, 25 Independent switch operation Ports 2 & 4, 30 India defaults TLE-INTL, 56 Information Code TLE-ICID, 85 Informational and Error Messages, 111 International Software Module (TLE-INTL), 39...
  • Page 137 Miscellaneous, 27 On/Off-hook Detect Times DC Signaling, 23 On-hook Channel Seizure TLE-ICID, 87 On-hook Mark Time TLE-ICID, 87 Open Switch Interval Caller ID, 22 Operational Screens, 14 Audio, 14 Busy Tone, 15 Dial Tone, 24 Loop Parameters, 25 Miscellaneous, 26...
  • Page 138 Telephone Line Emulator User’s Manual OSI Duration TLE-ICID, 88 OSI to FSK TLE-ICID, 87 Out of Area, 18, 19 TLE-ICID, 71, 72, 84 Overview, 1 TLE-ICID, 69 Phone Number, 82 Phone Numbers, 28 Busy, 29 Dial Tone, 29 Reorder, 29 Revert to Dial Tone, 29 Ringback, 29 Screen, 28...
  • Page 139 TLE-INTL, 45, 65 Sweep Tone TLE-TEST, 105 Switzerland defaults TLE-INTL, 66 Technical Assistance, 116 Technical Specifications Test Numbers Busy, 29 Dial Tone, 29 Reorder, 29 Ringback, 29 Special Test Tone, 30 Stuttered Dial Tone, 30 Test Tones Miscellaneous, 27 Front and Rear Panel, 3 Operation, 6 TLE-ADV, 2, 4, 18, 19, 39, 104, 107 Caller ID After Every Ring, 36...
  • Page 140 Telephone Line Emulator User’s Manual TLE-INTL, 45, 67 United States defaults TLE-ICID, 70, 101 TLE-INTL, 68 User Defined Parameters TLE-ICID, 81 Version 1.00, 106 Version 1.01, 106 Version 1.02, 106 Version 1.03, 107 Version 2.00, 25, 45, 107 Version 2.01, 107 Version 3.00, 25, 42, 45, 108 Version 3.01, 108 Version 3.02, 108...

This manual is also suitable for:

Tle-a-01Tle-advTle-intlTle-icid

Table of Contents
