Line Sharing Switch (LSS)
M-392, M-393, and M-394
Product Manual
40-400-00015, Rev. F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-392 and is the answer not in the manual?

Questions and answers

Related Manuals for Teltone M-392

Summary of Contents for Teltone M-392

  • Page 1 Line Sharing Switch (LSS) M-392, M-393, and M-394 Product Manual 40-400-00015, Rev. F...
  • Page 2 Note This manual covers Models M-392-B-01/02, M-393-B-01/02, and M-394-B-01/02. Copyright Notice Copyright © 1993 - 2004 Teltone Corporation All Rights Reserved Trademarks Teltone is a registered trademark of Teltone Corporation. Windows is a registered trademark of Microsoft Corporation. Other company and product names may be trademarks or registered trademarks of their respective owners.

  • Page 3: Table Of Contents

    Chapter 5: Standalone LSS Operation and Programming ....20 Figure 5 Standalone Line Sharing Switch ..... . . 21 Using the LSS Programming Commands Table.
  • Page 4 Line Sharing Switch Daisy-chain Remote Programming ......33 Table 6 Remote Programming Daisy-chained LSS Units ... 33 Alternate Telephone Connection .
  • Page 5 NOTE: Items C and D above are found on the label on any Teltone equipment connected to your telephone line. 2. These devices must not be installed on coin-operated telephone lines or party lines.

  • Page 6: Canadian Compliance

    Repairs to certified equipment should be made by Teltone Corporation. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

  • Page 7: Important Safety Instructions

    Reference Manual IMPORTANT SAFETY INSTRUCTIONS When using this product, basic safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock, and injury to persons. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3.

  • Page 8: About This Manual

    -or- Each step is accompanied by a check box: Check the box when you finish the step. Some steps are examples and look like this: This is an example step. Page vi ® M-392-A/B, M-393-A/B, and M-394-A/B Line Sharing...

  • Page 9: Chapter 1: Getting Started

    This configuration is intended for experienced users only. Follow the instructions to install, test, and program new port Transfer Codes. Product Registration Fill out the Product Registration card and return it to Teltone Corporation. 40-400-00015, Rev. F Chapter 1: Getting Started...

  • Page 10: Chapter 2: Overview

    Line Sharing Switch Chapter 2: Overview The Teltone Polling Controller and LSS enable businesses using multiple dedicated telephone lines for short-duration data transfers to save costs through line sharing. In companies where headquarters regularly poll branch offices for data collection, the system allows devices, such as modems, to share a phone line at the remote location.

  • Page 11: Programming

    Teltone Polling System. These types of telephone lines are also known as Analog Line, POTS (plain old telephone service) lines, and Single Line Telephone circuits. The LSS will not operate on digital lines or ground start trunk circuits.

  • Page 12: Basic Operation

    Line Sharing Switch Programmable Transfer Codes This group of features improves security by allowing you to specify the DTMF tones which route calls at the LSS, ensuring that calls are transferred to the appropriate port. Transfer codes can be programmed so that the LSS can be used with and without a Polling Controller in the same application.

  • Page 13: Chapter 3: Installing The Lss

    A UL and CSA approved AC to DC transformer is included which converts the input voltage to the 24 VDC required by the unit. Ports: two, three, or four RJ-11 device ports (models M-392-A/B, M-393-A/B, and M-394-A/B, respectively). Port 1 is the highest priority device port; if a telephone is to use the line it should be connected to Port 1.

  • Page 14: Mounting Options

    Line Sharing Switch Mounting Options The LSS is shipped with adhesive mounting pads, each with adhesive backing for mounting the unit to a wall or other surface, shown in Figure 4. The LSS may also be mounted on a wall using mounting strap (UM-110-101), shown in Figure 3 and available as an ordering option.

  • Page 15: Installation On Pbx Or Key Telephone Systems

    Connect other devices that will share the line to the remaining device ports (Port 2 on M-392-A/B; Ports 2 and 3 on M-393-A/B; Ports 2, 3, and 4 on M-394-A/B) Connect the power cord to the Power jack on the LSS and the transformer to a non-switched, standard AC wall outlet.

  • Page 16: Figure 3 Lss Mounted Using Mounting Strap

    Line Sharing Switch Figure 3 LSS Mounted Using Mounting Strap Apply 2" square dual lock fastening pad to unit as shown (allow for serial number label). Both pieces should be mated prior to installation on unit. Figure 4 Adhesive Mounting Pads...

  • Page 17: Figure 5 Line Sharing Switches

    Reference Manual Chapter 3: Installing the LSS Figure 5 Line Sharing Switches 40-400-00015, Rev. F Page 9...

  • Page 18: Chapter 4: Teltone Default Lss Operation With Polling Controller

    Line Sharing Switch Chapter 4: Teltone Default LSS Operation with Polling Controller This chapter is used for M-39X-B-02 models only. Example: When the Polling Controller and LSS are working together as a system, a typical polling call from a host computer would progress as described below.
  • Page 19 PSTN times out (usually within 10-15 seconds). If No Priority Mode is enabled, no port can access the line when another port is using it. 40-400-00015, Rev. F Chapter 4: Teltone Default LSS Operation with Polling Controller Page 11...
  • Page 20 Line Sharing Switch Calling Party Supervision The U.S. telephone network typically uses Calling Party Supervision. This means that even though the called party hangs up, they may be reconnected to the calling party when their phone is taken off-hook again. The calling party must hang up in order for the called party to be fully disconnected and initiate a new call.
  • Page 21 DTMF transfer code is not received, the call is routed to Port 1, and the off-hook port will be left connected to the local battery feed. No tones will be sent to the port. 40-400-00015, Rev. F Chapter 4: Teltone Default LSS Operation with Polling Controller Page 13...
  • Page 22 Line Sharing Switch Off-hook Timeout at the LSS Occasionally, a need to set a maximum off-hook time is required. The LSS allows either no limit or a programmable maximum time of up to 255 minutes per port. After an off-hook timeout timer expires, the device connected to the port will be sent a forced disconnect (COD) and the C.O.

  • Page 23: Programming The Lss

    Please make your entries in pencil, as you may wish to change them at a later date. 40-400-00015, Rev. F Chapter 4: Teltone Default LSS Operation with Polling Controller (no data entry) x = (single data field)

  • Page 24: Table 2 Lss Programming Commands

    Code that a Port 1 user can enter to obtain 52#x#x# access to the line in order to dial any number. THE ACCESS CODE MUST BE ENTERED TWICE, AS SHOWN. Page 16 Valid entries Teltone (x=/y=/n=) Default 1-30 0=disabled 1=enabled 1=enabled...
  • Page 25 12 DTMF digits (0-9, *, and #). Note 2: The Teltone Defaults are proprietary and unpublished and require the use of the Polling Controller, unless reprogrammed by the user. See routing codes *07 - *0, #7 in Table 3.

  • Page 26: Table 3 Routing Codes For Polling Controller

    Line Sharing Switch Routing Code (DTMF) for Proprietary Transfer Codes Routing Code (DTMF) for Programmable Transfer Codes Local Programming If a telephone line is NOT connected to Jack A of the LSS: Connect a DTMF telephone to LSS Port 2.

  • Page 27: Remote Programming

    Redial the unit and append #1 immediately. When the Polling Controller connects to the switch (you will hear a click and the LED changes modes), enter test# (8378#) within 30 seconds to check the new password. Listen for 3 beeps.

  • Page 28: Chapter 5: Standalone Lss Operation And Programming

    Line Sharing Switch Chapter 5: Standalone LSS Operation and Programming This chapter is used for M-39X-B-01 models only. The LSS can be used with or without the Polling Controller. In this Standalone mode, the modem or fax dialing string must be programmed to direct calls to assigned ports. (For example, in Figure 6, modem calls to the POS server would be sent to Port 3 and fax calls to Port 2.) The LSS can have two, three, or four ports.

  • Page 29: Figure 5 Standalone Line Sharing Switch

    Reference Manual Figure 5 Standalone Line Sharing Switch Programming Transfer Codes The Polling Controller sends transfer codes to the LSS indicating the port to which calls should be routed. Calls also can be manually routed to any of the ports using a one- to four-digit transfer code.
  • Page 30 Line Sharing Switch and/or receive a busy signal to indicate that she/he should redial in these instances. You can establish one of three types of priority which will determine how competing users at the LSS are given access to the line. This is determined by a programming command, as described in Chapter 4.
  • Page 31 Reference Manual Telephone Calls—Modem Active If in Total Priority Mode, and the modem is active, a priority port going off-hook remains connected to the local battery feed while the LSS disengages the active port. To do this, the LSS forces the modem on-hook (terminating the modem carrier), then sends a disconnect command to the Polling Controller and receives acknowledgment that the Polling Controller has gone on-hook, then goes on-hook towards the central office to obtain a new dial tone for the calling party.
  • Page 32 Line Sharing Switch the LSS connects Port 1 to the incoming call, and monitors for a DTMF transfer code from the host site Polling Controller. If a DTMF transfer code is received, the LSS will split the line. What happens next depends on which priority interrupt mode has been programmed.

  • Page 33: Using The Lss Programming Commands Table

    Reference Manual telephone keypad, either locally or remotely. Command Format All commands start with * and end with #. # is also used to separate the parts of the command. In general, the formats are as follows: *<command># *<command>#<x># *<command>#<x>#<x># Cancel Command To cancel the entire command, enter: * in a command field.

  • Page 34: Table 4 Lss Programming Commands

    THE ACCESS CODE MUST BE ENTERED TWICE, AS SHOWN. Page 26 Valid entries Standalone (x=/y=/n=) Default 1-30 0=disabled 1=enabled 1=enabled 3-10 digits, any DTMF 8358663 digits except # “Teltone” 0=precise 0=precise 1=stuttered 0=disabled 1=enabled 1=enabled 0=disabled 0=disabled 1-4=ports 0-255 (minutes) 0=disabled 0-255 (minutes) 0=disabled...
  • Page 35 Reference Manual Table 4 LSS Programming Commands Command Function Description Delay before routing: Number of seconds 70#x# delayed before routing to default or disconnecting, if no default is set. Answer tone: When the LSS answers, a 71#x# four-beep confirmation tone is sent, or four-seconds of dial tone are heard.

  • Page 36: Local Programming

    Connect a DTMF telephone to Jack A of the LSS Port 1 Go off-hook and dial ## within 15 seconds . Enter the password within 30 seconds (default 8358663# or “Teltone”). When you hear a confirmation tone (3 short beeps), begin programming.

  • Page 37: Remote Programming

    Redial the unit and append #1 immediately after hearing the first ring. When the Polling Controller connects to the switch (you will hear a click and the LED changes modes), enter test# (8378#) within 30 seconds to check the new password.

  • Page 38: Chapter 6: Advanced Applications

    4 ports. Two typical applications are described in this chapter. The first is a distributed application using Standalone operation, and the second is a daisy-chain configuration using Teltone Default operation. Cascaded units operate just as they would normally, with one exception: Priority operation via Port 1 must always be connected from port 1 of the primary LSS to the Jack A input of the cascaded LSS, see Figure 7.

  • Page 39: Programming For Cascaded Lss Units

    Reference Manual For the following explanation, assume that three LSS units are being cascaded as indicated in the illustration. If you assign No Priority (default) to all LSS units, equal access is given to the Central Office line for all ports. If you assign Total Priority to the first LSS unit and the LSS connected to Port 1, devices connected to ports on the first and second LSS will be disconnected if Port 1 goes off-hook.

  • Page 40: Programming For Daisy-Chained Lss Units

    Line Sharing Switch In order to use Emergency Priority, program the last LSS in the chain for Emergency Priority and all others for Total Priority. The last LSS in the chain will have priority over all others in the chain. When an emergency call is made, the Total Priority mode of other units up the chain will cause any call in progress to be terminated.

  • Page 41: Table 5 Routing Codes

    Reference Manual Routing Code When assigning transfer codes for remote programming or for ports, all codes must be unique and must have the same number of digits. Select a port on one of the daisy-chained LSS units. Choose the routing codes (*01 - *16) that you want associated with that port. Assign a unique transfer code to that port.

  • Page 42: Alternate Telephone Connection

    Chapter 4 to program settings for the features you will use. Alternate Telephone Connection Note: Jack B is available only on M-392-A/B and M-393-A/B LSS units. Installation Using Jack B: Use Jack B to ensure that the LSS is the first device on the line.

  • Page 43: Figure 8 Installation Using Jack B

    Reference Manual Chapter 6: Advanced Applications Figure 8 Installation Using Jack B 40-400-00015, Rev. F Page 35...

  • Page 44: Chapter 7: Warranty, Troubleshooting, And Technical Support

    Chapter 7: Warranty, Troubleshooting, and Technical Support Warranty Information Teltone warrants this product to be free from defects in material and workmanship for a period of 30 months, given proper installation and usage. At its sole discretion, Teltone will repair or replace free of charge any unit found to be defective during the warranty period.

  • Page 45: Return Procedures

    Reference Manual Return Procedures If a unit is found to be defective, contact Teltone customer service to obtain a RMA (Return Material Authorization) number and shipping instructions. When returning units, provide the following information: • Unit model number, unit part number, and serial number (obtained from the Unit ID label on the bottom of the unit).

  • Page 46: Appendix 1: Specifications

    Line Sharing Switch Appendix 1: Specifications M-392-A/B, M-393-A/B, and M-394-A/B Line Sharing Switches Power Requirements Environmental Requirements Versions 250-00187-18 or higher Operating Temperature Storage Temperature Versions 250-00187-17 or lower Operating Temperature Storage Temperature Humidity Incoming Line Ring Detect Frequency Voltage...
  • Page 47 Reference Manual Regulatory Compliance Safety United States Canada United States Telecom United States Canada FCC and Industry Canada REN 40-400-00015, Rev. F Appendix 1: Specifications UL 1459 CSA C22.2 No. 225-M90 FCC Part 15, Class B FCC Part 68 Certification Number: AHHUSA-73685-KX-N Industry Canada CS-03 Registration Number: 344 4918 A 1.2B...

  • Page 48: Appendix 2: Ordering Information

    PS-24DC-01 power transformer with cord (one per unit) or UM-112-801 rack mount shelf (one for each eight units). M-392-B-01 Two-port Line Sharing Switch. Includes technical manual 40-400-00015. Enables two M-392-B-02 devices to share one telephone line. Includes AC transformer with cord (PS-24DC-01).

  • Page 49: Appendix 3: Glossary

    Factory default A setting programmed by Teltone. You can change this value with one of the programming commands. If necessary, you can use the Restore Defaults command to return to factory defaults.
  • Page 50 Line Sharing Switch Key telephone system A telephone system in which the telephones have multiple buttons that permit a user to select outgoing or incoming central office phone lines directly. LED or light Light-emitting diode. A semiconductor diode that emits light when a current is passed through it. Used for status and information displays on electronic devices.

  • Page 51: Index

    6 No priority defined ... 11, 22 detailed operation ... 23 No Priority Daisy-chain ... 31, 32 Off-hook timeout at Line Sharing Switch ... 14, 24 On-hook mode ... 42 Operation as a system... 10 Ordering information ... 40 Passwords programming command ...
  • Page 52 ... 23 Priority, total defined ... 11, 22 detailed operation ... 12, 23 Privacy timeout ... 14, 24 Privacy timeout at Line Sharing Switch ... 23 Programming local, Line Sharing Switch... 18, 28 remote, Line Sharing Switch... 19, 29 Programming commands Line Sharing Switch ...
