Summary of Contents for aivituvin GUT 08
- Page 1 INSTRUCTION MANUAL GUT 08...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M6.0x40mm SCREW M8.0x50mm KNOBS 2PCS 8PCS M3.5x25mm SCREW M3.5x35mm SCREW 14PCS+1 spare 64PCS+1 spare M3.0x16mm SCREW M3.5x45mm SCREW 24PCS+1 spare 8PCS+1 spare... - Page 5 PARTS Bench Seat Backrest Bench Frame 2 PCS 2PCS 2PCS Side Frame Canopy Support Frame Panel 2PCS 4PCS 2PCS Frame Support Rectangle Canopy Frame Triangle Canopy Frame 3PCS 2PCS 2PCS...
- Page 6 PARTS Sand Screen Stopper Seat Divider 6PCS 6PCS Frame for Storage Bins- Canopy Metal Fixator Long Side 2PCS 2PCS Frame for Storage Bins- Divider for Storage Bins Storage Bins Short Side 3PCS 2PCS 2PCS...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY ① Attach three part J seat dividers to a part C bench seat with 6xP3 screws. ② Repeat on other bench seat. ① Attach a part B backrest to a part C bench with 6xP5 screws, three screws per hinge. ② Repeat on other bench seat. - Page 8 PRODUCT ASSEMBLY Attach part D and part E together by 8xP3 screws on each side. Insert Part F to Part N, then screw from outside by 3xP4. ① ② Screw part F to Part E by 4xP2 bolts.
- Page 9 PRODUCT ASSEMBLY Repeat on other sandbox side. ① Screw Part G to Part E from inside by 4xP4 screws on each side. Put the sand screen inside of the sandbox. ② ...
- Page 10 PRODUCT ASSEMBLY Attach two part A bench frames with 8xP3 screws. Attach two assembled benches with 12xP5 screws, three screws per hinge.
- Page 11 PRODUCT ASSEMBLY Attach three part K stopper with 6xP3 screws, two screws per stopper. ① Repeat attach the part K on the other side. ② Attach two part I to part F canopy support by 1xP1 each side.
- Page 12 PRODUCT ASSEMBLY Attach three part H to part I with 12xP3 screws. Screw Part Q to Part O by 4xP3, Then Screw Part P & O to complete the assemble of storage frame by 8xP6.
- Page 13 PRODUCT ASSEMBLY Put in the storage bins. Put the storage bins in the sandbox.
- Page 14 PRODUCT ASSEMBLY Stick the canopy by the magic sticks. P.S. The storage bins can put on the side of the sandbox too.
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
Need help?
Do you have a question about the GUT 08 and is the answer not in the manual?
Questions and answers
Am I supposed to attach the sand screen somehow?
To attach the sand screen for the aivituvin GUT 08, place the sand screen inside the sandbox. No screws or tools are required for this step.
