THANK YOU for purchasing this high-quality product. Register your microwave oven at www.whirlpool.com.
For future reference, please make a note of your model and serial number located on the front facing of the microwave oven
opening, behind the door.
Model Number _________________________________________
Para una versión de estas instrucciones en español, visite www.whirlpool.com
Deberá tener a mano el número de modelo y de serie, que están ubicados en la parte frontal de la abertura del horno de
microondas, detrás de la puerta.
MICROWAVE HOOD COMBINATION SAFETY
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
When using electrical appliances basic safety precautions should be followed, including the following:
WARNING:
To reduce the risk of burns, electric shock, fire,
injury to persons, or exposure to excessive microwave energy:
Read all instructions before using the microwave oven.
I
Read and follow the specific "PRECAUTIONS TO AVOID
I
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY" found in this section.
The microwave oven must be grounded. Connect only to
I
properly grounded outlet. See "GROUNDING INSTRUCTIONS"
found in this section and in the provided Installation Instructions.
05-Nov-2017 19:41:21 EST | RELEASED
Your safety and the safety of others are very important.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
In some European factories the letter "W" of the part code mentioned herein will be automatically
User Guide
Microwave Hood Combination
Serial Number __________________________________________
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
Install or locate the microwave oven only in
I
accordance with the provided Installation Instructions.
Some products such as whole eggs in the shell and
I
sealed containers - for example, closed glass jars -
are able to explode and should not be heated in the
microwave oven.
W11124880B
replaced by the number "4000" (e.g. "W12345678" becomes "400012345678")

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WML75011HZ0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Whirlpool WML75011HZ0

  • Page 1 User Guide Microwave Hood Combination THANK YOU for purchasing this high-quality product. Register your microwave oven at www.whirlpool.com. For future reference, please make a note of your model and serial number located on the front facing of the microwave oven opening, behind the door.
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Use the microwave oven only for its intended use as Liquids, such as water, coffee, or tea are able to be described in the manual. Do not use corrosive chemicals or overheated beyond the boiling point without appearing to vapors in the microwave oven.
  • Page 3: Electrical Requirements

    Electrical Requirements WARNING GROUNDING INSTRUCTIONS For all cord connected appliances: The microwave oven must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. The microwave oven is equipped with a cord having a grounding wire with a grounding plug.
  • Page 4: Cookware And Dinnerware

    Standby Mode Fan Timer Set vent fan to run for exactly 30 minutes or to run for only 30 When no functions are working (12-hour clock is displayed or if minutes more (off after 30 minutes). The vent fan may be turned off the clock has not been set), oven will switch to Standby Power at any time using the Vent Fan keypad.
  • Page 5 MENU PROGRAMS: Touch the menu control repeatedly to scroll through program options. Rest on the desired program options. Follow display prompts to select submenu items and/or amounts, and then start the program. Any invalid entry will cause an Invalid Tone and be corrected to a value that is within range and closest to the entered value.
  • Page 6: Microwave Oven Care

    MICROWAVE OVEN CARE Installing/Replacing Filters and Light Bulbs 5. Put the grease filter and charcoal filter back to the bottom plate. NOTE: A Filter Status indicator (on some models) appears in the display when it is time to replace the charcoal filter, and clean or replace the grease filters.
  • Page 7 3. Replace a new charcoal filter and reattach it back to grease 4. Replace a new LED, press it back between two hooks and plug filter. in the terminal. 4. Put the grease filter and charcoal filter back to the bottom plate.
  • Page 8: Replacement Parts

    2. Remove the second left top cover. 5. Replace a new LED, and snap it into the hook. Hook 6. Reattach the second top vent cover with the screw removed in step 1. 3. Take out LED board. Screw Second left vent top cover Top front of micowave oven...
  • Page 9: Troubleshooting

    TROUBLESHOOTING If you experience Recommended Solutions Microwave oven will Check the following: not operate Household fuse or circuit breaker - If a household fuse has blown or a circuit breaker has tripped, ■ replace the fuse or reset the circuit breaker. If the problem continues, call an electrician. Magnetron - Try to heat 1 cup (250 mL) of cold water for 2 minutes at 100% cooking power.
  • Page 10 DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY Whirlpool makes no representations about the quality, durability, or need for service or repair of this major appliance other than the representations contained in this warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes with this major appliance, you should ask Whirlpool or your retailer about buying an extended warranty.
  • Page 11 NOTES In some European factories the letter "W" of the part code mentioned herein will be automatically 05-Nov-2017 19:41:21 EST | RELEASED replaced by the number "4000" (e.g. "W12345678" becomes "400012345678")
  • Page 12 NOTES W11124880B SP PN W11177408 /™ ©2017 Whirlpool. All rights reserved. 10/17 ® In some European factories the letter "W" of the part code mentioned herein will be automatically 05-Nov-2017 19:41:21 EST | RELEASED replaced by the number "4000" (e.g. "W12345678" becomes "400012345678")
