Lattice Semiconductor MachXO5T-NX Quick Start

QuickSTART
This document provides a brief introduction to the MachXO5T-NX Development Kit.
Power Switch (SW6)
User LEDs
(D1-D8)
Done LED
(D10)
INIT LED
(D11)
DIP
Switches
(SW1)
VS1_2 (J24)
VS7 (J22)

Check Kit Contents

1
The MachXO5T-NX Development Board kit contains the following items:
MachXO5T-NX Development Board
„
12 V AC/DC Adapter and International Plug Adapters
„
USB Cable for Programming via PC (USB-A to Mini-B)
„
Quick Start Guide
„
Lattice Radiant software download information
„

Using the MachXO5T-NX Development Board

2
The MachXO5T-NX Development Board as shipped supports Internal Flash boot-based
configuration. The internal Flash Configuration Memory is pre-loaded with a LED blinking
demonstration program.

Installing the Software

3
The MachXO5T-NX Development Board is pre-programmed with a basic demonstration.
To develop your own solutions, download and use the Lattice Radiant design software
(version 2023.1 or later) in www.latticesemi.com/software.
If you only need to re-program the board, you can use the Radiant Programmer
Standalone software (version 2023.1 or later).
Power LED (D18)
VS6 (J21)
LFMXO5-100T
Device (U3)
MachXO5T-NX Development Kit
VS5 VS4
(J20) (J23)
Config
USB
Header
(J11)
Power
Jack
(J17)
REG1
(J28)
REG0
(J26)
