Bogen Nyquist NQ-GA400P Installation And Use Manual

NQ-GA400P 2-Channel AoIP Gateway
Installation and Use Guide
The NQ-GA400P is a 2-channel audio over IP (AoIP) encoder/decoder (i.e., gate-
way) incorporating two balanced line-level inputs and two balanced line-level
outputs, along with two Form-C SPDT-type 2-amp dry contact relays. Designed to
operate over a 10/100 Ethernet network, the NQ-GA400P AoIP Gateway is IEEE
802.3af–compliant and can be powered using Power over Ethernet (PoE). The
NQ-GA400P AoIP Gateway can provide two balanced line-level analog audio out-
puts to auxiliary power amplifiers and can accept two balanced line-level analog
inputs from auxiliary preamplifier outputs.
Notice
Every effort was made to ensure that the information in this manual was complete and accurate at the time of print-
ing; however, all information is subject to change.
This equipment is not suitable for use in locations where children are likely to be present.
Equipment is intended for use only in a restricted access area.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Avertissement: pour réduire le risque d'incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et
l'humidité.
The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall
be placed on apparatus.
L'appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun objet ne contenant de liquide, tel
qu'un vase, ne doit être placé sur l'objet.
The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, ta-
ble-cloths, curtains, etc.
- il convient que l'aération ne soit pas gênée par l'obstruction des ouvertures d'aéra
No naked flame sources, such as lighted candles, should be placed on the apparatus.
- il convient de ne pas placer sur l'appareil de sources de flammes nues, telles que des bougies allumées
The apparatus should be used in moderate climates.
- si l'appareil est destiné à être utilisé sous un climat tempéré.
LIN E LIN E LIN E LIN E
O U TP U T 1 O U TP U T 2 IN P U T 1 IN P U T 2 R ELAY 1 R ELAY 2
+ - G G + - + - G G + -
N C CO M N O N C CO M N O
