- Page 1 Voice / Fax over IP Networks Configuration Guide for Voice/IP Gateways Bogen PCM Zone Paging MultiVOIP Models: MVP130-BG, MVP210-BG, MVP410-BG, MVP810-BG...
-
Page 2: Configuration Guide
Configuration Guide Doc # Bogen03 MultiVOIP Models MVP130-BG, MVP210-BG, MVP410-BG, MVP810-BG This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-Tech Systems, Inc. All rights reserved. Copyright © 2004, by Multi-Tech Systems, Inc. Multi-Tech Systems, Inc. - Page 3 Bogen paging example using FXS Pass Through feature. The example below shows a Bogen PCM/ZPM Zone Paging unit at the Corporate site connected through MultiVOIPs to amplifiers and speakers at each of two branch sites. Users at the corporate site can page users at the Branch A and/or Branch B sites.
- Page 4 In the Configuration / IP screen of the MultiVOIP Configuration software, configure each MultiVOIP with a unique IP address. Also configure the mask and gateway address. If all MultiVOIPs are located in the same subnet, you can leave the gateway address field blank. Click Ok when finished.
- Page 5 Branch A Branch B...
- Page 6 In the Configuration/Interface screen, Select each voice channel used for paging from the Select Channel drop-down list and configure that channel so FXS Loop Start and Pass Through are enabled. Click Ok when finished.
- Page 7 Go to the Phone Book / Phone Book Modify / Outbound Phone Book / List Entries screen.
- Page 8 Click the Add button to add a phone book entry. In the Destination Pattern field, enter the identifying number for one of the remote MultiVOIP units. Enter the IP address of the remote MultiVOIP unit in the IP Address field. Leave the other fields set at their defaults.
- Page 9 Click Ok when finished with this entry. Click the Add button as needed to create enties for other remote MultiVOIP units. In our example, the Corporate MultiVOIP would have two entries like below: The Branch A and Branch B MultiVOIP entries would look like this:...
- Page 10 In the configuration / Voice/Fax screen, select one of the channels to be used for paging and click the Auto Call Enable checkbox to enable the auto call feature. In the Phone Number field, enter x:y where x equals the remote MultiVOIP identifying number and y equals the remote MultiVOIP Voice Channel number.
- Page 11 Corporate Channel 2 Branch A Channel 1...
- Page 12 Select Save Setup / Save and Reboot to save the configuration to the MultiVOIP. 9. Assuming a Bogen PCMZPM is located at Corporate, connect a RJ11 phone cord to channel 1 FXS/FXO jack on the Corporate MultiVOIP. Connect the two wires on the other end of the phone cord to the Zone A + and –...
