Air Conditioner Features & Operating Instructions

Air Conditioner Features

ACTIVATES
TIMER
SETS MODE
REMOTE CONTROL
Operating Instructions
NOTE
The following instructions represent the Touch Pad, the same instructions can be used for the Remote Control.
TO TURN UNIT ON:
2009 Electrolux Home Products, Inc.

ELECTRONIC CONTROL

Before you begin, thoroughly familiarize yourself with the control panel and remote
as shown below and all its functions, then follow the symbol for the functions you
desire. The unit can be controlled by the touch pad alone or with the remote.
DISPLAYS TEMPERATURE/TIME
TURNS UNIT
ON OR OFF
ADJUSTS
TEMPERATURE
OR TIME
DO THIS:
PRESS ON/OFF BUTTON
SETS FAN
SPEED

TO REPLACE BATTERY

Battery Size: CR2025
Turn Remote Control upside down. Squeeze tab and
pull to remove battery tray. Place battery in tray with
POSITIVE("+") side facing UP, according to diagram.
Re-insert battery tray.
YOU WILL SEE:
Note: The unit will run in energy saver(econ) mode when
used for the first time. In this mode, the fan will continue to
run for 1 minute after the compressor shuts off. The fan then
cycles on for 20 seconds at 10 minute intervals until the room
temperature is above the set temperature, at which time the
compressor turns back on.
CHECK FILTER
RESET BUTTON
SLEEP MODE
TAB
All rights reserved.
5
