luceco UTF6WD2W Installation & Operating Instructions

FTYPE ULTRA 4W/6W DIM2WARM
FIRE RATED LED DOWNLIGHT & CONNECTOR
PART CODE: UTF6WD2W / UTR6WD2W / UTA6WD2W
This Luminaire contains a light source of Class: D

ASSEMBLY AND INSTALLATION

• This product is only suitable for indoor use
• This product is suitable for direct insulation cover (layover and blanket)
• This product must be disconnected before insulation resistance testing of the lighting circuit
• IP65* rated – zone 1 & 2 suitable
• *: IP65 is rated for exposed parts. IP20 for recessed parts.
• Wire for interconnection ≥1.5mm
• Maximum amount of interconnections:50pcs/2A current
• UK Flat Cable: 6242Y 2x1.5mm
• EU Round Cable: H03VV-F 3x0.75mm .H05VV-F 3x1.0mm -1.5mm
1
3

HOW TO OPEN THE CONNECTOR

1. To open cable clamp,
lift on locking tabs.
UTxx-D2W.DC.05.2023
2
+1.0mm , 6242Y 2x1.0mm +1.0mm
2 2
Tech Help Line
0330 0249 279
UK -
+44 (0)1952 238 100
Non UK -
Supplied by LUCECO
Stafford Park 1, Telford, Shropshire,
England, TF3 3BD
www.luceco.com
Visit our website at
Installation & Operating Instructions
2
2. To open collar, push
locking tab and lift.
BEAM REGRESSED
CRI
IP65
>
ANGLE
80 RATED
60
M A T T
30
WHITE
FIRE RATED
BEZEL ACOUSTIC
PART E
SUPPLIED
AIR LEAKAGE
INSULATION
PART C
COVERABLE
76mm
Suggested
3. Remove terminal block.
Servicio de asistencia telefónica
0330 0249 279
UK -
+34 93 829 55 74
Non UK -
(EU) Luceco SE
C/ Bobinadora 1-5
08302 Matarό Spain
www.luceco.com
Visite nuestra web en
FLAT ADJUSTABLE
IP65 IP20
RATED RATED
60 90
min min min
FIRE RATED FIRE RATED
7 year
standard
50,000
WARRANTY
HOURS
