INSTRUCTION MANUAL
LIGHTNING SURGE PROTECTOR FOR
PROFIBUS-PA
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System's Sales Office or representatives.
■ PACKAGE INCLUDES:
Surge protector ....................................................................(1)
■ MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
LIMITATION APPLICABLE TO M-RESTER
The M-RESTER will protect electronics equipment from
damage caused by lightning by absorbing most of the
surge voltages.
However, M-RESTER may not be effective against cer-
tain extremely high voltages caused by a direct or almost
direct hit by lightning.
M-RESTER must be installed according to this installa-
tion / instruction manual.
GENERAL
■ FUNCTION & FEATURES
• High discharge current capacity 20 kA (8 / 20 µs), 1 kA
(10 / 350 µs)
• Ultra-thin 7-mm-wide module can be mounted in high
density
• Excellent protection employing multi-stage SPD circuits
• DIN rail mounting and grounding
• Shield terminal provided
SEN TRONIC
(ultra-slim)
■ SPECIFICATIONS
Max. continuous
operating voltage (Uc)
Voltage protection level
(Up) @4kV (1.2 / 50 µs)
Leakage current @Uc
Response time
Approx. capacitance
@10 kHz
Max. discharge current
(Imax)
Nominal current (I
Internal series resistance
*1. Values for the MD7PA-FF.
Shortcircuited for the MD7PA-FG.
POINTS OF CAUTION
■ ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -25 to +85°C
(-13 to +185°F) with relative humidity within 30 to 90%
RH in order to ensure adequate life span and operation.
• This unit needs a DIN rail as earth grounding bar. Ox-
ide coating of an aluminium rail may lower the electric
conductivity between this module and the ground. Use a
steel or copper rail.
■ DIELECTRIC STRENGTH TESTING
• The surge protector starts discharging when 160V or
greater voltage is applied between lines and earth. Re-
move the grounding wire before conducting a test. Be
sure to return the wire after the test.
■ AND ....
• We recommend that you keep spare surge protectors so
that you can replace them when necessary.
• Lightning surge can enter not only through signal lines
but also through power supply lines. We recommend that
you also use the Lightning Surge Protector for Power
Lines for adequate protection.
056 222 38 18
mailbox@sentronic.com
AG
MD7PA
MODEL
LINE TO
LINE TO
LINE
EARTH
±32V
±160V
±60V
±800V
≤ 5µA
≤ 5µA
≤ 4 nsec.
≤ 20 nsec.
1500 pF
100 pF
20kA (8 / 20 µs)
1.0kA (10 / 350 µs)
)
400mA
N
1.5Ω ±10% per line
EM-8056 Rev.4 P. 1 / 5
www.sentronic.com
SHLD TO
EARTH
±160V*
1
±800V*
1
≤ 5µA*
1
≤ 20
nsec.*
1
100 pF*
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD7PA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for M-system MD7PA

  • Page 1 BEFORE USE ..LINE TO LINE TO SHLD TO LINE EARTH EARTH Thank you for choosing M-System. Before use, please check Max. continuous ±32V ±160V ±160V* contents of the package you received as outlined below. operating voltage (Uc) If you have any problems or questions with the product, Voltage protection level ±60V...
  • Page 2: Component Identification

    MD7PA COMPONENT IDENTIFICATION Body DIN Rail Mounting Adaptor (for grounding) Connection Diagram (left side) Model No. Indication Spring Loader INSTALLATION Mount the unit on a DIN rail. Once installed, do not move it to another DIN rail. ■ MOUNTING THE UNIT ON A DIN RAIL A) Hang the upper hook of the DIN rail mounting adaptor at the rear side of unit, on the DIN rail.
  • Page 3: Terminal Connection

    MD7PA TERMINAL CONNECTION Connect the unit as in the diagram below. Be sure to ground the DIN rail on which the unit is mounted and cross-wire between the rail and FG terminal of the protected device as shown in Figure 1 in order to equalize the earth potential.
  • Page 4 When the distance between nodes are relatively long (e.g. grouped and separated by cabinets), install the MD7PA by each group of devices. Insert the MD7PA at the surge side of the network. For detailed information on the network, refer to that provided by PROFIBUS International.
  • Page 5: Wiring Instructions

    Terminals (4) – (5), (4) – (DIN rail), (5) – (DIN rail), (8) – (DIN rail) The tester should show 10 MΩ or greater. For the MD7PA-FGx, (8) – (DIN rail) should show approx. 0 Ω. 3) Confirm conduction across the same terminals with a 500 V DC 1000 MΩ...
