- Page 1 MAXHUB UC M40 User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Warnings ————————————————————————————————— 02 2. Product Images -———————————————————————————————— 03 3. Connection -——————————————————————————————————— 05 4. Hardware Mode -———————————————————————————————— 06 5. Pro Mode ————————————————————————————————————— 08... -
Page 3: Safety Warnings
1. Safety Warnings Before using this equipment, please read carefully and observe the following precautions to avoid dangerous or improper operations. Working Environment ① DO NOT expose the camera to any heat source (such as electric heaters). ② Use it in an environment with a temperature of 0~40℃ and humidity of 10%–90%RH. ③... -
Page 4: Product Images
③ All images are for illustration purpose only and may not reflect the actual product. The Company reserves the right Add Packaging content design of the product without prior notice. 2. Product Images 1. Packaging content MAXHUB UC M40 User Manual UC M40... - Page 5 Power Adaptor (12V/1A) UC M40 User Manual USB 2.0 Cable (Type-A to Type-C) 1.5 meter 2. Appearance Camera Mode Switch USB Type-C type-c Loudspeaker DC Port Indicator Light Touch Button Microphone...
-
Page 6: Connection
3. Connection Please connect the device according to the following figure before use. Adapter ① The video conference equipment is connected to the 12V/1A adapter and automatically starts up. ② Connect the USB cable to the computer. ③ Select the following modes and follow the instructions to get started. Note: (1) If the 12V/1A power adapter isn't being utilized, the camera would only provide USB video output. -
Page 7: Hardware Mode
② Open Video Platforms such as Tencent Meeting, Zoom and MicrosoftTeams, and select MAXHUB UC M40 as the main camera source. ③ Select UC M40 as the main Speaker and Microphone source from your Video Platform and start your Video Meeting. Volume can be adjusted from your computer directly. - Page 8 - Red: microphone OFF; - The blue LED "circle" indicates the direction of the sound source. Indicator Light Touch Button Microphone ⑥ Equipment power off. *Note: Some video conferencing platforms require you to select the MAXHUB UC M40 camera and microphone.
-
Page 9: Pro Mode
5. Pro Mode ① Connect the USB cable to the computer. ② Go to your computer disk, open the PanoCAM Studio folder, and double-click on the PanoCAM Studio Setup_1.0.2930.0 to install. (You can refer to the Quick start guide-English-f0965 in the PanoCAM Studio folder for more detail.) *Note: If you are on a MacOS, install the PanoCAM Studio Installer_1_3107.2.pkg... - Page 10 ③ Open the PanoCAM Studio Software and select the desired "Display Layout" as well as all other necessary controls. (Compose/ Manual/ Body-fit/ Discussion/ Grid/ Presentation/ Speaker modes). B. Angle Adjustment choose: FOV-Top: Vertical+ 45°Up/ -15°Down FOV-Center: Vertical± 30° FOV-Down: Vertical+ 20°Up/ -40°down A.
- Page 11 ⑤ Open Video Platforms such as Tencent Meeting, Zoom and Microsoft Teams, and select Studio Camera as the main camera source. ⑥ Select UC M40 as the main Speaker and Microphone source from your Video Platform and start your Video Meeting. Volume can be adjusted from your computer directly.
- Page 12 MAXHUB MAXHUB.Global maxhub-overseas/...
