Summary of Contents for WAC Lighting AELLA
- Page 1 AELLA Installation Instructions works with the Google Assistant...
- Page 2 Please read and instructions before installation...
- Page 3 GENERAL INQUIRIES FAN SUPPORT For all questions about your ceiling fan please read all For fast service have the following information below included instructions, installation procedures, trouble- when you call: shooting guidelines and warranty information before starting installation • Model Name and Number For missing parts or general inquiries •...
- Page 4 SAFETY RULES For operation, maintenance, and troubleshooting information, visit http://waclighting.com/fan-support/ To avoid personal injury or damage to the fan and at the circuit breaker before beginning. other items, please be cautious when working around or cleaning the fan. All wiring must be in accordance with the National Electrical Code “ANSI/ NFPA 70”...
- Page 5 SAFETY RULES WARNING: Do not install or use your fan if any part(s) is/are damaged or WARNING: Do not insert foreign objects between rotating fan blades. missing. This product is designed for use only with the supplied parts and/or accessories designated for use with this product by WAC. Substitution of parts WARNING: Do not operate fan unless fan blades are in place.
- Page 6 GET SMART This WAC Smart Fan is: Quiet, reliable, and up to 70% Wet Location-listed to the strictest Coordinates with smart devices UL/cUL safety regulations for voice-activated control MOTOR Wi-Fi and Bluetooth enabled Compatible with our WAC app for unlimited control The WAC app synchronizes seamlessly with smart home devices you already own APP DOWNLOAD WALL CONTROL...
-
Page 7: Table Of Contents
TABLE OF CONTENTS Package Contents Mounting Options Hanging the Fan Installing the Mounting Bracket Making the Electrical Connections Installing the Optional Wall Control Finishing the Installation Controlling the Fan Reset App Instructions Accessories Troubleshooting... - Page 8 TOOLS & MATERIALS REQUIRED Electrical tape Wire cutters Phillips screwdriver Step ladder NOTE: Before discarding packaging materials, be certain all parts have been removed. NOTE: Place the parts from the hardware bag into a small container to keep them from being lost. MAC ID IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place.
-
Page 9: Package Contents
PACKAGE CONTENTS Hanger Plate Hardware Bag RPL- -PARTS RPL-F096-HGR Junction Box Safety Cable Machine Screws (2) Flat Washer (1) Spring Washers (2) Spring Washer (1) Flat Washers (2) Wood Screw (1) Wall Mounting Fastener Wire Connectors (8) Screws ( ) (included with receiver) Receiver Remote Control... -
Page 10: Mounting Options
MOUNTING OPTIONS CAUTION: To prevent electrical shock, ensure electricity Figure 1 is an example of how to mount the outlet box. If needed use hardware to mount the outlet box to the ceiling joist. Standard Ceiling Slope Ceiling To Switch To Switch (No Neutral) (Ground) - Page 11 HANGING THE FAN INSTALLING THE MOUNTING BRACKET Caution: Remember to disconnect the power at the circuit breaker. Fan Body Use Hardware UNLESS OTHERWISE SPECIFIED: NOTE: Your blades come pre-attached to the Fan. DIMENSIONS ARE IN INCHES DRAWN TOLERANCES: CHECKED FRACTIONAL ANGULAR: MACH BEND ENG APPR.
-
Page 12: Hanging The Fan
HANGING THE FAN NOTE: A Safety cable is required for all installations in Canada. Safety cable is required for ceiling fan and light combinations over DATE TITLE: F- 0 9 6L SIZE DWG. NO. -
Page 13: Making The Electrical Connections
HANGING THE FAN MAKING THE ELECTRICAL CONNECTIONS outlet box Outlet Make sure all connections are made correctly or you will permanently damage the receiver. GREEN(Ground) Black(Hot) You may also refer to the labels on the receiver wires for can be RED from Switch leg WHITE(Neutral) direction on how to make proper connections. - Page 14 HANGING THE FAN Fan Assembly Receiver WARNING: Installation of this fan requires that a three-conductor cable (including ground and neutral wire) which should run between ceiling and wall outlet box. WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts, except for the ground wire.
-
Page 15: Installing The Optional Wall Control
INSTALLING THE OPTIONAL WALL CONTROL NOTE: Wall control not included. A Bluetooth wall control accessory can be purchased separately. Skip this section if you did not purchase a wall control. NOTE: For multi-location wiring, skip to the next step. Connect the green wire marked “GROUND” from the wall control to the copper wire from the wall outlet box that feeds back to the circuit breaker –... - Page 16 INSTALLING THE OPTIONAL WALL CONTROL Wall Control 1 Wall Control 2 Wall Control 3 Install the wall control using the wiring diagram in below. Individually pair each of the wall controls with the fan receiver using the pairing instructions in section 15. F - 09 6L...
-
Page 17: Finishing The Installation
FINISHING THE INSTALLATION Secure all wire connections with supplied wire ties to assist in canopy installation. Tuck connections neatly into ceiling outlet box. Slide the motor up to the mounting bracket and place the key hole on the motor over the screw of the mounting bracket. Turn motor until it locks in place at the narrow section of the key holes. -
Page 18: Controlling The Fan
CONTROLLING THE FAN Summer Mode (Counter-Clockwise) Air-Gap Switch* Optional Remote Pairing Unpairing Wall Control Control Press and hold buttons To purge, press and hold Winter Mode for 10-15 seconds. buttons for 4 seconds. (Clockwise) * Air-Gap Switch only included with wall control Your fan was delivered to you with the included remote already NOTE: Your fan features 6 speeds. - Page 19 CONTROLLING THE FAN Breeze Mode Controlling Multiple Fans with Remote or Wall Controls Your remote and wall controls are capable of controlling multiple fans. A remote or wall control has the ability to control Breeze Mode mimics the natural ebb and flow of winds in an unlimited number of fans with the only limitation being the nature by varying the fan speed.
- Page 20 CONTROLLING THE FAN Fan Direction Press and hold Press and hold Press and hold button for 4 seconds. button for 4 seconds. button for 4 seconds. Press and hold Ligh Press and hold Fan Direction: Press and hold beep to indicate the message has been received.
-
Page 21: Reset
RESET WACFan_841812 Factory Reset Receiver Factory Reset Fan Wi-Fi Reset Press and hold buttons for 10 seconds Press the reset button on the receiver Press and hold the for 10 seconds until LED until the receiver beeps blinks green and receiver emits 2 long beeps NOTE: If you change your Wi-Fi settings (SSID or Security NOTE: Factory reset will remove remote control(s), wall control(s) Passphrase you will need to perform a Wi-Fi reset on the fan... - Page 22 APPLICATION In addition to the included control, you can operate your fan with the WAC app. Upgradeable with Smart Features can enable smart features through the WAC app and integrate with your smart home ecosystem. NOTE: Press light toggle and season toggle and hold for 4 seconds if you prefer not using the app or broadcasting Wi-Fi.
- Page 23 APPLICATION The WAC app will walk you through the main screen and show you how to create schedules, change fan speeds, dim the light, switch between Summer and Winter Modes, invite users, create groups and much more. Please refer to the WAC app instructions for more details.
-
Page 24: Accessories
ACCESSORIES Product Model Description Finish Compatible with WAC Smart Fans RC20- Bluetooth Remote Control 6 fan speeds, dims light to 0% 6 fan speeds, dims light to 0% WC20- Works in conjunction with WAC Smart Fan receiver Bluetooth Wall Control (not included) F - 096 L... -
Page 25: Troubleshooting
TROUBLESHOOTING My Fan Will Not Start Check main and branch circuit fuses or circuit breakers. Check line wire connections to fan and switch wire connections in the switch housings. WARNING My Fan is Noisy Allow for 24-hour break-in period. Most noises associated with a new fan will go away during this time period. Check to make sure the screws which attached to the blades (and blade arms when applicable) are tight. - Page 26 TROUBLESHOOTING My Fan is not producing Enough Air Movement If possible, please consider using a longer than included downrod. My remote or wall control is not controlling my fan Verify that the fan is receiving power by power cycling the fan. To do this: Wait at least 10 seconds, and then restore power.
- Page 27 TROUBLESHOOTING What is power cycling and how do I power cycle my fan? 10 sec is wired through a WAC wall control (P/N: WC20-WT) pull the Air-Gap Switch on your wall control, wait 10 seconds, and re-insert. What is Breeze Mode? What is Pairing? Pairing is the process of connecting your WAC remote or wall control to your fan.
- Page 28 Felicidades por tu nueva compra. CERTIFICATE OF WARRANTY Su nuevo ventilador WAC Smart Fans está diseñado para facilitarle la vida cada día. WAC crea ventiladores y luminarias para el futuro que proporcionan ahorros de energía y xcepcional. Nuestra dedicación a hacer las cosas de la manera correcta va Congratulations on your new purchase.
- Page 29 Félicitations pour votre nouvel achat. quotidien. WAC crée des ventilateurs et des luminaires d’avant-garde qui permettent des éc faire les choses va au-delà de notre amour pour les produits étonnants.WAC garantit à tous ses produits pour ventilateurs de plafond pour extérieur qu’ils ne doivent présenter aucun défaut de matériau ou de fabrication pendant un (1) an date d’achat;...
- Page 30 F- 096 L...
- Page 31 F-096L waclighting.com...
