- Page 1 INSTRUCTION MANUAL Stereo Radio Double Cassette Recorder with 3 CD Changer and Turntable CDMP 9933PRT...
-
Page 2: Troubleshooting
TROUBLE SHOOTING Power switch on, but no power Record button cannot be pressed in • Check power to wall outlet. • Cassette erase-protection tab is removed. • Check AC cord connection to wall plug. Use another cassette or apply adhesive tape over tab hole. - Page 3 CONTROLS 1) Plak-up Holder 15) CD Door 2) Speed Selector 16) CD Skip Forward button 3) Spindle Adapter 17) Standby LED Indicator 4) LCD Display 18) Volume Up button 5) CD Skip Backward button 19) Volume Down button 6) Power button 20) Tuning button 7) Power Standby button 21) CD PLAY/PAUSE button...
- Page 4 REMOTE CONTROL This unit comes with a Remote Control which allows the user to control certain REMOTE CONTROL RANGE system functions from a distance of up to 20 feet. The Remote Control requires two AAA Remote Control Sensor batteries (not included). NOTE : The Remote Control should always be aimed at the Remote Control Sensor on the...
-
Page 5: Remote Control
CONNECTIONS POWER CONNECTION HEADPHONE JACK (PHONES) REMOTE CONTROL Connect the power cord to AC outlet only. This unit will accept stereo headphones (not included) with a 1/8" plug and an impedance SPEAKER JACKS of 16 ohms or greater. Connect the SPEAKER PLUGS to the The speakers are automatically SPEAKER JACKS located on the rear of the disconnected when headphones are... - Page 6 TUNER Tuning: 1) Turn the unit "ON" using the POWER switch. 1) Set BAND switch to desired band to 2) Select the TUNER function. access presets. 3) Set the BAND selector as desired. 2) Press MEMORY, M-DOWN,M-UP BUTTON 4) Tune in the desired station using the (on remote Handset) as desired to Tuning UP/DOWN or SCAN UP button.
-
Page 7: Cassette Tapes
PHONO Note : 6. Place the tone arm to the desired position. Remove the stylus protector. 7. Adjust VOLUME & EXTRA BASS Be sure that the tone arm is detached from the controls to the desired sound level and sound tone arm rest before operation and re-secured equalization. - Page 8 CASSETTE PLAYBACK (DECK B) (DECK A) The TAPE B is used for playback only. The Fast-Forward and Rewind TAPE A is used both for recording and For fast winding or rewinding the tape, press playback. the F.Fwd or REW button. Press the STOP/ Do not turn the unit off while the tape is EJECT button when the desired location has running.
-
Page 9: Maintenance
DUBBING (DECK B) TO (DECK A) This unit enables you to duplicate a pre- Dubbing at High Speed recorded tape to another tape by using the This unit is equipped with a HIGH SPEED unit-in double deck mechanisms. It is DUBBING system which allows duplicating performed only one way, from the DECK B a pre-recorded tape at approximately two-... -
Page 10: Handling Compact Discs
Safety Instruction : Do not connect the power cord to the mains supply until all other connections have been made. Do not expose this apparatus to dripping or splashing HANDLING COMPACT DISCS To remove a disc from its storage case, press down on the centre of the case and lift the disc out, holding it carefully by the edges. -
Page 11: Loading Cds
LOADING CDS 1) Press the POWER button to turn the unit on. 2) Select the CD FUNCTION button. The CD Disc tray will turn to check if any discs are present. If no discs are in the tray, NO DISC will appear in the display. 3) Press the OPEN/CLOSE button to open the disc compartment. -
Page 12: Programmed Disc Play
PLAYING MP3 1) Press the FUNC. button to select CD-MP3 mode. 2) Press once to open the CD door (CD door wil open automatically) and place the MP3 disc with label /mark facing on the disc tray. “OPEN” appears on display. - Hold the disc without touching either of its surfaces position it with the printed title side faling up, align it with the guides, and place it in its proper position. - Page 13 PROGRAMMING THE TRACK FROM MORE THAN 1 DISC Programming the track from a different disc. Repeat the same procedure 1-4. Press the No. button to select the next disc. Repeat procedures 1-4 to program the next tracks. Continue entering tracks in this way until all the desired tracks are stored. 20 Tracks can be programmed in this way.
- Page 14 REPEAT DISC PLAY BY REMOTE CONTROL This function allows the operator to repeat a single track, all of the tracks of one CD or with all of the tracks on all 3 CD's. 1. REPEAT ALL Disc Press REPEAT Disc once "REPEAT DISC ALL" appears in the display Press PLAY/PAUSE to start play 2.
- Page 15 INTRO BY REMOTE CONTROL Operates in STOP or PLAY mode 1. Press INTRO once, each song will play for 10 seconds. 2. Press INTRO twice to delete this function. Unit will resume normal play. SLEEP BY REMOTE CONTROL 1. Press SLEEP once, "SLEEP 90" will appear on LCD. This means unit will be stopped & turned to STAND BY mode in 90 minutes.
-
Page 16: Track Skip
TRACK SKIP Starting disc play from the beginning of a particular track Press the Forward or Reverse SKIP/SEARCH buttons to select the desired track. The number of the selected track will be shown on the CD display. Press the PLAY/ PAUSE button to start play. To skip to the next track on a disc For example, to skip ahead to the beginning of track 2 while track 1 is playing.
