SansAmp RPM Specifications
Note: With on-going product development and improvements, specifications and/or
the cosmetic appearance of this unit may change without prior notice. Replacement
parts are available, i.e., knobs, rack handles, faceplate, etc. For more information,
please contact your authorized dealer or Tech 21, Inc.
Model Number:
Input Impedance-Input 1:
Input Impedance-Input 2:
Output Impedance-1/4":
Output Impedance-XLR:
Input Level-Input 1:
Input Level-Input 2:
Output Level-XLR:
Maximum Output Level:
Effects Loop Send:
Effects Loop Return:
Low Frequency Response:
High Frequency Response:
Maximum Power Consumption:
AC Input Power (factory set):
Cycles:
NOTE: Each unit constructed for specific voltages. AC power cannot be switched.
Enclosure:
Dimensions:
Weight:
*Due to the variety of amplifier emulations available, frequency response
characteristics will vary.
OPTIONAL TECH 21 FOOTSWITCH
Footswitch has LED status indicator, and is powered via the cable,
so no batteries are required. And, unlike most amps which require a
custom multi-pin connector, this Footswitch is engineered to utilize
any standard 1/4" instrument or speaker cable. You can easily
replace the cable should you lose it, or purchase different cable
lengths to suit your particular needs.
The Footswitch measures 3.5" x 4.5" x 1.25" and is available through
your local authorized dealer or directly through Tech 21.
RPM
4.7MOhm
1MOhm
1KOhm min
600 Ohms min
1V RMS max
1V RMS or 10V max, with -20dB pad engaged
Switchable to -20dB or 0dB range
+10dB or better
1K Ohm min, -20dB
100K Ohm min, -20dB
10Hz or better*
Harmonic content, 20kHz or better*
5 Watts
100V, 117V, 230V, 240V
50/60 Hz
Aluminum and steel, fully shielded
19.0"w x 1.75"h x 5.25"d / Overall depth: 6.25"
5 lbs.
(Model # FSPL)
