- Page 1 ThingsMatrix: TMX-200225 TMX01 USER MANUAL 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved.
-
Page 2: Table Of Contents
3.4.1 Introduction ........................ 9 3.4.2 Configuration Example ..................10 3.5 Storage Mode ........................10 3.5.1 Introduction ......................10 3.5.2 Configuration Example ..................10 3.6 Schedule Mode ........................11 3.6.1 Introduction ......................11 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! - Page 3 5.4 No optical sensor alert ...................... 14 6 Installation Instructions ........................ 14 6.1 Get Started ..........................15 6.2 SIM Card Installation ......................16 6.3 Device Power Up ......................... 16 6.4 Device Installation ......................16 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right!
-
Page 4: Preface
TMX01 device. In this manual, Platform means ThingsMatrix Service Platform. 2. Introduction 2.1 Overview TMX01 is a ruggedized remote monitoring and tracking device that supports 2G/3G connectivity and positioning features. It is waterproof (IP67 rating) with ultra-low power consumption for long battery life. -
Page 5: Specifications
-20℃ to +70℃ Temperature Environmental Humidity 95%RH GPS Antenna Internal Antenna/SIM Cellular Antenna Internal SIM Form Factor SIM (2FF) Certification PTCRB Data Monitoring Supported Device Management Device Configuration Supported Firmware Upgrade Supported 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 6: Main Features And Use Cases
The wake-up feature must be set and enabled from the Platform 2.3.3 Position Monitor The Position Monitor feature is enabled by default, which means the TMX01 will report the location information every 24 hours. The information includes: Position 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. -
Page 7: Agps
2.3.5 LBS The LBS provides the location information by utilizing the carrier network signal. It is enabled when the TMX01 does not have GPS location information. Please note that LBS is largely dependent on distance to surrounding network cell sites, which could be up to a few miles away in worst case scenarios. -
Page 8: Optical Sensor
Table 3 - TMX01 Usage Working Mode Use Case Storage Mode is used when the TMX01 is ready for shipment. It can be stored (like in a Storage warehouse) for long periods of time while saving power. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. -
Page 9: Parameter Table
Version Default: v1.0 3.4 Periodic Mode 3.4.1 Introduction In Periodic Mode the device can only report data in fixed intervals. It can be used if there are no specific requirements. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 10: Configuration Example
For example, if the user sets the report interval to a month, Storage Mode can be activated. Storage Mode is off by default. 3.5.2 Configuration Example If the device is required to report data every 10080 minutes, Storage Mode can be configured as follows: 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 11: Schedule Mode
If the device is required to report data at 08:00, 12:30, 16:00 and 20:30 respectively, the user can set the device to Clock Mode (for this example, the device is in the time zone of UTC +08:00). The parameters can be configured as follows: 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 12: Device Data Fields
JSON-formatted data payload. The user can view the data fields in the device's Status and Statistics tabs on the Platform or via the API. The data fields supported by the device are listed in the table below. Table 5 - TMX01 Data Field Definitions Field Definition... -
Page 13: Troubleshooting
− The device is shown as being offline • Possible cause – The SIM card does not have an active subscription – The SIM card is inserted incorrectly – The device is asleep 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 14: Unable To Boot
Possible cause – The light intensity is too weak • Solution – Move the device to a position with more light 6 Installation Instructions The device external appearance is as follows: 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 15: Get Started
GPS green LED Off: No location 1s On, 1s Off: LBS location Solid On: GPS location GPRS red LED Fast blinking: GPRS connecting Slow blinking: GPRS connected Solid On: Module error 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 16: Sim Card Installation
(optical sensor side), making sure not to cover the sensor. Select a place where the device will be installed. Peel the other side of the tape and place it over a clean flat surface pressing down firmly. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! - Page 17 TMX-200225 If the device is removed, the optical sensor will be activated immediately. The Platform will display a “DEVICE_REMOVED” alarm along with the current location data. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right!
