- Page 1 ThingsMatrix: TMX-200225 TMX07 USER MANUAL 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved.
-
Page 2: Table Of Contents
3.4.1 Introduction ......................10 3.4.2 Configuration Example ..................10 3.5 Storage Mode ........................10 3.5.1 Introduction ......................10 3.5.2 Configuration Example ..................10 3.6 Motion Mode ......................... 11 3.6.1 Introduction ......................11 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! - Page 3 5.4 No optical sensor alert ...................... 15 6 Installation Instructions ........................ 16 6.1 Get Started ..........................16 6.2 SIM Card Installation ......................17 6.3 Device Power Up ......................... 17 6.4 Device Installation ......................18 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right!
-
Page 4: Tmx07 User Manual
2. Introduction 2.1 Overview TMX07 is an Intelligent device with long battery life, ultra-low power consumption, and support for 4G/2G global networks and positioning functionality. It also has an accelerometer (magnetic sensor and optical sensor are also available as an option). -
Page 5: Specifications
-20℃ to +70℃ Temperature Environmental Humidity 95%RH GPS Antenna Internal Antenna/SIM Cellular Antenna Internal SIM Form Factor SIM (2FF) Certification PTCRB Data Monitoring Supported Device Management Device Configuration Supported Firmware Upgrade Supported 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 6: Main Features And Use Cases
The wake-up feature must be set and enabled from the Platform 2.3.3 Position Monitor The Position Monitor feature is enabled by default, which means the TMX07 will report the location information every 24 hours. The information includes: Position 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. -
Page 7: Agps
2.3.5 LBS The LBS provides the location information by utilizing the carrier network signal. It is enabled when the TMX07 does not have GPS location information. Please note that LBS is largely dependent on distance to surrounding network cell sites, which could be up to a few miles away in worst case scenarios. -
Page 8: Optical Sensor
Table 3 - TMX07 Usage Working Mode Use Case Storage Mode is used when the TMX07 is ready for shipment. It can be stored (like in a Storage warehouse) for long periods of time while saving power. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. -
Page 9: Parameter Table
For example, set parameter "time zone: UTC Timezone Timezone +08:00", which means the device is in the time zone of UTC +08:00. Server Server Default: ftp.thingsmatrix.io Firmware Settings Port Port Default: 21 Version Version Default: v1.0 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 10: Periodic Mode
Storage Mode can be activated. Storage Mode is off by default. 3.5.2 Configuration Example If the device is required to report data every 10080 minutes, Storage Mode can be configured as follows: 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 11: Motion Mode
The priority of Motion/Static Mode is higher than the other two working modes (Clock Mode and Refresh Mode). The user can select a working mode according to the specific use case (refer to Table 3). 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 12: Configuration Example
The device cannot be woken up by vibration/motion in Clock Mode. The user can select a working mode according to their specific use case (refer to Table 3). 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 13: Configuration Example
JSON-formatted data payload. The user can view the data fields in the device's Status and Statistics tabs on the Platform or via the API. The data fields supported by the device are listed in the table below. Table 5 - TMX07 Data Field Definitions Field Definition... -
Page 14: Troubleshooting
− The carrier network cell tower that the device is attached to is too far • Solution − Move the device around so it can acquire a GPS signal 5.2 The device is offline • Problem − The device is shown as being offline 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 15: Unable To Boot
The optical sensor is exposed to light but there is no LED activity and no alarm • Possible cause – The light intensity is too weak • Solution – Move the device to a position with more light 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 16: Installation Instructions
Fast blinking: The indicator light flashes 2-3 times in 1s. Slow blinking: The indicator light flashes one times in 5s. GPS green LED Off: No location 1s On, 1s Off: LBS location Solid On: GPS location 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 17: Sim Card Installation
6.1, move the power switch to the left). When the red LED starts blinking, the device is powered on. Verify that the red LED starts blinking slowly. It may take up to 3 minutes. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right! -
Page 18: Device Installation
If the device is removed, the optical sensor will be activated immediately. The Platform will display a “DEVICE_REMOVED” alarm along with the current location data. 2021 ThingsMatrix Inc. Confidential Information. All Rights Reserved. Just Right!
