C4408R and C4408DR are compatible with ActiV conventional detectors.
Remove the optional identification and security tags from the centre of the
base and use as shown in steps 1, 2 & 4. See overleaf for wiring details.
Fit the ID tag
1
Fit the head-base locking mechanism (optional)
2
C4408R DETECTOR RELAY BASE
C4408DR DETECTOR RELAY BASE WITH DIODE
DFU0000409 Rev 1
Fit the detector
3
head
Unlocking the
4
detector head
