Refrigerator
Simple User manual
Free Standing Appliance
• In order to save valuable resources, we are reducing paper manuals and providing electronic user
manuals that you can check on your smartphone or a website.
• For the instructions of how to use the product, please refer to the user manuals provided as QR code or
the Samsung Electronics' website (http:/www.samsung.com/sec/).
• For more information about the following things, visit the Samsung website
(http://www.samsung.com), go to the Support section, and then search your model name.
-
How to minimize the energy consumption, additional tips for proper usage, operations, maintenance,
refrigerator type, specifications (dimensions).
Viewing the user manuals
Simple_A5_T-TYPE_RF5000C_DA68-04755C-01_EN.indd 1
1. Launch a QR code reader app and then scan the QR image attached to the
product.
2. Select a menu from the product registration, viewing the manuals, or
connecting a service. When you select a manual, you can view the manual
of your purchased product.
2023-06-15
10:54:15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Samsung RF44 Series
Summary of Contents for Samsung RF44 Series
- Page 1 • For the instructions of how to use the product, please refer to the user manuals provided as QR code or the Samsung Electronics’ website (http:/www.samsung.com/sec/). • For more information about the following things, visit the Samsung website (http://www.samsung.com), go to the Support section, and then search your model name.
-
Page 2: Table Of Contents
Contents Safety information Operations Important safety precautions Main panel Instructions about the WEEE SmartThings Safety Guide Maintenance Installation Cleaning Refrigerator at a glance Clearance Appendix Step-by-step installation Safety Instruction Install Instruction Temperature Instruction Information for model and ordering spare parts 23 2 ... -
Page 3: Safety Information
Safety information • R-600a or R-134a is used • To avoid contamination of food, as a refrigerant. Check the please respect the following compressor label on the rear instructions: of the appliance or the rating – Opening the door for label inside the fridge to see long periods can cause which refrigerant is used for... -
Page 4: Important Safety Precautions
– Two-star frozen-food • Fill with potable water only. compartments are suitable • Connect to potable water for storing pre-frozen food, supply only. storing or making icecream • Keep ventilation openings, in and making ice cubes. the appliance enclosure or in –... - Page 5 Lamp Covers and LED been given supervision or lamps yourself. instruction concerning use of – Contact a Samsung service the appliance in a safe way center. and understand the hazards – Use only the LED involved.
- Page 6 • To get the best energy WARNING efficiency of this product, • This appliance contains a please leave all shelves, small amount of isobutane drawers and baskets on their refrigerant (R-600a), a natural original position. gas with high environmental This appliance is intended to be compatibility that is, however, used in household and similar also combustible.
- Page 7 • R-600a or R-134a is used • Cyclopentane is used in the as a refrigerant. Check the insulation. The gases in the compressor label on the insulation material require a rear of the appliance or the special disposal procedure. rating label inside the fridge Please contact your local to see which refrigerant is authorities in regard to the...
-
Page 8: Instructions About The Weee
For information on Samsung’s environmental Installation commitments and product regulatory • This appliance should only be transported obligations, e.g. REACH, WEEE or Batteries,... - Page 9 • Do not place glass containers, bottles or cans power plug. Fore more details on grounding, (especially those containing carbonated drinks) inquire at the Samsung Electronics service in the freezer compartment, shelves or ice bin center. that will be exposed to temperatures below •...
-
Page 10: Installation
• If you close a door forcefully, the other door may open. • If the internal or external LED lamp is out of order, contact a local Samsung service center. • If the door is left open for too long, the top internal LED will blink. This is normal. -
Page 11: Clearance
Clearance See the following figures and tables for installation space requirements. RF44* RF49* Model RF50* RF57* RF5G* Depth “A” 715 mm 765 mm Width “B” 817 mm 817 mm Height “C” 1749 mm 1749 mm Overall Height “D” 1776 mm 1776 mm RF44* RF49*... -
Page 12: Step-By-Step Installation
Step-by-step installation STEP 1 Door removal for entrance Detach the fridge doors If the refrigerator cannot pass through the entrance to your home or kitchen due to its size, follow these instructions to remove and then re- install the refrigerator’s doors. If you do not need to remove the doors, go to page 14 to continue the installation procedure. - Page 13 To reattach the fridge doors After moving the refrigerator to its final location, reattach the doors by following the removal instructions in the reversed order. Detach the freezer drawer 4. Use a Phillips screwdriver to remove the screw fastening the ground wire (C). 1.
- Page 14 CAUTION • Be careful not to scratch or dent the rail 3. Use a socket wrench (10 mm) to fasten the door assembly. to the rail with 4 screws. • Make sure you mount the freezer baskets in the correct position. Otherwise, the door will not open or close properly, which causes frost to build up.
- Page 15 1. Fully open the freezer drawer (A), and then find • To adjust the height of the left side: Insert a the middle hinge (B). flat-head screwdriver into the leveler of the 2. Insert the Allen wrench (C) into the shaft (D) of left side front leg.
- Page 16 • Samsung takes no responsibility for the water line installation. If water leaks occur, contact the installer of the water line. To connect the cold water pipe to the water...
-
Page 17: Operations
Operations Main panel Type A Type B • Displays the current or desired temperature of the fridge. • indicates that the Power Cool function is on. 01 Fridge indicator • indicates that the AI Energy Mode is operating. (applicable models only) •... -
Page 18: Smartthings
• If your Internet service provider has registered the MAC address of your PC or modem for identification, your Samsung Smart Refrigerator may fail to connect to the Internet. If this happens, contact your Internet service provider for technical assistance. - Page 19 Samsung account You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. Getting started Turn on the device you want to connect, open the SmartThings app on your phone, and then follow the instructions below.
-
Page 20: Maintenance
The lamp(s) and/or control gear(s) are not user- 1. Unplug the power cord. serviceable. To replace the lamp(s) and/or control 2. Use a moistened, soft, lint-free cloth or paper gear(s) in the product, contact a local Samsung towel to clean the refrigerator’s interior and service centre. exterior. -
Page 21: Appendix
Appendix Safety Instruction • For the most efficient use of energy, please keep the all inner fittings such as baskets, drawers, shelves and ice cube tray on the position supplied by manufacturer. • This refrigerating appliance is not intended to be used as a built-in appliance. Install Instruction For refrigerating appliances with climate class Depending on the climate class, This refrigerating appliance is intended to be used at ambient... - Page 22 Power Cool Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for two and a half hours and then returns to the previous temperature. Power Freeze Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for 50 hours and then returns to the previous temperature.
-
Page 23: Information For Model And Ordering Spare Parts
Months. • Relevant information for ordering spare parts, directly or through other channels provided by the manufacturer, importer or authorized representative • You can find professional repair information on http://samsung.com/support. You can find user servicing manual on http://samsung.com/support. Appendix Simple_A5_T-TYPE_RF5000C_DA68-04755C-01_EN.indd 23... - Page 24 NOTE Hereby, Samsung declares that this radio equipment is in compliance with Directive 2014/53/EU and with the relevant statutory requirements in the UK. The full text of the EU declaration of conformity and the UK declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.
