  • Page 1 Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www. sam sung.co m/reg ister Free Standing Appliance...
  • Page 2 KEY FEATURES OF YOUR NEW REFRIGERATOR Your Samsung French Door Refrigerator comes equipped with various innovative storage and energy-efficient features. ,, Twin Cooling System The fridge and freezer have separate evaporators. Due to this independent cooling system, the fridge and freezer cool more efficiently. Additionally,...
  • Page 3 3 fet7 nforrn SAFETY INFORMATION Before using your new Samsung French Door Refrigerator, please read this manual thoroughly to ensure that you know how to safely and efficiently operate the features and functions that your new appliance offers. This appliance...
  • Page 4 3 fet7 nforrn • If the wall socket is loose, do not insert the power plug. There is a risk of electric shock of fire. • Do not use a cord that shows cracks or abrasion damage along its length or at either end. •...
  • Page 5 Lamp Cover and LED Lamp by yourself. Please contact your service agents. • If any dust or water is in refrigerator, pull out power plug and contact your Samsung Electronics service center. Otherwise there is a risk of fire. cAuTioN C AUTION SIGNS FOR USING •...
  • Page 6 Any changes or modifications performed by a 3rd party on this finished appliance is not covered under Samsung warranty service, nor can Samsung be responsible for safety issues that result from 3rd party modifications. • Do not block air holes.
  • Page 7 Storing food in the freezer drawer Using Flex Zone Removing the refrigerator accessories Removing the freezer accessories Food storage tips Cleaning the refrigerator TROUBLESHOOTING 40 Troubleshooting WARRANTY 41 Warranty on samsung refrigerator (27.7 Cubic feet and larger capacity) contents _07...
  • Page 8 First thing! Make sure that you can easily move your refrigerator to its final location by measuring doorways (both width and height), thresholds, ceilings, stairways, etc. The following chart details the exact height and depth of Samsung French Door Refrigerator. Overall Model Depth "A" Width "B" Height "C"...
  • Page 9 SETTING UP THE REFRIGERATOR Now that you have your new refrigerator installed in place, you are ready to set up and enjoy the features and functions of the appliance. By completing the following steps, your Refrigerator should be fully operational. 1.
  • Page 10 Disassemble refrigerator doors Be careful not to drop and scratch the doors while WARNING removing the doors. Disassemble refrigerator doors 1. With the door opened, remove the cap top table ( 1 ) with a flat-blade screwdriver(-), and close the door. Remove the 3 screws holding down the top table ( 2 ) and turn it with several wires connected.
  • Page 11 ur Frenoh Boor Aefr¢erator DISASSEMBLE THE FLEX DOOR 1. Take out the Flex room ( 1 ) by lifting it up. 2. Take off the cover ( 2 ) w/harness by with a flat-blade screwdriver(-). 3. Disconnect the housing connector. 4.
  • Page 12 DISASSEMBLE THE FREEZER DRAWER 1. Take out the upper drawer by lifting it up. 2. Remove the tilting pocket ( 1 ) by pulling both support guards ( 2 ) aside. And take out both support guards by pulling them aside. 3.
  • Page 13 ur Frenoh Boor Aefr¢erator REATTACHING THE REFRIGERATOR DOORS Assemble refrigerator doors 1. Reattach the lower left and right door hinges ( 12 ). With a Philips head screwdriver, insert and tighten the screw ( 10 ) into the lower left and right door hinges. With a allen wrench(3/16"), insert and tighten the 2 hex head bolts ( 11 ) into the lower left and right door hinges.
  • Page 14 4. Connect the dispenser door tube ( 5 ) and then insert a clip on the coupler with pulling tube. Connect the connector ( 4 ) on the left side door and one connector ( 3 ) on the right side door. The clip is enveloped inside of the top cap.
  • Page 15 ur Frenoh Boor Aefr¢erator ASSEMBLE THE FLEX DOOR 1. Pull out the rails fully on each side of the cabinet. 2. Attach the Flex door front onto the open slots on the sides. 3. Tighten 2 hex head bolts completely with a socket wrench (10mm).
  • Page 16 ASSEMBLE THE FREEZER DRAWER 1. Pull out the rails fully on each side of the cabinet. 2. Attach the freezer door front onto the open slots on the sides. 3. Tighten 4 hex head bolts completely with a socket wrench(10mm). 4.
  • Page 17 ur Frenoh Boor Aefr¢erator INSTALLATION OF THE REFRIGERATOR HANDLES 1. Make sure the word "UP" on the rear of the handle is facing right side up. 2. a. Match the upper and lower Handle Locking Tabs on the doors to the handles.
  • Page 18 INSTALLATION FO THE FLEX AND FREEZER HANDLE 1. Make sure the word "The Upper Direction" on the side of the handle is facing up. • ....,,., 2. a. Align the handle with the mounting studs. b. Push the handle onto the mounting studs until you hear a click.
  • Page 19 Sett r French Door Refrgerator ADJUSTING THE LEVEL After putting the doors back on the refrigerator, make sure the refrigerator is level so that you can make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even, which may cause moisture condensation and increased energy bills.
  • Page 20 MAKING MINOR ADJUSTMENTS BETWEEN DOORS Remember, a leveled refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the refrigerator. When the left When the left door is lower than door is higher the right door.
  • Page 21 Sett n ur French Door FRefr gerator ADJUSTING THE FREEZER DRAWER LEVEL Adjustment part Freezer Drawer 1. Locate the height-adjuster ( 1 ) in the freezer drawer. Unscrew the 8 Phillips screws ( 2 ) slightly to loosen the door. 2.
  • Page 22 CHECKING THE WATER DISPENSER LINE A water dispenser is one of the helpful features on your new refrigerator. To help promote better health, the water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. You may need to purchase a water purifying system to do that.
  • Page 23 Sett n ur French Door Refrgerator INSTALLING THE WATER LINE Connecting the water supply line to the refrigerator, There are several items that you need to purchase to complete this connection. You may find these items sold as a kit at your local hardware store.
  • Page 24 © sr French Door FRefr gerator USING THE CONTROL PANEL Press the Energy Saver button for better energy efficiency. This icon will light up when you press the Energy Saver button. The Energy Saver function is automatically set to "ON" when power is supplied to the refrigerator. If condensation or water drops occur on the doors, turn the Energy Saver mode off.
  • Page 25 Cubed Crushed Press the Lighting button to turn on the Dispenser LED lamp. This icon will light up when you press the Lighting button. In this case, the dispenser light (under the display) will be on constantly. If you would like the dispenser light to come on only when using the dispenser, turn the Lighting mode off.
  • Page 26 USING THE CONTROL PANEL Freezer Temp ( 1 ) indicates the current freezer temperature. Fridge Temp ( 2 ) indicates the current refrigerator temperature. If you do not press any button, freezer & fridge temperature indicator will turn off in a few seconds. If any button is pressed, the display will light up again.
  • Page 27 When you pull the water filter, a little of water can be leaked. It is normal. To minimize the water leak, keep the filter cartridge horizontal or down the grip when you pull it. In order to prevent overflow, empty the tray water filter ( 3 ). And dry around of case filter ( 2 ).
  • Page 28 Display and Main Controller, the Convertible Display light may blink. Once the normal set temperatures are reached, the blinking will stop. If the blinking continues for a long period of time, please contact a Samsung Electronics Service Center. 28 Operat ng...
  • Page 29 USING THE TWO LEVER DISPENSER Press the ice type or water button to select the type of you want Cubed Crushed Using ice Dispenser ( 1 ) Place a glass underneath the two lever dispenser and push gently against the dispenser upper lever with your glass.
  • Page 30 © jr Frenoh Door Aefr erator If a power failure occurs, ice cubes may melt then freeze together when the power comes back on, causing the dispenser to be out of order. CAUTION To prevent this problem, pull out the ice bucket and discard the residual ice or water. When you dump the ice from the ice bucket, you should press the dispenser...
  • Page 31 PARTS AND FEATURES Use this page to become more familiar with the parts and features of the refrigerator. interlocking switch Light Door Closer FF Ice-Maker Cover Eva (Light) Right Door Bins Slide-Shelf Tempered glass shelves Cap Chute Light Vertical Hin( Section Quick-Space Glass Shelf...
  • Page 32 STORING FOOD IN THE REFRIGERATOR The Samsung Refrigerator has been designed to provide you with maximum space saving features and functions. Here are some of the customized compartments we have created to keep your food fresher longer. In order to further prevent odor from seeping into the ice compartment,...
  • Page 33 r French Door Refrgerator ©perat n USING FLEX ZONE The Flex Zone is a full-width room with an adjustable temperature control. This Flex room can be used for large party trays, deli items, wines, pizzas, beverages or miscellaneous items. There is a temperature sensor which can adjust the amount of cold air...
  • Page 34 © REMOVING THE REFRIGERATOR ACCESSORIES 1.Door Bins & Dairy Compartment To remove - Simply lift the bin up and pull straight out. To relocate - Slide it in above the desired location and push down until it stops. Injury may occur if the door bins are not firmly assembled. Do not allow children to play with bins.
  • Page 35 4.Fie× Zone To remove the Flex room - Pull the Flex door out to full extension. And lift Flex room up, pulling it to your body with both hands. To relocate the Flex room - Open the Flex room to full extension. In this condition, make Flex room reached to rail slantingly and push it...
  • Page 36 © sr French Door FRefr gerator REMOVING THE FREEZER ACCESSORIES 1.Tilting Pocket To remove - Pull both bracket the tilting pocket ( 1 ) by pulling both suport guards ( 2 ) aside. And take out both support guards by pulling them aside. To replace - Hook the ends of the pocket into both brackets ( 2 ) and push down until it locks into place.
  • Page 37 FOOD STORAGE TIPS DAIRYPRODUCTS Butter 2-3 Weeks 6-9 Months Wrap or cover tightly. Check date code. Most milk and similar products are sold in date-coded Milk 1-2 Weeks Not recommended cartons that indicate a products's peak freshness. Re-sealwith cap or wrap tightly.
  • Page 38 © jr Frenoh Door Aefr erator iiiii,, FISH AND SHELLFISH Fish Fatty Fish (mackerel, 1-2 Days 2-3 Months trout, salmon) Keep in original wrapper and store in coldest part of refrigerator.Pack- Lean Fish (cod, flounder, age invapor-proof and moisture proof wrap for freezer. Freezeat 0°R 1-2 Days 6 Months etc)
  • Page 39 CLEANING THE REFRIGERATOR Caring for your Samsung French Door Refrigerator prolongs the life of your appliance and helps keep the refrigerator from odor and germ. Cleaning Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth. You can remove the drawers and shelves for a more thorough cleaning.
  • Page 40 [roub e¢hoot n¢ TROUBLESHOOTING The refrigerator • Check that the power plug is properly connected. does not work at all • Check the set temperature on the digital display is warmer than freezer or fridge inner temperature. , • Set the refrigerator colder. or it does not chill Is the refrigerator in direct sunlight or located near a heat source?
  • Page 41 Samsung authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to Samsung or Samsung authorized service center. Samsung will repair or replace any part found...
  • Page 42 WARRANTY PERIODS STATED ABOVE, A NDNOOTHER EXPRESS W ARRANTY ORGUARANTY GIVEN BYANY PERSON, F IRMORCORPORATION WITHRESPECT TOTHISPRODUCT SHALLBEBINDING ONSAMSUNG. SAMSUNG SHALLNOTBELIABLE FORLOSSOFREVENUE O RPROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, ORANYOTHER SPECIAL, INCIDENTAL ORCONSEQUENTIAL DAMAGES CAUSED BYTHE USE,MISUSE ORINABILITY TO USETHISPRODUCT, REGARDLESS OFTHELEGAL THEORY ONWHICH THE CLAIMISBASED, A NDEVENIFSAMSUNG HASBEENADVISED OFTHEPOSSIBILITY O F SUCHDAMAGES.
  • Page 44 QUESTIONS OR COMMENTS? COUNTRY CALL ORWSlT U S O.U.E WR_TE 800-SAMSUNG Samsung Electronics America, Inc. 400 Valley Road (800-726-7864) www.samsung.com Suite 201 Mt. Arlington, NJ 07956 800-SAMSUNG Samsung Electronics Canada Inc. Customer Service, CANADA (800-726-7864) www.samsung.com/ca 55 Standish Court Mississauga, Ontario L5R 4B2 Canada Code No.
