SwimPure Plus
®
Electronic Chlorine Generator
Owner's Manual
Contents
Operation..............................2
Installation.......................11
Troubleshooting.................. 15
Warranty..............................18
W3SWP15
W3SWP9
Hayward Pool Products
620 Division Street, Elizabeth NJ 07207
Phone: (908) 355-7995
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Advertisement
Related Manuals for Hayward SwimPure Plus W3SWP15
Summary of Contents for Hayward SwimPure Plus W3SWP15
- Page 1 092744 RevC SwimPure Plus ® Electronic Chlorine Generator Owner’s Manual Contents Operation......2 Installation.......11 Troubleshooting....15 Warranty......18 W3SWP15 W3SWP9 Hayward Pool Products 620 Division Street, Elizabeth NJ 07207 Phone: (908) 355-7995 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 2 • Hayward salt systems are designed, tested and sold as systems and are certified by several agencies around the globe --- with each component of the systems meeting all required certi- fications and attendant legal requirements. The use of an untested, uncertified generic cells (or generic circuit boards) with Genuine Hayward salt chlorination products could lead to premature product failure.
-
Page 3: Operation
NOTE: Hayward does not recommend using the SwimPure Plus to generate bromine. Select the proper model for your pool (installation and mounting requirements are the same for all... - Page 4 Use the table above to determine Ti, Ci, Ai, and TDS in the formula shown above. If the Si is equal to 0.2 or more, stains may appear. If the Si is equal to -0.2 or less, corrosion or deterioration may occur. -0.2 Corrosion Stain USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 5 For outdoor pools, always check stabilizer (cyanuric acid), when checking salt. These levels will most likely decline together. Use the chart on page 6 to determine how much stabilizer must be added to raise the level to 40 ppm. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 6 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 7 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 8 SUPER CHLORINATE Illuminates during super-chlorination. See description above. REMOTELY CONTROLLED When illuminated, indicates that a remote pool automation control (Hayward Pro Logic, Pentair Intellitouch, Polaris Eos, etc.) is controlling the SwimPure Plus--the main switch and "Desired Output %" adjustment are inactive. When flashing, the Pro Logic, Intellitouch or Eos is in SERVICE or TIME-OUT mode and the Main Switch and "Desired Output...
- Page 9 The Instant Salinity display is the measured salt level of the pool water at that moment. If salt has recently been added, the Instant Salinity may show the change while the Salt Display (average salt level) may take some time before the changes can be seen. Under these circumstances, you may USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 10 “Desired Output %” should be lowered accordingly. When connected to a pool automation control (Hayward Pro Logic, Pentair Intellitouch or Polaris Eos): The SwimPure Plus is designed to operate with all pool automation controls. The Pro Logic, Intellitouch or Eos can fully control the function of the SwimPure Plus chlorinator in addition to the other pool equipment.
- Page 11 Spring Start-up DO NOT turn the SwimPure Plus on, until the pool water chemistry has been brought to the proper levels. This information can be found on page 3. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 12: Installation
Because the enclosure also acts as a heat sink (disperses heat from inside the box), it is important not to block the four sides of the control. Do not mount SwimPure Plus inside a panel or tight enclosed area. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 13 Install using the unions provided. Tighten unions BY HAND for a watertight seal. For pool/spa combination systems with spillover, use configurations #2 or #3 above to allow chlorination of both the pool and spa during spillover but preventing overchlorination when operating the spa only. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 14 (similar to a telephone jack) located outside, on the bottom of the enclosure. Refer to the diagram below for the location of these connections. Cutout for Flow switch connector cell cable Bonding lug to pool bonding system USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 15 Optional Hayward, Pentair and Polaris controls: The Hayward, Pentair and Polaris controls use a 4 wire connection to communicate to the SwimPure Plus and can be wired up to 500' apart. Any outdoor rated 4 conductor cable can be used. Refer to each manufacturer's instructions and the wiring diagrams below for proper wiring connection to the SwimPure Plus.
-
Page 16: Troubleshooting
Polaris PCB. Swimpure Plus Troubleshooting Visit www.hayward.com for helpful information on operation, maintenance and troubleshooting your SwimPure Plus Electronic Chlorine Generator. Diagnostic Displays Sequential pushes of the small "diagnostic" button next to the LCD display will cause the SwimPure Plus to display the following information: 1. - Page 17 - High level of Nitrogen in pool water. - "Yellow Out" or similar treatment recently used. Some yellow algae treatments will use chlorine at a very high rate and deplete the residual free chlorine. Manually shock the pool if indicated USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 18 30 - 50 ppm Add cyanuric acid to increase. Calcium 200 - 400 ppm Add calcium to increase. Drain and add water to decrease. Electrolytic Cell inspect & clean Refer to section in manual. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 19: Warranty
In no event shall Hayward Pool products be responsible for any consequential, special or incidental damages of any nature. Some states do not allow a limitation on how long an implied warranty lasts, or the exclusion of incidental or consequential damages, so the above limitation may not apply to you. - Page 20 Hayward is a registered trademark and SwimPure Plus, Pro Logic and Aqua Logic are trademarks of Hayward Industries, Inc. © 2019 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
