11017_AB
EarthX Lithium
Battery User' s
Manual
Copyright© 2023 EarthX, Inc. All rights reserved. The information contained in this document is the property of EarthX, Inc.
EarthX reserves the right to make changes to its documents or products without notice. It is the responsibility of each user to
ensure that all applications of EarthX's products are as intended and safe based on conditions anticipated or encountered during
use. The EarthX logo is a trademark of EarthX, Inc

Advertisement

Table of Contents
loading

Related Manuals for EarthX ETX1600

Summary of Contents for EarthX ETX1600

  • Page 1 Copyright© 2023 EarthX, Inc. All rights reserved. The information contained in this document is the property of EarthX, Inc. EarthX reserves the right to make changes to its documents or products without notice. It is the responsibility of each user to ensure that all applications of EarthX’s products are as intended and safe based on conditions anticipated or encountered during...

  • Page 2: Table Of Contents

    E T X - S E R I E S L I T H I U M B A T T E R I E S T able of Contents Overview ................... 1 Technology Inside ................1 Battery Cells ..................1 ETZ-Series - BMS ................

  • Page 3: Overview

    B A T T E R I E S Overview EarthX Lithium batteries are designed as a maintenance free replacement for the 12-volt lead-acid or lithium batteries. To ensure a smooth replacement process, our batteries are similar in dimensions to many OEM motorsport or power sport batteries. Our 12V replacement lithium battery consists of 4 Lithium Iron Phosphate (LiFePO4) cells in series and one or more in parallel with built in electronics to protect the lithium cells.

  • Page 4: Etz-Series - Bms

    ETZ-Series - BMS All EarthX integrated BMSs continuously monitor each cell’s voltage as part of the cell balancing and over-charge protection. If the voltage of a cell exceeds the others, the BMS circuits will work to reduce that cell’s charge level. This ensures that the charge level of all the cells remains equal, even with the high discharge (>...

  • Page 5: Etx-Hundred Series - Bms

    (crowbar circuit) to activate first. This design offers charge voltage protection greater than 40V. The discharge current (current out of battery) is unaffected in this situation. EarthX requires having automatic over-voltage protection (crowbar) for alternator type charging systems (not required for <20 Amp pad mount standby alternators).

  • Page 6: Operating Instruction

    E T X - S E R I E S L I T H I U M B A T T E R I E S single wire connection with a ¼” quick connect terminal. The output is a “current sinking” type circuit (see diagram below) that can handle 100mA (connects the discrete output to battery ground if a fault is present).

  • Page 7: Limitations

    E T X - S E R I E S L I T H I U M B A T T E R I E S LED Light Voltage Possible Cause Recommended Action Battery over-discharged Slow Flashing Less than Charge battery. Once charged, the (due to faulty charging (5s on/5s off) 12.8V...

  • Page 8: Specifications

    E T X - S E R I E S L I T H I U M B A T T E R I E S • The maximum charge rating shown in the specification section (model specific) must be adhered to.
  • Page 9 E T X - S E R I E S L I T H I U M B A T T E R I E S Pulse Crank Amps (PCA) 690A (3 sec @ 20 °C, voltage >7.2V) Cold Crank Amps (CCA) 330A (modified SAE test, 3 sec@ 0°F, voltage >7.2V) Self-Discharge Rate...
  • Page 10 E T X - S E R I E S L I T H I U M B A T T E R I E S Operating Temperature -30 °C to +60 °C Storage Temperature -40 °C to +70 °C Model: ETX18B, ETX18C, ETX18F (ETX18C discontinued as of 2-2019, use ETX18F as replacement) Voltage...
  • Page 11 E T X - S E R I E S L I T H I U M B A T T E R I E S Recommended Charger/Maintainer .8 - 10A Amps Max Charge Amps 40A (from vehicle charging system) Life (Charge cycles) 4000 cycles @ 1C discharge rate, 25°C (20% depth of discharge)
  • Page 12 E T X - S E R I E S L I T H I U M B A T T E R I E S Environmental Rating (resistance to IP 66 (wash down with a high-pressure water intrusion) washer) Operating Temperature -30 °C to +60 °C Storage Temperature...
  • Page 13 E T X - S E R I E S L I T H I U M B A T T E R I E S 2000 cycles @10C discharge rate, 25°C (80% depth of discharge) Life (Years) Up to 6 Years Weight 1.3 lb.
  • Page 14 E T X - S E R I E S L I T H I U M B A T T E R I E S 14.5 6.2A (.5C) 12.4A (1C) 13.5 18.6A (1.5C) 12.5 11.5 10.5 Amp-hours (Ah) ETX680/680C Discharge Capacity 6.2A (.5C) 12.4A (1C) 18.6A (1.5C)
  • Page 15 E T X - S E R I E S L I T H I U M B A T T E R I E S Model: ETX900 / ETX900-VNT Voltage 13.2 V Capacity 15.6Ah @ 1C rate (See below) Capacity vs Temperature 25 °C = 100% 0°C = 97%...
  • Page 16 E T X - S E R I E S L I T H I U M B A T T E R I E S ETX900 Discharge Capacity 6.2A (.39C) 12.4A (.77C) 18.6A (1.16C) 90 100 110 120 130 140 150 160 Time (Minutes) ETX900 Discharge Time Model: ETX1200 (Discontinued January 2023, replaced with ETX1200 (Gen 2)
  • Page 17 E T X - S E R I E S L I T H I U M B A T T E R I E S Pulse Crank Amps (PCA) 1200A (3 sec @ 20 °C, voltage >7.2V) Cold Crank Amps (CCA) 600A (modified SAE test, 3 sec@ 0°F, voltage >7.2V) Max Continuous Discharge Amps...
  • Page 18 E T X - S E R I E S L I T H I U M B A T T E R I E S Environmental Rating (resistance to IP 66 (wash down with a high-pressure water intrusion) washer) Operating Temperature -30 °C to +60 °C Storage Temperature...
  • Page 19 E T X - S E R I E S L I T H I U M B A T T E R I E S Model: ETX1600 Voltage 13.2 V Nominal Voltage 12.8 V Capacity 32Ah @ 1C rate Capacity vs Temperature 25 °C = 100%...
  • Page 20 E T X - S E R I E S L I T H I U M B A T T E R I E S Recommended Charger/Maintainer 5 - 20A Amps Max Charge Amps 80A (@28.8V from charging system); 150A (@28V from charging system) Life (Charge cycles, 80% depth of 4000 cycles @ 1C...
  • Page 21 E T X - S E R I E S L I T H I U M B A T T E R I E S ETX900-24 Discharge Capacity Model: ETX680-24-VNT Voltage 26.4 V Capacity 11.7Ah (See charts) Capacity vs Temperature 25 °C = 100% 0°C = 97% -30°C = 95%...
  • Page 22 E T X - S E R I E S L I T H I U M B A T T E R I E S Dimensions 6.5 in (L) x 5.1 in (W) x 6.6 in (H) 166mm(L) x 129mm (W) x 168mm (H) Environmental Rating (resistance to IP 66 (wash down with a high-pressure water intrusion)
  • Page 23 E T X - S E R I E S L I T H I U M B A T T E R I E S Model: ETX1200-24-VNT Voltage 26.4 V Capacity (1C, 1hour rate at 23 °C) 19.4Ah @ 1C rate (See below) Capacity vs Temperature 25 °C = 100% 0°C = 97%...

  • Page 24: Discharge Versus Temperature

    E T X - S E R I E S L I T H I U M B A T T E R I E S ETX1200-24-VNT Discharge Capacity Discharge Versus Temperature We use a similar Cold Cranking Amp test standard as the lead acid battery manufacturers (SAE test performed at 0°F, but 3 second discharge time vs 30 second).

  • Page 25: Self-Discharge Rates

    E T X - S E R I E S L I T H I U M B A T T E R I E S Self-discharge Rates The self-discharge rate is dependent on temperature. At high temperatures (>25°C), the cell internal resistance decreases so the self-discharge rate increases.
  • Page 26 ETX12 discharge curves at a 1C rate over a wide operating temperature range. Note: there can be as much as a 15% decrease in Ah and discharge voltage at -30deg C as compared to 25 deg C. All the EarthX ETX-Series batteries exhibit similar discharge curve profiles.

  • Page 27: Installation

    E T X - S E R I E S L I T H I U M B A T T E R I E S Installation Battery Installation Lithium Iron Phosphate batteries are very robust, but if mishandled or misused they can rupture and they can burn.

  • Page 28: Fault Monitoring Installation (Etx-Hundred Series)

    E T X - S E R I E S L I T H I U M B A T T E R I E S Make sure the Phillips screws are securely fastened (35in-lbs for 6mm screw, 45in-lbs for 8mm screw), but do not over-tighten. 4.
  • Page 29 E T X - S E R I E S L I T H I U M B A T T E R I E S Fault Monitoring Connection to Dynon Avionics SkyView SV-EMS-220/221 Configure the input as “active low”, “alarm” type. Note; when Dynon power is off the LED inside battery may be dimly lit (less than 120uA, too small to drain the battery).
  • Page 30 E T X - S E R I E S L I T H I U M B A T T E R I E S Fault Monitoring Connection to Garmin EFIS (G3X) Configure the digital input 1-4 (pin 40-43) as “active low”, “user defined alert” type. Fault Monitoring Connection to Grand Rapids Technologies EFIS...
  • Page 31 E T X - S E R I E S L I T H I U M B A T T E R I E S The following example details how to connect the fault monitoring output to a remote LED. An incandescent bulb can NOT be used.

  • Page 32: Voltage Monitoring Alert Recommendation (Existing Aircraft Equipment If Applicable)

    E T X - S E R I E S L I T H I U M B A T T E R I E S Connect the LED’s red wire (positive) to a spare or existing fuse or breaker off the electrical bus. Use any .25 Amp to 2 Amp fuse or breaker.

  • Page 33: Vent Tubing Installation (Model With Part # That End In Vnt)

    ID of 3/8”. Fittings must be brass or stainless if installed within 2 feet from the battery (EarthX supplied kit parts ok). For fittings more than 2 feet from the battery they may be polyethylene or nylon. See figure below for tubing connections to the battery and clearances.
  • Page 34 E T X - S E R I E S L I T H I U M B A T T E R I E S Images below for ETX680-24-VNT Mounting and Vent Tubes...
  • Page 35 E T X - S E R I E S L I T H I U M B A T T E R I E S Images below for ETX1200-24-VNT Mounting and Vent Tubes...
  • Page 36 E T X - S E R I E S L I T H I U M B A T T E R I E S Back View Top View...

  • Page 37: Battery Inspection And Testing

    E T X - S E R I E S L I T H I U M B A T T E R I E S Battery Inspection and Testing The ETX-Hundred Series battery is a maintenance free battery. Charging is only required as needed (see charging section in this manual).

  • Page 38: Charging

    25 amps. After installing the ETX680, the peak charge amps jumped to 54 amps. This is normal and as expected and within the charge current rating of the ETX680. This table shows typical charging times for the different EarthX batteries: Model Charging Amps...
  • Page 39 15V! This will damage the battery. If in doubt, consult the manual that comes with your charger. The “full charge” voltage for the EarthX Lithium battery is 13.9V or higher. Some lead-acid battery trickle charger’s maintenance mode voltage can be below 13.3V, which is too low for a lithium battery.
  • Page 40 (set at 13 volt) or another 12V battery in parallel with the EarthX battery so the charger will read the connected device’s voltage. Once the charger sees a normal battery voltage (volts above 9 volts) it should engage and start charging.

  • Page 41: Storage

    EarthX, Inc. (Manufacturer) warrants its ETX-Series lithium batteries (hereafter referred to as Battery or Batteries) and the EarthX Jump Pack to be free of defects in material and workmanship for a period of two years. EarthX, Inc. warrants the ETZ-Series lithium batteries to be free of defects in material and workmanship for a period of 1 year.

  • Page 42: Troubleshooting

    EarthX’s acceptance of any items shipped to EarthX for warranty replacement shall not be deemed an admission that the item(s) are defective. For international warranty returns, customer will pay the shipping expenses.

  • Page 43: Regulations

    E T X - S E R I E S L I T H I U M B A T T E R I E S Regulations The ETX-Series Lithium battery, including the ETX-Hundred Series, are designed and tested to the following safety regulations as outlined in: •...
